Lincoln Electric Certified Pre-Owned Easy MIG Flux-Core/MIG Welder Transformer, 208/230V, 30-180 Amp Output, Model # U2689-2

Item# 115202
Lincoln Electric Certified Pre-Owned Easy MIG Flux-Core/MIG Welder Transformer, 208/230V, 30-180 Amp Output, Model # U2689-2

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Lincoln Electric Certified Pre-Owned Easy MIG Flux-Core/MIG Welder Transformer, 208/230V, 30-180 Amp Output, Model # U2689-2

Click or Tap image to Zoom

$749.99

  • Shipping:

    Not available

  • In Store Only:

    Not Available
  • Plug in the MIG180 wire feed welder anywhere 208/230V input power is available
  • Weld up to 140 Amps and a maximum thickness of 1/2in.
  • Metal case provides protection from the elements
  • Ideal for maintenance and mobile welders
  • Simple two-knob control for wire speed and voltage

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Lincoln Electric Certified Pre-Owned Easy MIG Flux-Core/MIG Welder Transformer features 208/230V input with 30-180 Amp output. Every Lincoln Electric Certified Pre-Owned machine undergoes a comprehensive cleaning, inspection, and full servicing by our dedicated team to guarantee our stringent quality standards. We subject each machine to the same rigorous testing procedures as new equipment. Any flaws found, such as minor scratches and dents, are purely cosmetic and will not affect the machine's performance. Whether you are a home DIYer or a professional, the Lincoln Electric Certified Pre-Owned MIG 180 wire feed welder is the perfect tool for your next project. Requiring 208/230 Volt input power, the MIG 180 allows you to weld on thicker material! With its simple two knob controls and lightweight wire drive system; this compact welder is easy to use even for beginners! The user-friendly interface makes dialing in easier and yields a smooth arc with minimal splatter. The Lincoln Electric MIG180 is an excellent choice for light fabrication, home shops and farm repairs.

What's Included

    (1) Lincoln Electric Certified Pre-Owned MIG 180 Flux-Core/MIG Welder, Model# U2689-2 (1) MIG Gun (3) .025in. contact tips and (2) .035in. contact tips (1) Gasless nozzles (1) Spindle adapter for 8in. diameter spools (1) Shielding gas apparatus (1) Sample spool MIG wire (1) Sample spool of flux-core wire (1) Drive roll for .025 and .035 wire (1) Work clamp

Downloads

Product Manual

Features + Benefits

  • Plug in the MIG180 wire feed welder anywhere 208/230V input power is available
  • Weld up to 140 Amps and a maximum thickness of 1/2in.
  • Metal case provides protection from the elements
  • Ideal for maintenance and mobile welders
  • Simple two-knob control for wire speed and voltage
  • Best for DIY projects, hobbyists, home repairs and more
  • Fully adjustable drive system reduces the chance of wire tangling and crushing
  • Brass-to-brass gun connection enhances conductivity
  • Ideal for shop, farm and home
  • MIG aluminum welder capabilities with spool gun sold separately

Key Specs

AttributeSpecification

item#

115202

Brand

Lincoln Electric

Manufacturer's Warranty

3 year limited warranty

Ship Weight

69.0 LB

Volts

208/230

Max. Amps

180

Power Type

AC

Multi-process

Yes

Spool Gun Included

No

Welding Processes

Flux-Core, MIG

Max. Weld Thickness

0.5 in

Max. Welding Wire Diameter

0.045 in

Duty Cycle

30% At 130a
AttributeSpecification

Weldable Materials

Steel, Stainless Steel, Aluminum

Min. Amps

30

Wire Feed Speed Control

Yes

Cart Included

No

Mig Ready

Yes

Power Cord Length

10 ft

Clamp Cable Length

10 ft

Electrode Cable Length

6 ft

Regulator and Gas Hose Included

Yes

Shielding Gas Required

Yes

Product Weight

56.0000 lb

Dimensions L x W x H (in.)

14.0 x 10.15 x 18.2 in

Reviews

Questions & Answers

5 Reviews This action will navigate to reviews.

Questions

1–3 of 3 Questions
Sort by:

  1. What is the thinest metal it will weld?

    1 answer

    1. The thinnest metal the machine will weld is 24 gauge mild steel.

      Helpful?

  2. Is it a gas welder also

    1 answer

    1. The welder can be used with gas. It will include a regulator and gas hose.

      Helpful?

  3. Why do you say "weld up to 140 amps" when it's a 180 welder?

    1 answer

    1. The output range on the welder is 30-180 amps DC 50-500 IPM WFS. The rated output current/voltage/duty cycle is 208 volts:130 A/17.6 V/30% and 230 volts: 130A/20V/30%.

      Helpful?
