SunStar Heating Products Infrared Ceramic Heater - 104,000 BTU, Propane, Aluminized Steel, Model# SGM10-L1

Item# 16285
SunStar Heating Products Infrared Ceramic Heater - 104,000 BTU, Propane, Aluminized Steel, Model# SGM10-L1

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

SunStar Heating Products Infrared Ceramic Heater - 104,000 BTU, Propane, Aluminized Steel, Model# SGM10-L1

Click or Tap image to Zoom

$929.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Constructed from aluminized steel for corrosion resistance and long life
  • Aluminum reflectors are designed to maximize radiant output
  • Heaters can be angled mounted horizontal and up to 45 degrees
  • The minimum mounting height is 15ft. above finished floor for uniform energy distribution and human comfort
  • Requires the following clearances from any combustible material: 36in. above, 96in. below and 45in. from the sides of the heater

See full description

Complete Your Solution

  • SunStar Heating Products Infrared Ceramic Heater - 104,000 BTU, Propane, Aluminized Steel, Model# SGM10-L1
  • SunStar Heating Products 750 Millivolt Thermostat for SGM Series Infrared Ceramic Heaters, Model# 42489010
  • SunStar Heating Products SIR Series Garage Heater Regulator, Above 2 PSIG, Model# 03483070
  • SunStar Heating Products SIR Series Garage Heater Regulator, Up To 2 PSIG, Model# 03307260
Price for all four:

$1124.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The SunStar Heating Products Ceramic Heater is ideal for spot heating or area heating of remote locations, farm buildings, shops, service areas, pump houses or other hard-to-heat spaces, providing both fuel efficiency of radiant heat and installation flexibility (not recommended for car washes). This is a Millivolt Standing Pilot heater and does not require an external power or electricity to operate, so it's great for use during power outages. Requires Millivolt thermostat for SGM (sold separately). May require the following second stage regulators prior to the heater based on gas supply pressure: A regulator up to 2 PSIG line pressure or a regulator above 2 PSIG line pressure (both sold separately). NOT CERTIFIED OR APPROVED FOR RESIDENTIAL USE. Indoor use only. U.S.A.

NOTE: Please review the detailed Installation Operating Instructions (attached) for other specific installation requirements (gas pressure, ventilation etc) prior to purchasing the heater.

What's Included

    (1) Infrared ceramic heater

Downloads

Product Manual

Features + Benefits

  • Constructed from aluminized steel for corrosion resistance and long life
  • Aluminum reflectors are designed to maximize radiant output
  • Heaters can be angled mounted horizontal and up to 45 degrees
  • The minimum mounting height is 15ft. above finished floor for uniform energy distribution and human comfort
  • Requires the following clearances from any combustible material: 36in. above, 96in. below and 45in. from the sides of the heater
  • The minimum supply gas pressure is 11.0in. Water Column (WC) and the maximum supply pressure is 14in. WC gas pressure
  • If higher gas pressure is supplied, you will need to install a line pressure regulator (sold separately) to reduce it to less than 14in. WC (or 1/2 PSIG)
  • Supply pressure of 11in. WC is critical and supply pressure less than 11in. WC can affect the operation of the pilot/heater
  • The standing pilot flame can be affected in windy/drafted areas and not recommended in these environments
  • No assembly required
  • Heaters are 100% test-fired prior to shipment
  • CSA design certified

Key Specs

AttributeSpecification

item#

16285

Brand

SunStar

Manufacturer's Warranty

1 year limited warranty

Ship Weight

10.0 LB

Heat Output

104,000 Btu/hour

Heat Type

Infrared
AttributeSpecification

Heating Capability

2,000 ft²

Needs Direct Venting

Yes

Blower Included

No

Thermostat Included

No

Oxygen Depletion Sensor

No

Reviews

Questions & Answers

Questions

1–2 of 2 Questions
Sort by:

  1. What are the measurements?

    1 answer

    1. The measurements for this heater are 61" L x 22" W x 12" H.

      Helpful?

  2. Propane Burn

    what is the hourly usage of propane for this unit?

    1 answer

    1. This heater has a fuel consumption of 1.1 gallon per hour when being used continuously.
