Tow Tuff, Universal Heavy-Duty spare tire carrier, Material Steel, Model# TTF-08HD

Item# 5104597
Tow Tuff, Universal Heavy-Duty spare tire carrier, Material Steel, Model# TTF-08HD

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Tow Tuff, Universal Heavy-Duty spare tire carrier, Material Steel, Model# TTF-08HD

Click or Tap image to Zoom

$82.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Attaches to the frame of your trailer
  • Capacity of 120 lbs. - capable of holding a wide variety of spare tires
  • Fits tires 13” and larger with bolt hold patterns from 4 holes to 8 holes
  • Constructed of welded, heavy-duty steel with a powder-coat finish
  • Measures 24.25” x 6” x 7” overall; weighs 16 lbs.

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Tow Tuff brings you the TTF-08HD Heavy-Duty Universal Spare Tire Carrier - your solution for carrying a spare tire for your trailer. The Spare Tire Carrier is universal and attaches to the frame of your trailer. This Tow Tuff product is capable of holding a wide variety of spare tires with a weight capacity of 120 lbs. Tires 13” and larger with bolt hold patterns from 4 holes to 8 holes will fit easily onto this carrier, which gives you a versatile product. Constructed of welded, heavy-duty steel with a powder-coat finish, this tire carrier is durable and reliable. The overall weight of the carrier is 16 lbs. and measures 24.25” x 6” x 7”. Designed with a heavy-duty stiffener bar to handle heavy tires and rims. The mounting plate includes pre-drilled holes with matching hardware to make mounting easy. Installation is fast and easy with the bolt-on design and included zinc-plated mounting hardware, giving you more time to put your trailer to use. Optional TTF-ISCTC Ice Castle Bracket available (sold separately) for mounting your Spare Tire Carrier onto your Ice Castle.

What's Included

    (1) Heavy-Duty Universal Spare tire Carrier. TTF-08HD

Features + Benefits

  • Attaches to the frame of your trailer
  • Capacity of 120 lbs. - capable of holding a wide variety of spare tires
  • Fits tires 13” and larger with bolt hold patterns from 4 holes to 8 holes
  • Constructed of welded, heavy-duty steel with a powder-coat finish
  • Measures 24.25” x 6” x 7” overall; weighs 16 lbs.
  • Designed with a heavy-duty stiffener bar to handle heavy tires and rims
  • Mounting plate includes pre-drilled holes with matching hardware to make mounting easy
  • Installation is fast and easy with the bolt-on design and included zinc-plated mounting hardware, giving you more time to put your trailer to use
  • Optional TTF-ISCTC Ice Castle Bracket available (sold separately) for mounting your Spare Tire Carrier onto your Ice Castle
  • 1 year limited manufacturer’s parts warranty

Key Specs

AttributeSpecification

item#

5104597

Brand

Tow Tuff

Manufacturer's Warranty

1 year limited warranty

Ship Weight

18.0 LB

Material

Steel
AttributeSpecification

Adjustable

No

Mount Type

Trailer Tongue

Product Weight

18.0000 lb

Dimensions L x W x H (in.)

24.25 x 6.0 x 7.0 in

Reviews

Questions & Answers

Questions

1–3 of 3 Questions
Sort by:

  1. What is the vertical and horizontal offsets of this when mounted on a trailer?

    1 answer

    1. When mounting a 15” tire on a 3x5 trailer tongue - Horizontal, From the tongue to inside of the tire: 10-7/8 inches. Vertical, From the top of the tongue to the center of the 15 inch tire: 9-1/2 inches. Mount plate for tongue is 5.5 inches wide x 6.5 inches high. The Tire mount plate: 7 inches wide x 9.25 inches high. How the spare tire carrier is mounted and the tire size will make a difference as well.

      Helpful?

  2. What size of frames will this fit I have 6x2 tube frames

    1 answer

    1. This spare tire carrier will fit trailer tongues up to 3" wide x 5" high.

      Helpful?

  3. Does this adjust to fit a 5 on 5 bolt pattern

    1 answer

    1. This carrier will fit a 5 hole rim with a 5 inch bolt pattern.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
