Optima Scale Single Cattle Scale, 5000-Lb. Capacity, 1-Lb. Display Increment, Model# OP-929

Item# 71070
Optima Scale Single Cattle Scale, 5000-Lb. Capacity, 1-Lb. Display Increment, Model# OP-929

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Optima Scale Single Cattle Scale, 5000-Lb. Capacity, 1-Lb. Display Increment, Model# OP-929

Click or Tap image to Zoom

$1399.99

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

  • An ideal option when weighing one animal at a time
  • Works well installed in an alleyway or chute system
  • Can be used to buy and sell animals, track gain or loss and monitor animal health condition
  • An economical solution to weighing heavy animals accurately
  • Large platform to make complete livestock alleyway

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

This Optima Scale Single Cattle Scale is an ideal option when weighing one animal at a time. It works well to install in an alleyway or chute system. It can be used to buy and sell animals, track gain or loss and monitor animal health condition. It's also an economical solution to weighing heavy animals accurately. The large platform makes a complete livestock alleyway. The durable design is made to last. The automatic zero tracking function maintains the scale at zero. The hold function retains the displayed weight after the animal is removed, and the sleep mode helps save power. This full-featured scale includes thread plate surface motion sensing technology, built-in ramps and side rails, water-tight nickel plated load cells, 200% overload protection, NEMA 4 stainless steel junction box, and a 20ft. strong, metal shielded serial cable. Platform dimensions: 96in.L x 30in.W x 4in.H.

What's Included

    (1) Platform (1) Weighing indicator

Features + Benefits

  • An ideal option when weighing one animal at a time
  • Works well installed in an alleyway or chute system
  • Can be used to buy and sell animals, track gain or loss and monitor animal health condition
  • An economical solution to weighing heavy animals accurately
  • Large platform to make complete livestock alleyway
  • Durable design
  • Automatic zero tracking to maintain the scale at zero
  • Hold function to retain displayed weight after the animal is removed
  • Sleep mode to help save power
  • Thread plate surface motion sensing technology, built-in ramps and side rails
  • Water-tight nickel plated load cells
  • 200% overload protection
  • NEMA 4 stainless steel junction box
  • 20ft. strong, metal shielded serial cable
  • Platform dimensions: 96in.L x 30in.W x 4in.H.

Key Specs

AttributeSpecification

item#

71070

Brand

OptimaScale

Manufacturer's Warranty

1 year limited warranty

Ship Weight

350.0 LB

Capacity

5,000 lb

Capacity

5,000 lb

Platform Length

96 in

Platform Length

96 in

Platform Width

30 in

Platform Width

30 in

Style

Livestock Scale

Style

Livestock Scale

Display Type

LCD
AttributeSpecification

Display Type

LCD

Measures

lb, kg

Measures

lb, kg

Power Source

Battery

Power Source

Battery

Battery Included

Yes

Battery Included

Yes

Battery Type

Lead acid

Dimensions L x W x H (in.)

96 x 30 x 4 in

Product Weight

350.0000 lb

Dimensions L x W x H (in.)

96.0 x 30.0 x 4.0 in

Product Weight

350 lb

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

1–6 of 6 Questions
Sort by:

  1. can this scale be left in the ally or does it need to be put after when not being used

    1 answer

    1. The scale platform is sturdy enough to remain in the alley; however, the digital display and wiring need protection from rain and extreme weather. If the alley is not covered, it's advisable to either move the scale when it's not in use or cover it with a tarp to prevent damage. Keeping the electronics dry will help prolong the lifespan of the system and prevent warranty issues.

      Helpful?

  2. Battery operation?

    1 answer

    1. The Optima Scale model OP-929 will have AC/DC power with a built in rechargeable battery. The battery will last up to 100 hours per charge.

      Helpful?

  3. Can you get the 20-ft home run cable for these scales with quick connectors on both ends

    1 answer

    1. The home run cables for the OP-929 are 15' in length.

      Helpful?

  4. What is the dimension?

    1 answer

    1. This scale is 83"L x 30"W x 5"H.

      Helpful?

  5. The installation would be in an alleyway for cattle. How wide is this unit? Does it need to be installed on a concrete slab or will stall mats suffice? Thanks.

    1 answer

    1. The overall width of this unit is 30". The unit can be installed on any surface as long as each corner of the scale rests on a hard level surface,

      Helpful?

  6. Do you need any other parts to make this usable? Is it easily removed when not needed?

    1 answer

    1. No other items are needed to use. This can be removed and stored when not in use.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty

Extend Your Warranty Coverage with a Northern Protection Plan (NPP)

Repair Plan — 1 Year

A Northern Protection Plan is available after adding the product to your shopping cart.
