Optima Scale Load Link Dynamometer, 50,000-Lb. Capacity, 20-Lb. Display Increments, Model# OP-927-50K

Item# 71069
"Optima Scale Load Link Dynamometer, 50,000-Lb. Capacity, 20-Lb. Display Increments, Model# OP-927-50K"
Optima Scale Load Link Dynamometer, 50,000-Lb. Capacity, 20-Lb. Display Increments, Model# OP-927-50K

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Optima Scale Load Link Dynamometer, 50,000-Lb. Capacity, 20-Lb. Display Increments, Model# OP-927-50K

Click or Tap image to Zoom

$1249.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Designed to measure high-capacity loads for cranes, hoists and winches
  • Can be used with shackles to measure force, and for other types of lifting, weighing
  • Backlit LCD display shows both lb. and kg
  • Temperature compensated
  • Gross, tare, peak and hold functions

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

This Optima Scale Load Link Dynamometer is designed to measure high-capacity loads for cranes, hoists and winches. It is also used with shackles to measure force, and for many other types of lifting and weighing. The backlit LCD display shows both lb. and kg. This plated steel unit is temperature compensated and features gross, tare, peak and hold. The rechargeable battery allows continuous operation for 72 hours before recharging. The load cell cable length is 40ft.; load cell dimensions are 12 1/2in.H x 4 3/8in.W x 1 5/8in. thick; and the load cell hole size is 1 5/8in. outer diameter. This unit is a cost effective solution for processing, monitoring and controlling overhead loads. The lightweight and compact design allows easy operation, while the robust construction helps maintain a safe work environment. The peak hold feature allows for maximum sensitivity and accurate weighing without worrying about readings showing too quickly for the eye to see.

What's Included

    (1) Tension link load cell (1) Weight indicator

Features + Benefits

  • Designed to measure high-capacity loads for cranes, hoists and winches
  • Can be used with shackles to measure force, and for other types of lifting, weighing
  • Backlit LCD display shows both lb. and kg
  • Temperature compensated
  • Gross, tare, peak and hold functions
  • Rechargeable battery for 72 hours of operation before recharging
  • 40ft. load cell cable
  • 12 1/2in.H x 4 3/8in.W x 1 5/8in. thick load cell
  • 1 5/8in. outer diameter load cell hole
  • A cost effective solution for processing, monitoring and controlling overhead loads
  • Lightweight, compact design for easy operation
  • Robust construction to help maintain a safe work environment
  • Peak hold feature for maximum sensitivity and accurate weighing

Key Specs

AttributeSpecification

item#

71069

Brand

OptimaScale

Manufacturer's Warranty

1 year limited warranty

Ship Weight

40.0 LB

Capacity

50,000 lb

Capacity

50,000 lb

Platform Length

12.5 in

Platform Length

12.5 in

Platform Width

4.375 in

Platform Width

4.375 in

Style

Dynamometer

Style

Dynamometer
AttributeSpecification

Display Type

LCD

Display Type

LCD

Measures

lb, kg

Measures

lb, kg

Power Source

Battery

Power Source

Battery

Battery Included

Yes

Battery Included

Yes

Battery Type

Lead acid

Dimensions L x W x H (in.)

12.5 x 4.37 x 1.625 in

Product Weight

lb

Dimensions L x W x H (in.)

12.5 x 4.37 x 1.625 in

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

1–2 of 2 Questions
Sort by:

  1. Does this come with a certificate of calibration.

    1 answer

    1. The scale does not come with a certificate of calibration.

      Helpful?

  2. Can I get this scale with a 100 foot cord?

    1 answer

    1. Optima Scale does offer customization to include a 60' cable extension for a total of 100' cable but you would need to order directly through the manufacturer for custom orders.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
