Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 3in. Bore, 20in. Stroke, 1 1/2in. Shaft, Model# PMC-8320

Item# 908320
Top Seller
Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 3in. Bore, 20in. Stroke, 1 1/2in. Shaft, Model# PMC-8320

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 3in. Bore, 20in. Stroke, 1 1/2in. Shaft, Model# PMC-8320

Click or Tap image to Zoom

$419.99

  • Shipping:

    Available now

  • Store Pickup:

    Not available - online only

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Universal end mountings. A favorite for contractors, industrial, and agricultural applications. All steel welded construction: weld-on cross tube. Heavy wall steel tubing, ground and polished chrome piston rod with pin eye, cast iron piston. O-rings and back up washers, trac-type gland retainer. Maximum working PSI is 2,500, bursting PSI is 5,000. 2 1/2in. bore cylinders have 3/4in. pin holes. The 3in. and 3 1/2in. bore cylinders have 1in. pin holes. The 4in. bore cylinders have 1 1/4in. pin holes. 2 1/2in. bore cylinders have 3/8in. working ports. The rest have 1/2in. working ports. Double acting. U.S.A.

Downloads

Product Manual

Key Specs

AttributeSpecification

item#

908320

Brand

Prince

Manufacturer's Warranty

3 year limited warranty

Ship Weight

33.1 LB

Max. PSI

2,500
AttributeSpecification

Bore Diameter

3 in

Stroke Length

20 in

Shaft Diameter

1.5 in

Closed Pin Center

28 in

Reviews

Questions & Answers

18 Reviews This action will navigate to reviews.

Questions

1–2 of 2 Questions
Sort by:

  1. the add says 20" stroke on cylinder it says 8"

    1 answer

    1. The model number PMC-8320 is an 3" bore with a 20" stroke. Retracted length is 28". The extended length is 48".

      Helpful?

  2. how wide is the welded end connection?

    The width of the welded end looks too wide to fit in the top link connection on my tractor. I need to know the width before I order please.

    1 answer

    1. One end of the cylinder is 3.5 inches wide and the other end is 1.5 inches wide.

      Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty
