The negative battery cable connects to the side of the DC motor. With the motor facing you, there is a 1/4-20 blind hole on the left side of the motor. Connecting the negative cable at this location helps ensure a proper ground connection and prevents grounding issues.
Free Gift Card Details
- The promo code 290264 must be entered on the Shopping Cart page.
- To qualify for this offer, your order subtotal must equal $100 or more. Excludes gift cards, free item offers, warranties, Advantage memberships, tax and shipping.
- Free gift cards will be issued in the form of e-gift cards only, not physical gift cards.
- E-gift cards will be sent to the email address used in your billing address when your order ships or is picked up.
- Free e-gift cards expire 04/01/27.
- Promo code not valid on prior purchases or on Honda and STIHL products and cannot be combined with other promotional offers.
- Valid online and in participating retail stores.
- Limited-time offer. Subject to change without notice.
NorTrac Dump Trailer Power Unit, 12V DC, 2.1-Gallon Tank, 2 HP Motor, 1.5 GPM Flow Rate

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Click or Tap image to Zoom
Shipping:
Free shipping (lower 48 states) - Available nowStore Pickup:
Not available - online only
- 2 HP, 12V DC motor operates double-acting cylinders
- Pressure-balanced pump ensures smooth hydraulic flow
- Electric pendant control allows simple hands-on operation
- 2.1-gallon tank supports extended run time
- 1.5 GPM flow rate enables quick cycle times
See full description
Description
Key Specs
Reviews
Q & A
Accessories
Warranty
Compare
Product Summary
What's Included
- (1) NorTrac Dump Trailer Power Unit
Features + Benefits
- 2 HP, 12V DC motor operates double-acting cylinders
- Pressure-balanced pump ensures smooth hydraulic flow
- Electric pendant control allows simple hands-on operation
- 2.1-gallon tank supports extended run time
- 1.5 GPM flow rate enables quick cycle times
- 2.1cc pump displacement delivers precise performance
- Ideal for dump trailers, truck lifts and tippers
Key Specs
| Attribute | Specification |
|---|---|
item# | 53461 |
Brand | NorTrac |
Manufacturer's Warranty | 1 year limited warranty |
Ship Weight | 33.4 LB |
Max. Flow Rate | 1.5 GPM |
Max. PSI | 3,190 |
Max. RPM | 3,000 |
| Attribute | Specification |
|---|---|
Power Source | Battery |
Port Outlet Size | 9/16 in |
Thread Type | SAE |
Reservoir Capacity | 2.1 Gal |
Volts | 12 |
Horsepower | 2 |
Action | Double Acting |
Reviews
Questions & Answers
Questions
-
· 18 days ago
Where goes the ground wire from the battery attach to the unit?
1 answer-
NorTracExpert12· 17 days ago
Helpful?
-
-
· a year ago
will this pump lift 5-8000 lbs of gravel on dump trailer?
1 answer-
NorTracExpert12· a year ago
The weight capacity will be dependent on the system this unit is used with. Please check the specifications of the system. This power unit can generate 3,000 maximum RPM and delivers a 1.5 GPM flow rate.
Helpful?
-
-
· 2 years ago
is there any way to speed up the pump
1 answer-
NorTracExpert12· 2 years ago
The motor is designed and tested to run at a maximum of 3,000 RPM. We do not recommend modifying the motor as it could become damaged and would void the warranty.
Helpful?
-
-
· 2 years ago
Can this model be mounted vertically?
1 answer-
NorTracExpert12· 2 years ago
This power unit is not configured to be mounted vertically.
Helpful?
-
-
· 2 years ago
is there a saftey that wont allow pump to work if there is no hydralic oil
1 answer-
NorTracExpert12· 2 years ago
This power unit is not equipped with any safety switches or floats to shut it down if the reservoir is empty. A float would have to be added by the user.
Helpful?
-
-
· 2 years ago
How many tons does it lift?
1 answer-
NorTracExpert12· 2 years ago
The lift capacity will be dependent on the hydraulic system of the dump trailer. Check the requirements of the system and/or consult a hydraulic specialist for the specific application.
Helpful?
-
-
· 2 years ago
Will this unit lift 18000 lbs in a 6 yard dump trailer
1 answer-
NorTracExpert12· 2 years ago
The lift capacity will be dependent on the hydraulic system of the dump trailer. Check the requirements of the system and/or consult a hydraulic specialist for the specific application.
Helpful?
-
-
· 2 years ago
What remote would go with a 6 pin hydraulic pumping
1 answer-
NorTracExpert12· 2 years ago
The replacement remote, part #DLH684.0008, is available through our sister company, Jacks Small Engines. Please visit www.JacksSmallEngines.com for pricing and availability.
Helpful?
-
-
· 3 years ago
does this have mounting holes or brackets of any kind
1 answer-
NorTracExpert12· 3 years ago
This unit does have two pre-drilled 3/8"-16 mounting holes. They are 3.25" apart on center.
Helpful?
-
-
· 3 years ago
3 cylinders ?
1 answer-
NorTracExpert12· 3 years ago
It is possible to use this power unit with 3 cylinders; however, it would be best to work with a hydraulic specialist to ensure it has a large enough reservoir for the application.
Helpful?
-
Warranty
Manufacturer's Warranty
1 year limited warranty
Extend Your Warranty Coverage with a Northern Protection Plan (NPP)
Repair Plan — 1 Year
A Northern Protection Plan is available after adding the product to your shopping cart.
Compare with Most Popular in Hydraulic Power Units
See All Hydraulic Power Units
See All NorTrac Hydraulic Power Units
Currently Viewing This Product
$649.99Shipping:
Free shipping (lower 48 states) - Available nowStore Pickup:
Not available - online only
Item # 53977
$1699.00Shipping:
Factory shippedHeavy/large item. Lift gate service available.
Store Pickup:
Not available - online only
Item # 53598
$549.99Shipping:
Free shipping (lower 48 states) - Available nowStore Pickup:
Not available - online only
Item # 53464
$549.99Shipping:
Free shipping (lower 48 states) - Available nowStore Pickup:
Not available - online only
Specifications
1.5 GPM
7 GPM
1 GPM
1.5 GPM
3,190
900
2,900
2,600
3,000
3,600
3,450
3,000
Battery
Air/Oil
Corded
Battery
9/16 in
1/2 in
9/16 in
9/16 in
SAE
-
SAE
SAE
2.1 Gal
5.6 Gal
2.5 Gal
5.3 Gal
12
-
115
12
2
4.8
-
2
Double Acting
Single Acting
Single Acting
Single Acting
-
1/2 in
3/8 in
-
