Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 2 1/2in. Bore, 12in. Stroke, 1 3/8in. Shank, Model# PMC-5412

Item# 905412
"Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 2 1/2in. Bore, 12in. Stroke, 1 3/8in. Shank, Model# PMC-5412"
Top Seller
Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 2 1/2in. Bore, 12in. Stroke, 1 3/8in. Shank, Model# PMC-5412

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 2 1/2in. Bore, 12in. Stroke, 1 3/8in. Shank, Model# PMC-5412

Click or Tap image to Zoom

$369.99

  • Shipping:

    Backordered: Order now to reserve yours -
    Estimated to ship 06/29/26

  • Store Pickup:

    Not available - online only

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Universal end mountings. A favorite for contractors, industrial, and agricultural applications. All steel welded construction: weld-on cross tube. Heavy wall steel tubing, ground and polished chrome piston rod with pin eye, cast iron piston. O-rings and back up washers, trac-type gland retainer. Maximum working PSI is 2,500, bursting PSI is 5,000. 2 1/2in. bore cylinders have 3/4in. pin holes. The 3in. and 3 1/2in. bore cylinders have 1in. pin holes. The 4in. bore cylinders have 1 1/4in. pin holes. 2 1/2in. bore cylinders have 3/8in. working ports. The rest have 1/2in. working ports. Double acting. U.S.A.

Downloads

Product Manual

Key Specs

AttributeSpecification

item#

905412

Brand

Prince

Manufacturer's Warranty

3 year limited warranty

Ship Weight

19.7 LB

Max. PSI

2,500
AttributeSpecification

Bore Diameter

2.5 in

Stroke Length

12 in

Shaft Diameter

1.375 in

Closed Pin Center

20 in

Reviews

Questions & Answers

2 Reviews This action will navigate to reviews.

Questions

  1. What is the overall length when collapsed and when fully extended ?

    1 answer

    1. The overall length when collapsed would be 20" from center pin to center pin. When extended it would be 32".

      Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty
