Canarm Exhaust Shutter Fan, 24in., 3,800/4,700 CFM, 1/2 HP, Model# XFS24

Item# 44781
"Canarm Exhaust Shutter Fan, 24in., 3,800/4,700 CFM, 1/2 HP, Model# XFS24"
Canarm Exhaust Shutter Fan, 24in., 3,800/4,700 CFM, 1/2 HP, Model# XFS24

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Canarm Exhaust Shutter Fan, 24in., 3,800/4,700 CFM, 1/2 HP, Model# XFS24

Click or Tap image to Zoom

$489.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • 24in. diameter fan
  • Two-speed high-efficiency outside rotor 1/2 HP motor
  • Totally enclosed with sealed ball bearings
  • 115V, 4.3/5.0 Amps
  • Two speeds: 1,070/1,140 RPM

See full description

Complete Your Solution

  • Canarm Exhaust Shutter Fan, 24in., 3,800/4,700 CFM, 1/2 HP, Model# XFS24
  • 3M Paint and Pesticide Respirator - N95, NIOSH Approved, Model# 65021HA1A
  • 3M Professional-Grade Over-the-Head Hearing Protector, NRR 30dB, Model# 90565-4DC-PS
  • Tjernlund Duct Booster Fan, 10in., 475 CFM, Model# EF-10
Price for all four:

$804.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

Powerful Canarm direct drive exhaust fan is ideal for light commercial applications. Direct-drive fan features a Euro design outside rotor motor for high efficiency, with totally enclosed with sealed ball bearings. Provides smooth, quiet and reliable maintenance-free operation. Fan has swept back, high-efficiency, low-noise blade design. Quiet aluminum shutters with tie bar are designed to maximize airflow. ETL certified. Oversize shipping charge applies.

What's Included

    (1) 24in. exhaust shutter fan

Downloads

Product Manual Product Manual2
Play Item Video

Features + Benefits

  • 24in. diameter fan
  • Two-speed high-efficiency outside rotor 1/2 HP motor
  • Totally enclosed with sealed ball bearings
  • 115V, 4.3/5.0 Amps
  • Two speeds: 1,070/1,140 RPM
  • Swept back, high-efficiency, low-noise blades
  • Air delivery: 3,800/4,700 CFM
  • Quiet aluminum shutters with tie bar for maximum airflow
  • 72dB high-speed sound level
  • Strong powder-coated OSHA guarding inside
  • Pull chain speed control
  • ETL certified
  • Durable steel construction with powder-coat black finish
  • 9ft. power cord with 115V 3-prong plug
  • Ships fully assembled
  • Overall size: 28 25/32in.W x 11 1/8in.D x 28 25/32in.H

Key Specs

AttributeSpecification

item#

44781

Brand

Canarm

Manufacturer's Warranty

1 year limited warranty

Ship Weight

46.0 LB

Drive Type

Direct

Fan Diameter

24 in
AttributeSpecification

Air Delivery

4,700 cfm

Volts

115

Speeds (qty.)

2

Max. Fan Speed

1,140 rpm

Horsepower

0.5 HP

Reviews

Questions & Answers

12 Reviews This action will navigate to reviews.

Questions

1–10 of 11 Questions
Sort by:

  1. Can you buy a replacement motor?

    1 answer

    1. It is best to contact the manufacturer directly for replacement parts for this Canarm Exhaust Shutter Fan - Model #XFS24.

      Helpful?

  2. How load is this fan?

    1 answer

    1. This exhaust shutter fan is rated at 72 DB (decibels).

      Helpful?

  3. I need 5 of these fans, but my rough opening is 25-1/4" x 25-1/4". What are the exact dimensions of the fan box? I would like to know if I can still fit it into this rough opening size.

    1 answer

    1. The rough cut-in for this fan is 26" x 26".

      Helpful?

  4. Can this work on a greenhouse? is it water proof?

    1 answer

    1. It is not recommended to be used in a green house application. The exhaust fan is not waterproof.

      Helpful?

  5. I am looking for the insertion depth. Will this work in an 8" block wall?

    1 answer

    1. This fan has a depth of 6-1/8" from the mounting face to the edge of the fan motor. The overall depth is 11-1/8".

      Helpful?

  6. Can a rotary timer switch be utilized

    1 answer

    1. A rotary timer switch cannot be used with this fan.

      Helpful?

  7. What would be the rough opening size for this ?

    1 answer

    1. The rough opening height is 26'' and 26'' wide.

      Helpful?

  8. Is this fan explosion proof?

    Would like to install in a 24' x 26' insulated shop where I paint small parts.

    1 answer

    1. This shutter fan would not be an explosion proof fan. See item #13770 and 14773 for a 24 inch explosion proof fan.

      Helpful?

  9. Can a thermostat be installed on this exhaust fan

    1 answer

    1. This exhaust fan cannot be run from a thermostat. It is not designed to be hardwired and has a pull chain for ON/OFF and speed control.

      Helpful?

  10. How do the tie bars for the shutters work?

    1 answer

    1. The shutters on this fan are attached to a tie bar so that they function together not independently. As air flow is reduced, they close by gravity.

      Helpful?
