Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 4in. Bore, 30in. Stroke, 2in. Shaft Size, Model# PMC-5630

Item# 905630
Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 4in. Bore, 30in. Stroke, 2in. Shaft Size, Model# PMC-5630

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 4in. Bore, 30in. Stroke, 2in. Shaft Size, Model# PMC-5630

Click or Tap image to Zoom

$669.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Double Acting Cylinder
  • Chromed, ground & polished piston rod
  • Ductile iron piston & gland
  • Crosstube end fittings with grease zerks
  • Urethane u-cup and urethane wiper in gland

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Universal end mountings. A favorite for contractors, industrial, and agricultural applications. All steel welded construction: weld-on cross tube. Heavy wall steel tubing, ground and polished chrome piston rod with pin eye, cast iron piston. O-rings and back up washers, trac-type gland retainer. Maximum working PSI is 2,500, bursting PSI is 5,000. 2 1/2in. bore cylinders have 3/4in. pin holes. The 3in. and 3 1/2in. bore cylinders have 1in. pin holes. The 4in. bore cylinders have 1 1/4in. pin holes. 2 1/2in. bore cylinders have 3/8in. working ports. The rest have 1/2in. working ports. Double acting. U.S.A.

What's Included

    (1) Welded tee cylinder

Downloads

Product Manual

Features + Benefits

  • Double Acting Cylinder
  • Chromed, ground & polished piston rod
  • Ductile iron piston & gland
  • Crosstube end fittings with grease zerks
  • Urethane u-cup and urethane wiper in gland
  • O-ring with backup washers & cast iron piston seals
  • Snap in gland retainer
  • Ports are 1/2" NPTF, extend and retract
  • 2500 PSI
  • Made in USA

Key Specs

AttributeSpecification

item#

905630

Brand

Prince

Manufacturer's Warranty

3 year limited warranty

Ship Weight

74.6 LB

Max. PSI

2,500
AttributeSpecification

Bore Diameter

4 in

Stroke Length

30 in

Shaft Diameter

2 in

Closed Pin Center

39 in

Reviews

Questions & Answers

Warranty

Manufacturer's Warranty

3 year limited warranty
