HeatStar Dual Fuel Low-Intensity Radiant Tube Heater, 100,000 BTU, Natural Gas or Propane, Model# ERXL100N

Item# 66560
Top Seller
HeatStar Dual Fuel Low-Intensity Radiant Tube Heater, 100,000 BTU, Natural Gas or Propane, Model# ERXL100N

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

HeatStar Dual Fuel Low-Intensity Radiant Tube Heater, 100,000 BTU, Natural Gas or Propane, Model# ERXL100N

Click or Tap image to Zoom

$939.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Direct line-of-sight radiant heat to floor-level objects
  • Heats surrounding air to desired temperature
  • Dual fuel capability -- burner box comes set up for natural gas and includes a propane conversion kit
  • Sealed burner control box with underside burner sight glass
  • Works with 30ft. tube set, Item# 66570, and 40ft. tube set, Item# 66571, both sold separately

See full description

Complete Your Solution

  • HeatStar Dual Fuel Low-Intensity Radiant Tube Heater, 100,000 BTU, Natural Gas or Propane, Model# ERXL100N
  • HeatStar Tube Set, 40ft.L, Model# F106406XL
  • Mr. Heater Universal Gas Connection Kit, Model# F271239
  • Worthington Cylinders Propane Tank, 100 Lbs., Model# 303953
Price for all four:

$2472.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This HeatStar Dual Fuel Low-Intensity Radiant Tube Heater delivers direct line-of-sight radiant heat to floor-level objects. Heats surrounding air to desired temperature. Plus, this heater features dual fuel capability. The burner box comes set up for natural gas and includes a propane conversion kit.

What's Included

    (1) Low-intensity radiant tube heater

Downloads

Product Manual

Features + Benefits

  • Direct line-of-sight radiant heat to floor-level objects
  • Heats surrounding air to desired temperature
  • Dual fuel capability -- burner box comes set up for natural gas and includes a propane conversion kit
  • Sealed burner control box with underside burner sight glass
  • Works with 30ft. tube set, Item# 66570, and 40ft. tube set, Item# 66571, both sold separately

Key Specs

AttributeSpecification

item#

66560

Brand

HeatStar

Manufacturer's Warranty

10 year limited warranty

Ship Weight

37.5 LB

Heat Output

100,000 Btu/hour

Heat Type

Radiant
AttributeSpecification

Blower Included

No

Thermostat Included

No

Oxygen Depletion Sensor

No

Product Weight

33.9000 lb

Dimensions L x W x H (in.)

24.0 x 13.5 x 9.5 in

Reviews

Questions & Answers

Questions

1–4 of 4 Questions
Sort by:

  1. is the burner box made of stainless steel ? what is the efficiency rating ? does 10 year warranty cover the burner box ?

    1 answer

    1. The burner box is not made of stainless steel. It would be made of sheet metal that is coated. The efficiency rating is 83-86%. The 10 year warranty would cover the burner box, as long as it is not installed in an area where there would be moisture.

      Helpful?

  2. Is it suitable for indoors

    1 answer

    1. This heater is designed for use in areas such as a garage or a shop.

      Helpful?

  3. How much square footage does this cover

    1 answer

    1. On average, a 100,000 BTU heater can heat up to 2,500 square feet; however, there are a number of factors which can influence how effectively it heats. Please see the BTU calculation below:

      1. How large is the area being heated in cubic feet? Calculate area dimensions (Length x Width x Height) = Total Cubic Feet

      2. What is the desired temperature increase to be gained by the heater? Calculate (Desired temperature(with Heater) - Area temperature(without heater)) = Desired Temperature Increase

      3. Calculate the BTU's required to achieve desired temperature. Calculate ((Total Cubic Feet x .133) x Desired Temperature Increase) = BTU's Required

      Helpful?

  4. Do I need electricity? Does it have a thermostat?

    1 answer

    1. This does require 120 volt AC power. A thermostat is not included. This heater can use either a line voltage thermostat or a 24 volt thermostat.

      Helpful?
