Katool 2-Post Vehicle Lift, 11,000-Lb. Capacity, 3 HP, Model# KT-M110

Item# 6349414
"Katool 2-Post Vehicle Lift, 11,000-Lb. Capacity, 3 HP, Model# KT-M110"
Top Seller
Katool 2-Post Vehicle Lift, 11,000-Lb. Capacity, 3 HP, Model# KT-M110

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Katool 2-Post Vehicle Lift, 11,000-Lb. Capacity, 3 HP, Model# KT-M110

Click or Tap image to Zoom

$2799.00

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

  • Store Pickup:

  • CE Approved and Certified. It has adopted the 115% dynamic loading capacity standard and was 150% static loading capacity tested.
  • Symmetric clear-floor design.
  • Manual safety release from two sides.
  • Symmetric arm.
  • Dual Hydraulic Chain-Drive Cylinders.

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Introducing the KT-M110 Two Post Clear-floor Vehicle Lift, a pinnacle of automotive lifting technology. With symmetrical lifting arms and a robust 11,000lbs capacity, it ensures a secure and balanced lift for a diverse range of vehicles. The bilateral unlocking mechanism guarantees synchronized control, prioritizing safety during operation. Ideal for professional garages and serious DIY enthusiasts, the KT-M110 excels in scenarios like routine maintenance, repairs, and inspections. Its clear-floor design provides unobstructed access underneath the vehicle, making it a versatile solution for a myriad of automotive tasks. Elevate your workspace and efficiency with the precision and power of the KT-M110 Two Post Clear-floor Vehicle Lift. Requires a forklift onsite for unloading. This item is delivered Monday-Friday with same day or 24 hours advance contact. A forklift is required to offload the lift from a box truck or a dock-height flatbed trailer.

What's Included

    (8) Anchor Bolts (1) Hydraulic Pump
Play Item Video

Features + Benefits

  • CE Approved and Certified. It has adopted the 115% dynamic loading capacity standard and was 150% static loading capacity tested.
  • Symmetric clear-floor design.
  • Manual safety release from two sides.
  • Symmetric arm.
  • Dual Hydraulic Chain-Drive Cylinders.
  • Rubber pad door opening protection.
  • Added overhead safety shutoff bar.
  • A forklift is required to offload the lift from a box truck or a dock-height flatbed trailer.

Key Specs

AttributeSpecification

item#

6349414

Brand

KATOOL

Manufacturer's Warranty

3 year limited warranty

Ship Weight

1400.0 LB

Capacity

11,000 lb

Max. Rise

6 ft
AttributeSpecification

Horsepower

3 HP

Motor Phase

Single-phase

Volts

220

Locking Position (qty.)

20

Product Weight

1256.0000 lb

Dimensions L x W x H (in.)

18.0 x 134.65 x 110.24 in

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

1–8 of 8 Questions
Sort by:

  1. What are recommended placement measurements for the 2 posts.  For example; Minimum/Recommended distance to garage door. Minimum/Recommended distance to side wall. Any other dimensions would be appreciated, Thanks  Thank you…take care..

    1 answer

    1. The minimum distance form the garage door would be 10-12 inches. The clearance from side walls would be approximately 12-24 inches. You would need to allow walk through space all around it. The unit has an overall width of 145.25 inches. Your bay must be wide enough to accommodate this plus clearance on both sides for safe operation. The concrete must be at least 5.9 inches thick and have a 3000 PSI rating.

      Helpful?

  2. I see that it uses 240 volts, I need to know how many amps it needs.

    1 answer

    1. This item must be connected to a 30-amp circuit.

      Helpful?

  3. Does it lock on both sides with just one release

    1 answer

    1. This vehicle lift has a dual-point safety lock release. The locks must manually release from both columns of the lift to lower the vehicle.

      Helpful?

  4. Is the motor rated 208-240. If not can I get it configured that way?

    1 answer

    1. The Katool KT‑M110 comes standard with a 220 VAC, 60 Hz, single‑phase motor, which falls within the 208–240 V range.

      Helpful?

  5. What is the height to the shut-off bar?

    1 answer

    1. The height from the floor to the bar will be 134.75". The maximum lifting height is 70.75".

      Helpful?

  6. Can the lift be mounted outside or is an enclosure required

    1 answer

    1. The lift is not designed for outdoor installation, it can only be installed indoors.

      Helpful?

  7. Need to know about the anker bolts.. like hole depth, width of hole needed.

    1 answer

    1. The drill bit to be used should be 3/4 inch, and the anchor bolt is 6.3 inches long. The hole should be at least 5.9 inches deep.

      Helpful?

  8. Thickness of floor for lift to set on?

    1 answer

    1. The minimum concrete thickness required to mount this lift to would be 5.9 inches.

      Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty

Compare with Most Popular in Two-Post Lifts

See All Two-Post Lifts

See All KATOOL Two-Post Lifts

Specifications

Specifications
Katool 2-Post Vehicle Lift, 11,000-Lb. Capacity, 3 HP, Model# KT-M110
BendPak 2-Post Car Lift, 10,000-Lb. Capacity, Model# 10AP
BendPak 2-Post Truck and Car Lift, 10,000 Lb. Capacity, Model# 10APX
BendPak, Two Post Parking Lift 6000lb Capacity, Capacity 6000 lb, Max. Rise 6.8 ft, Horsepower 4 HP, Model# PL-6000DCX
Capacity
Same

11,000 lb

10,000 lb

10,000 lb

6,000 lb

Max. Rise
Same

6 ft

6 ft

6.5 ft

6.8 ft

Horsepower
Same

3 HP

3 HP

3 HP

4 HP

Motor Phase
Same

Single-phase

Single-phase

Single-phase

Single-phase

Volts
Same

220

220

220

220

Locking Position (qty.)
Same

20

14

15

10

Product Weight
Same

1256.0000 lb

1710.0000 lb

1766.0000 lb

2288.0000 lb

Dimensions L x W x H (in.)
Same

18.0 x 134.65 x 110.24 in

145.0 x 20.0 x 145.0 in

145.0 x 20.0 x 157.0 in

163.5 x 112.0 x 131.0 in

Lock Spacing
Same

-

3.75 in

4 in

-

Time of Full Rise
Same

-

45 sec.

45 sec.

50 sec.

Pad Height
Same

-

4 in

4 in

-

Drive-Thru Clearance
Same

-

102 in

102 in

-

Material
Same

-

Steel

Steel

Steel
