Concentric 12 Volt DC Power Unit, Solenoid Operation, Single Acting, Model# 1261096

Item# 10721
On Sale
Concentric 12 Volt DC Power Unit, Solenoid Operation, Single Acting, Model# 1261096

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Concentric 12 Volt DC Power Unit, Solenoid Operation, Single Acting, Model# 1261096

Click or Tap image to Zoom

$274.99
Reg $549.99Save $275.00

Order today to get this price.

  • Shipping:

    Free shipping (lower 48 states) - Available now

  • Store Pickup:

    Out of stock at Fredericksburg VA

  • Operation: Solenoid w/Remote Cord Set

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Concentric 12V DC power unit with solenoid operation is used in applications where control valves are mounted externally away from power units. Flow and pressure to manifolds allow usage in many applications. Return port for returning oil back to tank. Check and relief valve. 9/16in.-18 SAE ports. Items 1076 and 1077 are for double acting cylinders; others are for single acting cylinders.

Downloads

Product Manual
Play Item Video

Features + Benefits

  • Operation: Solenoid w/Remote Cord Set

Key Specs

AttributeSpecification

item#

10721

Brand

Haldex

Manufacturer's Warranty

1 year limited warranty

Ship Weight

36.0 LB

Max. Flow Rate

1.4 GPM

Max. PSI

2,500

Max. RPM

1,750

Power Source

Electric
AttributeSpecification

Port Inlet Size

9/16 in

Port Outlet Size

9/16 in

Thread Type

SAE

Reservoir Capacity

2.5 Gal

Volts

12

Phase

DC

Action

Single Acting

Reviews

Questions & Answers

10 Reviews This action will navigate to reviews.

Questions

1–10 of 24 Questions
Sort by:

  1. How does this Haldex 1261096 unit bolt down ?

    Where are the ports for the hyd lines located?

    1. There are two bolt holes on the bottom between the pump and the tank has two tabs at the back side.

      Exit port is on the side which has a special thread.

      Helpful?

    2. The unit has feet that will bolt down. You can view a complete diagram of the the ports on our website at
      http://www.northerntool.com/downloads/manuals/10721.pdf.

      Helpful?

  2. Will this allow the dump box to gravity down?

    1 answer

    1. The power unit is for single acting cylinders. This will be specifically designed for power up/gravity down applications.

      Helpful?

  3. is there a pressure relief valve (to limit the pressure for constant operation) or somewhere to add a custom one? Additionally, if the pressure relief valve exists is it adjustable and over what range?

    1 answer

    1. The power unit would have a internal pressure relief valve, set at around2500 PSI, to protect the system, allowing for continuous operation by preventing over pressurization. The pressure relief valve would be adjustable. The range would be about 1000 to 2500 PSI.

      Helpful?

  4. How to install hydraulic lines

    1 answer

    1. You would need to first install the appropriate fittings into the A and B or A1 and B1 for dual acting units, then connect the hydraulic hoses to the ports and the corresponding cylinder connections, ensuring the proper torque for the fittings.

      Helpful?

  5. How much weight can this pump unit lift?

    1 answer

    1. The pump will only produce oil flow/pressure. Lift capacity is determined by the cylinder or the device powering the power unit.

      Helpful?

  6. How do you manually release the pressure. . it goes up but not down

    1 answer

    1. You would need to energize the solenoid coil with 12 volts on the spade connectors below to open the valve to release the pressure.

      Helpful?

  7. What amp fuse is required for protection?

    1 answer

    1. This unit is not capable of running continuously so a fuse would not protect the unit if it is operating for an extended period of time. The maximum rated current for this unit is 250 amps.

      Helpful?

  8. WHAT ARE THE DIMENSIONS

    1 answer

    1. The overall dimensions are 20.34'' long, 8'' wide, and 7.78'' high.

      Helpful?

  9. Need remote only For the model 1261096

    1 answer

    1. The part number for the replacement remote is JB2380261. You would contact the parts department at 1.800.657.0516 to order parts.

      Helpful?

  10. which plugged port returns directly to tank?

    the two return ports ("return" and "aux return") are plugged, and the hydraulic schematic shows one returning directly to tank and one returning to the outlet line, thus to tank via the solenoid valve. I need to know which one returns directly to tank.

    1 answer

    1. The aux return is the one that returns directly to the tank.

      Helpful?
