Powermatic Wood Planer 209 HH, 100 Knives, 4-Speed, 5 HP, 1 PH, 230 Volts

Item# 84657
Powermatic Wood Planer 209 HH, 100 Knives, 4-Speed, 5 HP, 1 PH, 230 Volts

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Powermatic Wood Planer 209 HH, 100 Knives, 4-Speed, 5 HP, 1 PH, 230 Volts

Click or Tap image to Zoom

$6268.99

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Helical cutterhead with 4-sided knife inserts provides smoother, quieter cutting and finer finish than conventional systems
  • 5 HP motor and 20in. planing capacity allow heavy-duty work
  • Fully enclosed base cabinet with integrated casters offers shop mobility
  • Cast iron table with extensions creates a big 55 1/2in. x 20in. working area
  • 4 feed speeds: 24 and 31 FPM, 16 and 20 FPM with gear change, provide versatility

  • Prop 65 Warning: See Details

See full description

Complete Your Solution

  • Powermatic Wood Planer 209 HH, 100 Knives, 4-Speed, 5 HP, 1 PH, 230 Volts
  • JET Dust Collector, 2 HP, 230 Volt, Model# DC-1200VX-BK1
  • 3M Professional-Grade Over-the-Head Hearing Protector, NRR 30dB, Model# 90565-4DC-PS
  • 3M SecureFit Safety Glasses, Clear Lens, Model# SF400C-LV-4-PS
Price for all four:

$7132.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Powermatic 209 HH Planer is a heavy-duty unit with standard features not found on other machines in its class. The powerful 5 HP motor and 20in. planing capacity will handle the most demanding work. The helical cutterhead provides quieter operation and finer finishing than conventional systems, and the 4-sided knife inserts seat themselves without requiring a setup gauge. The 5in. dust port connects easily to any dust collector. The anti-kickback fingers and pressure bar are located in close proximity to the cutterhead for an exceptional finish. The solid cast iron base, table and head are designed for production. The 2-speed oil bath gearbox transmits full power to feed rollers and facilitates fast speed changes at 24 and 31 FPM. The gearbox can be changed to 4-speed with the included gear to run lower speeds of 16 and 20 FPM. The corrugated infeed and fine groove outfeed rollers ensure a smooth feed. The precision-ground and polished cast iron table rides on 4 steel columns, giving it plenty of support for the larger workpiece. Heavy cast iron extension wings ensure a flat, smooth cut.

What's Included

    (1) Powermatic 209 HH Planer, 100 Knives, 4-Speed, 5 HP, 1 PH, 230

Downloads

Product Manual

Features + Benefits

  • Helical cutterhead with 4-sided knife inserts provides smoother, quieter cutting and finer finish than conventional systems
  • 5 HP motor and 20in. planing capacity allow heavy-duty work
  • Fully enclosed base cabinet with integrated casters offers shop mobility
  • Cast iron table with extensions creates a big 55 1/2in. x 20in. working area
  • 4 feed speeds: 24 and 31 FPM, 16 and 20 FPM with gear change, provide versatility
  • Feed rollers and cutterhead supported by full cast iron head assembly provide rigidity

Key Specs

AttributeSpecification

item#

84657

Brand

Powermatic

Manufacturer's Warranty

5 year limited warranty

Ship Weight

801.0 LB

Product Type

Planers

Max. Cutting Depth

0.094 in

Knives (qty.)

100
AttributeSpecification

Cutterhead Speed

5,000 rpm

Volts

230

Amps

40

Helical Head

Yes

Product Weight

801.0000 lb

Dimensions L x W x H (in.)

26.0 x 36.63 x 41.4 in

Reviews

Questions & Answers

2 Reviews This action will navigate to reviews.

Questions

  1. where is this machine made?

    1 answer

    1. The wood planer is made in Taiwan.
