GPI 15 GPM 12V Fuel Transfer Pump

Item# 109331
GPI 15 GPM 12V Fuel Transfer Pump
GPI 15 GPM 12V Fuel Transfer Pump

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

GPI 15 GPM 12V Fuel Transfer Pump

Click or Tap image to Zoom

$429.99

  • Shipping:

    Free shipping (lower 48 states) - Available now

  • Store Pickup:

    Not Available
  • Designed for permanent mounting on vented storage tanks
  • Includes manual unleaded nozzle, 3/4in. x 10ft. hose, 18ft. 12/2 AWG power cord and two-piece adjustable suction pipe (15in. to 40in)
  • For use with gasoline (up to 15% alcohol blends such as E15), diesel fuel (up to 20% bio-diesel blends such as B20) and kerosene
  • Low profile design
  • Received a Gold Medal Performance award for delivering 3 times more operating hours than comparable pumps

See full description

Complete Your Solution

  • GPI 15 GPM 12V Fuel Transfer Pump
  • Roughneck Mechanical Fuel Meter, 4–20 GPM, 3/4in. Inlet/Outlet
Price for all two:

$569.98

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This GPI® 12 Volt Fuel Transfer Pump features a rotary gear design and is made from durable and light weight cast aluminum. The 12-volt DC motor delivers flow rates up to 15 GPM. The fuel transfer pump provides longer run times and award-winning performance year after year. Ideal for use in agricultural, automotive and construction applications with low viscosity petroleum fuels. Motor is cULus listed.

What's Included

    (1) Fuel transfer pump model# M-150S-EM with nozzle cover (1) 3/4in. manual unleaded nozzle (1) Fuel hose (1) Adjustable suction pipe (1) Power cord (1) Strain relief connector (1) 30 amp fuse (1) Hardware kit

Downloads

Product Manual

Features + Benefits

  • Designed for permanent mounting on vented storage tanks
  • Includes manual unleaded nozzle, 3/4in. x 10ft. hose, 18ft. 12/2 AWG power cord and two-piece adjustable suction pipe (15in. to 40in)
  • For use with gasoline (up to 15% alcohol blends such as E15), diesel fuel (up to 20% bio-diesel blends such as B20) and kerosene
  • Low profile design
  • Received a Gold Medal Performance award for delivering 3 times more operating hours than comparable pumps
  • Longer pump life offers greater value for the dollar
  • Direct mount connection
  • Circuit breaker motor protection extends motor life
  • Aluminum body provides corrosion and tarnish resistance
  • Pre-installed power cord greatly reduces installation time
  • Lockable nozzle cover protects your investment and deters theft
  • Combine this M-150S-EM pump with GPI Model 01A31GM digital flow fuel meter (Item# 10930) or Model FM-200-G6N mechanical fuel meter (both sold separately) to create your own fueling system

Key Specs

AttributeSpecification

item#

109331

Brand

GPI

Manufacturer's Warranty

Lifetime Limited Warranty

Ship Weight

25.0 LB

GPM

15

Nozzle Type

Manual

Max. Suction Lift

5.5 ft

Max. Total Head

25 ft

Amps

18

Watts

216

Inlet Port

1 in

Outlet Port

1/2 in

Inlet Port (in.)

1
AttributeSpecification

Discharge

19.5 ft

Self-Priming

Yes

Hose Length

10 ft

Outlet Port (in.)

3/4

Speed

1,900 rpm

Discharge (ft.)

19.5

Duty Cycle

30 min

Bypass Valve

Yes

Hose (in. x ft.)

3/4 x 10

Horsepower

0.2 HP

Product Weight

23.2500 lb

Dimensions L x W x H (in.)

19.0 x 16.0 x 9.0 in

Speed (RPM)

1,900

Reviews

Questions & Answers

16 Reviews This action will navigate to reviews.

Questions

1–10 of 13 Questions
Sort by:

  1. what is suction pipe made of?

    1. it is made of plastic and is extendable.

      Helpful?

    2. The suction pipe included with this pump is made of plastic and can be trimmed if necessary.

      Helpful?

  2. When not in use does the pump automatically seal the drum to keep air from entering and evaporating the fuel?

    1 answer

    1. The pump is not sealed to keep air out completely and you would also be getting air in from the vented fuel cap. You would get some evaporation.

      Helpful?

  3. How long is the wiring harness

    1 answer

    1. The cord is 18 feet long.

      Helpful?

  4. I already have 20 feet of hose and nozzle. Can I buy this without the hose and nozzle?

    1 answer

    1. Northern Tool does not offer this fuel transfer pump separate from the hose and nozzle.

      Helpful?

  5. How many gallons per minute does this put out?

    1 answer

    1. This will produce up to 15 gallons per minute.

      Helpful?

  6. Will the nozzle fit a gasoline vehicle

    1 answer

    1. The nozzle will fit most gasoline vehicles.

      Helpful?

  7. increased discharge hose size

    This pump has a 3/4" discharge. my auto shut off, filter housing and hose are all 1". If I install a 3/4" x 1" adapter at the pump outlet, will I get any increase in flow as compared to using a 3/4" filter housing, hose, and shutoff?

    1 answer

    1. To use an adapter from 3/4" to 1" would not give you any increase in the flow. It will still put out the 15 GPM the pump is rated for.

      Helpful?

  8. What is the difference between the model (M-150S-EM) & Model# M150S-MU?

    What is the difference between the model (M-150S-EM - item# 109331) & Model# M150S-MU (item# 360566)?

    1 answer

    1. The M-150S-EM model has a direct mount 2" NPT fitting and a 10' dispensing hose, while the M150S-MU model has a spin collar 2" NPT fitting and a 12' dispensing hose.

      Helpful?

  9. Can this unit be installed without turning the pump?

    My tank has a step down where the pump is mounted. you would not be able to spin the pump to screw it in.

    1 answer

    1. This item would need to be twisted in to be locked into place to be secure.

      Helpful?

  10. What size fuse will be required for installation?

    1 answer

    1. The item comes with a 25 amp fuse.

      Helpful?
