NorthStar Belt Driven Generator Head, 5,500 Surge Watts, 5,000 Rated Watts, 11 HP Required

Item# 165913
"NorthStar Belt Driven Generator Head, 5,500 Surge Watts, 5,000 Rated Watts, 11 HP Required"
Top Seller
NorthStar Belt Driven Generator Head, 5,500 Surge Watts, 5,000 Rated Watts, 11 HP Required

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

NorthStar Belt Driven Generator Head, 5,500 Surge Watts, 5,000 Rated Watts, 11 HP Required

Click or Tap image to Zoom

$749.99

  • Shipping:

    Free shipping (lower 48 states) - Available now

  • Store Pickup:

    Out of stock at Fredericksburg VA

  • Two 20 Amp 120V receptacles
  • One 20 Amp 240V locking plug receptacle
  • Uses NEMA 5-20R and NEMA L6-20R plugs
  • 41.7 Amps at 120 Volts, 20.8 Amps at 240 Volts
  • 100% Copper windings

See full description

Complete Your Solution

  • NorthStar Belt Driven Generator Head, 5,500 Surge Watts, 5,000 Rated Watts, 11 HP Required
  • Reliance Generator Transfer Switch Kit, 6 Circuits, Model# 306CRK
  • Strongway Outdoor Extension Cord, 15 Amps, 12/3 Gauge, 50ft. Rust-Resistant Blades, Flexible to -40°F
  • Honda Power Equipment 10W-30 Motor Oil, 1-Qt. Bottle
Price for all four:

$1152.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

Add an 11 HP engine to this NorthStar® Belt Driven Generator Head and produce portable electric power! Brushless design for reliable performance and low maintenance. Packs 5,000 continuous Watts. Delivers 41.7 Amps at 120 Volts, 20.8 Amps at 240 Volts. Has two 20 Amp, 120 Volt outlets and one 20 Amp 240 Volt locking plug outlet. Sealed ball bearings. Input shaft turns clockwise and counterclockwise. For horizontal application only.

What's Included

    (1) Generator

Downloads

Product Manual

Features + Benefits

  • Two 20 Amp 120V receptacles
  • One 20 Amp 240V locking plug receptacle
  • Uses NEMA 5-20R and NEMA L6-20R plugs
  • 41.7 Amps at 120 Volts, 20.8 Amps at 240 Volts
  • 100% Copper windings
  • Brushless design, less than 6% Total Harmonic Distortion
  • Bi-directional
  • Thermal overload protection
  • Conveniently located control panel
  • Push button circuit breakers
  • Plugs sold separately

Key Specs

AttributeSpecification

item#

165913

Brand

NorthStar

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

54.75 LB

Required Horsepower

11

Shaft Diameter

7/8 in
AttributeSpecification

Rated Watts

5,000

Surge Watts

5,500

Continuous Run Time

Yes

Receptacles (qty.)

3

Product Weight

lb

Dimensions L x W x H (in.)

16.25 x 7.5 x 7.75 in

Reviews

Questions & Answers

9 Reviews This action will navigate to reviews.

Questions

1–10 of 17 Questions
Sort by:

  1. is this unit contains permanent magnets.

    I would like to transport this unit in my luggage.
    is it airline safe ?
    regards

    1. It is airline safe but should go as Cargo in the shipping carton or a small crate - the generator head is 53 Lbs. You have to label it as Heavy so nobody hurts themselves or damages it, and "Contains Permanent Magnets."

      The pilot has to be aware of cargo containing magnets - it will throw the compass off. He has to readjust/null the compass before departure to compensate (if possible) and/or rely on GPS and other navigation aids.

      Helpful?

    2. The NorthStar Generator Head will include permanent magnets.

      Helpful?

  2. is it safe to run as a main power supply for a house?

    I am interested in a generator head replacement for a home made wind generator... The issue i am seeing is that most generator heads are for temporary use only, Is this the case with this unit as well?

    1. This generator head can be used as a back up, standby power source for a building. For this application, it would need to be installed by a licensed electrician. It can also be used as a portable power source where appliances and tools are plugged into the generator's electrical outlets directly. Both applications are meant to be temporary.

      Helpful?

    2. Yes they are for temporary use only.

      Helpful?

  3. Can this run outside in inclement weather?

    1 answer

    1. The generator head is designed to be used in an outdoor location. You will need to choose a location where the generator will not be exposed to rain, snow or direct sunlight. Exposure to water can cause electric shock.

      Helpful?

  4. I have a 8 HP BS industrial horizontal gasoline engine.  I’ll be running a 3/4 Hp 240 volt submersible well pump during emergencies only for about 15 minutes, probably no more than 30 minutes.  Can I use the 5KW generator head vs the 2.5 KW generator head

    1 answer

    1. This generator head requires a gas engine rated for a minimum of 11 HP. An 8 HP engine would not be large enough. With the proper engine size, the amperage is still required to determine the wattage needs, which will determine the required generator size for the application. Please use this formula to calculate the needs: Volts x Amps = Watts.

      Helpful?

  5. When ramping up the rpm’s for a short period of time or ramping it down does that effect the generator over time?

    1 answer

    1. This generator head is made to operate at 3540-3720 RPM. Rotating the generator at lower speeds will not cause any damage to the generator itself; however, the power output of the generator at slower speeds will not produce the correct voltage. Rotating the generator at higher speeds, may cause a problem and could damage the generator. This will also not produce the correct voltage. If this is referring to the ramp up time from 0 RPM to the operating RPM, it should not cause any harm to the machine as long as the electricity from the generator is not being used at the time.

      Helpful?

  6. What rpm do you run this unit

    1 answer

    1. This generator head can be run at 3,540 to 3,720 RPM.

      Helpful?

  7. Could you direct couple the shafts with iron jaw (rubber) coupler instead of belt driven?

    1 answer

    1. This generator head can be directly coupled to a motor.

      Helpful?

  8. with 24/7 use, what is the predicted life span? about how many hours of use can one get out of this generator head before needed to expect to replace?

    1 answer

    1. This generator head is manufactured to an engineering specification of 2000 hours; duty life is affected by the application and environmental conditions.

      Helpful?

  9. Can this generator be driven by a hydraulic motor?

    1 answer

    1. This generator head is made to operate at 3540-3720 RPM. A hydraulic motor could be used as long as it is able to run at a consistent speed within that RPM range.

      Helpful?

  10. What would be the smallest electic motor the could run this well?

    1 answer

    1. This generator head is intended to be run by a gas engine with an 11 horsepower rating or more. This generator head is not rated or recommended for use with an electric motor.

      Helpful?
