The shaft rotation is counter clockwise.
DuroMax, 23Hp Electric Start Portable Engine, Engine Displacement 713 cc, Engine Type Gasoline Engines, Shaft Diameter 1 in, Model# XP23HPE
This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.
Click or Tap image to Zoom
$1119.99
- 713cc 4 Stroke OHV engine
- Runs on Standard 87 Octane Gasoline
- Electric Start Key Switch Box
- Air Cleaner: Dual, Semi-dry, Oil Bath
- EPA and CARB Approved for Safe Mandated Use
Prop 65 Warning: See Details
See full description
See All Horizontal Engines
See All DuroMax Horizontal Engines
Currently Viewing This Product
Specifications
Specifications
DuroMax, 23Hp Electric Start Portable Engine, Engine Displacement 713 cc, Engine Type Gasoline Engines, Shaft Diameter 1 in, Model# XP23HPE
Honda Engines, V-TWIN HORIZONTAL 630CC RQXA, Engine Displacement 688 cc, Engine Type GX Series OHV V-twin Commercial-duty, Shaft Diameter 1 in, Model# GX630RHXQXA
Honda Engines GX Series 688cc Horizontal OHV V-Twin Engine, Model# GX630RHXQZE
Honda Engines, HONDA V-TWIN HORIZ GX690RHXTAF, Engine Displacement 688 cc, Engine Type GX Series OHV V-twin, Shaft Diameter 1-1/8 in, Model# GX690RHXTAF
Engine Displacement
Same
713 cc
688 cc
688 cc
688 cc
Engine Type
Same
Gasoline Engines
GX Series OHV V-twin Commercial-duty
GX Series OHV V-twin Commercial-duty
GX Series OHV V-twin
Shaft Diameter
Same
1 in
1 in
1 in
1-1/8 in
Fuel Type
Same
Gasoline
-
-
-
Start Type
Same
Electric
Electric
Electric
Electric
Shaft Keyway
Same
.25inch in
0.25 in
0.25 in
0.25 in
Product Weight
Same
103.0000 lb
-
-
-
Dimensions L x W x H (in.)
Same
19.3 x 18.3 x 14.0 in
-
-
-
Shaft Length
Same
-
2.9 in
2.9 in
3.5 in
Net Torque
Same
-
35.6 ft-lbs.
35.6 ft-lbs.
35.6 ft-lbs.
Crankshaft
Same
-
Q-type
Q-type
T-type
PTO Height
Same
-
5.25 in
5.25 in
-
Cylinders (qty.)
Same
-
2
2
2
Cylinder Bore
Same
-
Integrated
Integrated
Integrated
Net Power Output
Same
-
20.8 HP
20.8 HP
22.1 HP
Compression Ratio
Same
-
9.3:1
9.3:1
9.3:1
Fuel Tank
Same
-
No
No
No
Oil Capacity
Same
-
2 qt
2 qt
2 qt
Low Oil Alert
Same
-
Yes
Yes
Yes
Shaft Rotation (From PTO Shaft Side)
Same
-
Counter Clockwise
Counter Clockwise
Counter Clockwise
Governor System
Same
-
Mechanical
Mechanical
Mechanical
Ignition System
Same
-
Electonic, Digital CDI W/variable Ignition Timing
Electonic, Digital CDI W/variable Ignition Timing
Electrical, Digital CDI W/variable Ignition Timing
Carburetor
Same
-
2-barrel, Fuel Cut Solenoid, Inner Vent
2-barrel, Fuel Cut Solenoid, Inner Vent
(2) Barrel, Fuel Cut Solenoid, Inner Vent
Lubrication System
Same
-
Full Pressure
Full Pressure
Full Pressure
Cooling System
Same
-
Air
Air
Air
Bore
Same
-
3.1 in
3.1 in
3.1 in
Stroke
Same
-
2.8 in
2.8 in
2.8 in
Air Cleaner Type
Same
-
Dual Element
Dual Element
Dual Element
Choke Control
Same
-
Remote
Manual
Manual
Throttle Control
Same
-
Remote
Manual
Manual
Charging System Amps
Same
-
3
2.7
20
Muffler Included
Same
-
No
No
No
Low Oil Shutdown
Same
-
-
-
No
Bearing Type
Same
-
-
-
Ball
