Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 3 1/2in. Bore, 24in. Stroke, 1 1/2in. Shaft, Model# PMC-5524

Item# 905524
Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 3 1/2in. Bore, 24in. Stroke, 1 1/2in. Shaft, Model# PMC-5524

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 3 1/2in. Bore, 24in. Stroke, 1 1/2in. Shaft, Model# PMC-5524

Click or Tap image to Zoom

$519.99

  • Shipping:

    Available now

  • Store Pickup:

    Not Available

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

Universal end mountings. A favorite for contractors, industrial, and agricultural applications. All steel welded construction: weld-on cross tube. Heavy wall steel tubing, ground and polished chrome piston rod with pin eye, cast iron piston. O-rings and back up washers, trac-type gland retainer. Maximum working PSI is 2,500, bursting PSI is 5,000. 2 1/2in. bore cylinders have 3/4in. pin holes. The 3in. and 3 1/2in. bore cylinders have 1in. pin holes. The 4in. bore cylinders have 1 1/4in. pin holes. 2 1/2in. bore cylinders have 3/8in. working ports. The rest have 1/2in. working ports. Double acting. U.S.A.

Downloads

Product Manual

Key Specs

AttributeSpecification

item#

905524

Brand

Prince

Manufacturer's Warranty

3 year limited warranty

Ship Weight

44.0 LB

Max. PSI

2,500
AttributeSpecification

Bore Diameter

3.5 in

Stroke Length

24 in

Shaft Diameter

1.5 in

Closed Pin Center

32 in

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

  1. What is the width of the shaft end tee?

    Do you have a 24 inch stroke cylinder where the pin goes through the 1 1/2 inch shaft?

    1 answer

    1. The Prince Welded Tee Cylinder item #905524 has a 24 inch stroke cylinder with a 1 inch pin. The width of the shaft end tee is 1 1/2 inch.

      Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty

Extend Your Warranty Coverage with a Northern Protection Plan (NPP)

Repair Plan — 1 Year

A Northern Protection Plan is available after adding the product to your shopping cart.
