NorTrac 12 Volt DC Hydraulic Power Unit, Double Acting, Model# YBZ5-F2.1A1A61/WUATT2

Item# 47393
"NorTrac 12 Volt DC Hydraulic Power Unit, Double Acting, Model# YBZ5-F2.1A1A61/WUATT2"
NorTrac 12 Volt DC Hydraulic Power Unit, Double Acting, Model# YBZ5-F2.1A1A61/WUATT2

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

NorTrac 12 Volt DC Hydraulic Power Unit, Double Acting, Model# YBZ5-F2.1A1A61/WUATT2

Click or Tap image to Zoom

$579.99

  • Shipping:

    Backordered: Order now to reserve yours -
    Estimated to ship 08/25/26

  • Store Pickup:

    Not available - online only
  • Large 0.75 gallon reservoir capacity
  • Load-holding check valves on both A & B ports
  • Heavy-duty 12 Volt, 2 HP motor delivers 3,000 max. RPM
  • 1.5 GPM flow rate
  • 2.4cc displacement

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This NorTrac 12 Volt DC Double-Acting Power Unit is ideal for OEM or replacement applications. The fast-acting power up and power down hydraulic circuit allows for easy lifting and lowering.

What's Included

    (1) 12V DC power unit

Downloads

Product Manual

Features + Benefits

  • Large 0.75 gallon reservoir capacity
  • Load-holding check valves on both A & B ports
  • Heavy-duty 12 Volt, 2 HP motor delivers 3,000 max. RPM
  • 1.5 GPM flow rate
  • 2.4cc displacement
  • 9/16-18 SAE O-rings on the outlet ports
  • Low amperage draw
  • Electric pendant control for easy operation
  • Fast response cartridge valve operation
  • Low leakage electric solenoid valves
  • Pressure-balanced pump
  • 22.4in.L x 6in.W x 7.5in.H

Key Specs

AttributeSpecification

item#

47393

Brand

NorTrac

Manufacturer's Warranty

1 year limited warranty

Ship Weight

33.6 LB

Max. Flow Rate

1.5 GPM

Max. PSI

2,900
AttributeSpecification

Max. RPM

3,000

Port Outlet Size

9/16 in

Reservoir Capacity

0.75 Gal

Volts

12

Product Weight

lb

Dimensions L x W x H (in.)

22.4 x 6.0 x 7.5 in

Reviews

Questions & Answers

10 Reviews This action will navigate to reviews.

Questions

1–10 of 22 Questions
Sort by:

  1. DO YOU HAVE THE PART NUMBER FOR THE STEMS THAT CONTROL THE HYDRAULIC FLOW BOTH WAYS

    1 answer

    1. The 4-way, 2-position solenoid valve is part #MSLSV-08-2NCP-5B. The 2-way, 2-position solenoid valve is part #MSLSV-08-2NCP-5B. Neither valve includes a coil, but one is available as part #MSLC-08-C-5B. These parts are available through our sister company, Jacks Small Engines. Please visit www.JacksSmallEngines.com for pricing and availability.

      Helpful?

  2. How does do you mount the unit down ? as I dont see any brackets or mounting holes in the picture or in the technical drawing on line.

    1 answer

    1. This power unit should be mounted either in an enclosure or a location preventing the unit from being exposed to moisture and weather. Mount it as close to the battery as possible. The bolt pattern is 3/8-16 x 1/2" deep and the holes are 3-1/4" apart.

      Helpful?

  3. Can the pressure be adjusted ?

    1 answer

    1. The pressure is adjustable, but it is not recommended to adjust it as the consumer. Please consult a hydraulic specialist before making any adjustments.

      Helpful?

  4. Do you have a unit with two double acting valves for power up power down power angle left and power angle right

    1 answer

    1. Northern Tool does not offer a unit with two double acting valves.

      Helpful?

  5. Can you attach a larger capacity reservoir for larger capacity cylinders?

    1 answer

    1. We do offer other models with a larger capacity reservoirs such as our item #53460 and #53461.

      Helpful?

  6. Do they make a different type of pendant control. More like a joystick or toggle. Thank you

    1 answer

    1. At this time, we do not offer a different control type for this unit.

      Helpful?

  7. would it be possible to add something to adjust the flow rate to the pump?

    1 answer

    1. Adding anything to this unit to adjust the flow is not recommended. By adjusting the flow, the amperage could increase which may cause premature failure of the solenoid.

      Helpful?

  8. Is the flow rate adjustable?

    1 answer

    1. There is no flow control on this to adjust flow rate.

      Helpful?

  9. Can you use this unit for a single action jack

    1 answer

    1. This power unit could not be used on a single acting jack.

      Helpful?

  10. how long is the pendant cord on the YBZ5-F2.1A1A61/WUATT2 unit and can I order a specific length

    1 answer

    1. The pendant cord length is 19 feet. There is not a longer option available.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
