Hobart Handler 100 Flux-Core Welder, Transformer, 115V, 30-100 Amp Output, Model# 500572

Item# 68750
On Sale
Hobart Handler 100 Flux-Core Welder, Transformer, 115V, 30-100 Amp Output, Model# 500572

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Hobart Handler 100 Flux-Core Welder, Transformer, 115V, 30-100 Amp Output, Model# 500572

Click or Tap image to Zoom

$248.99
Reg $299.99Save $51.00

Order today to get this price.

  • Shipping:

    Not available

  • In Store Only:

  • Compact design with versatile and powerful output
  • Capable of welding 18-ga. to 3/16in. (4.8mm) mild steel with flux-core wire
  • Amperage output: 30-100
  • 4 output voltage settings provide a broader operating window for each wire, with quick and easy thickness and joint adjustments
  • Durable, positive feed head with quick-release drive roll tension lever for adjustable tension plus easy accessibility to thread new wire

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Hobart Handler 100 Flux-Core Welder is the perfect welding choice for the novice or personal user to perform light fabrication projects, maintenance and repair, and farm/home applications. This compact welder has a broad output range of 30 to 100 Amps that allows you to weld up to 3/16in. (4.8mm) steel with flux-core wire. Comes ready to weld without shielding gas; no additional kits are required. Includes Hobart's 5/3/1in.dustrial Warranty - Five-year warranty on transformers, stabilizers and main rectifiers; three years on generators, PC boards and drive systems; and one year on guns (MIG, plasma and TIG torches).

What's Included

    (1) Hobart Handler 100 Flux-Core Wire-feed Welder (1) 8ft. Gun, (1) Work cable with clamp, (1) Set of 0.030in. contact tips, (1) Power cord with plug

Downloads

Product Manual Product Manual2

Features + Benefits

  • Compact design with versatile and powerful output
  • Capable of welding 18-ga. to 3/16in. (4.8mm) mild steel with flux-core wire
  • Amperage output: 30-100
  • 4 output voltage settings provide a broader operating window for each wire, with quick and easy thickness and joint adjustments
  • Durable, positive feed head with quick-release drive roll tension lever for adjustable tension plus easy accessibility to thread new wire
  • Built-in contactor makes wire electrically "cold" until the trigger is pulled, providing excellent safety and ease of use
  • Operates with 115 Volt household current
  • Manual wire feed speed control of 85-310 IPM (inches per minute)
  • Comfortable 8ft. gun with liner for 0.030in. and 0.035in. diameter wire
  • Includes work cable with clamp, 0.030in. (0.8mm) contact tips and power cord with plug

Key Specs

AttributeSpecification

item#

68750

Brand

Hobart

Manufacturer's Warranty

5 year limited warranty

Ship Weight

46.8 LB

Volts

115

Max. Amps

100

Power Type

AC

Multi-process

No

Welding Processes

Flux-Core Only

Max. Weld Thickness

0.31 in

Max. Welding Wire Diameter

0.035 in
AttributeSpecification

Duty Cycle

20% At 80a

Weldable Materials

Steel

Min. Amps

30

Wire Feed Speed Control

Yes

Cart Included

No

Power Cord Length

5 ft

Clamp Cable Length

5 ft

Regulator and Gas Hose Included

No

Shielding Gas Required

No

Product Weight

lb

Dimensions L x W x H (in.)

16.0 x 10.0 x 13.5 in

Reviews

Questions & Answers

34 Reviews This action will navigate to reviews.

Questions

1–10 of 16 Questions
Sort by:

  1. Can this welder weld Aluminum

    1. This welder cannot weld aluminum.

      Helpful?

    2. Not that I know of, there are other options for welding aluminum. Such as a MIG welder spool gun or an AC capable TIG welder.

      Helpful?

  2. What type of gas hole does it use?

    1 answer

    1. This welder is just a flux core welder, it would not use any type of gas.

      Helpful?

  3. Will this welder run off a Honda 5000 generator

    1 answer

    1. A minimum 3,675 watt surge generator would be recommended for this Hobart Handler 100. A Honda 5000 watt generator will be enough for this welder.

      Helpful?

  4. What would the duty cycle be if I ran it on 2/35 on the settings??

    1 answer

    1. The duty cycle would be determined by the size and type of wire you are using. If using .030 14 gauge wire, the duty cycle would be approximately 15 -20% (about 1 1/2 minutes out of 2 minutes).

      Helpful?

  5. do you need to use a 4 plug (like the one in some dryers) for wiring this

    1 answer

    1. The welder comes with a 3-prong 115-volt plug. This model operates with 115-volt household current.

      Helpful?

  6. Will this welder weld quarter inch steel

    1 answer

    1. This welder can weld up to 3/16" steel in a single pass. Welding 1/4" steel may require multiple passes.

      Helpful?

  7. Can you use a 5 lb spool in this?

    1 answer

    1. This welder will accept a 5 lb. spool.

      Helpful?

  8. Does this welder allow changing the wire feed liner? Can this welder use .023 flux core wire?

    1 answer

    1. The individual wire feed liner part of the gun assembly is available from the manufacturer directly. This welder is only designed for 0.030 and 0.035 flux cored wire.

      Helpful?

  9. where are fuses located

    1 answer

    1. This welder has a circuit breaker instead of a fuse. It is located on the back of the welder near where the power cord comes in.

      Helpful?

  10. How many amps does this welder pull As in what size breaker do I need in by breaker box?

    1 answer

    1. It is recommended to use a 20 amp dedicated circuit.

      Helpful?
