Klutch Dual-Voltage AC/DC TIG/Stick Welder with Inverter Technology, 120/230 Volts, 200 Amp Max.

Item# 5875906
Top SellerClearance
Klutch Dual-Voltage AC/DC TIG/Stick Welder with Inverter Technology, 120/230 Volts, 200 Amp Max.

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Klutch Dual-Voltage AC/DC TIG/Stick Welder with Inverter Technology, 120/230 Volts, 200 Amp Max.

Click or Tap image to Zoom

$399.99
Reg $799.99Save $400.00

Order today to get this price.

  • Shipping:

    Not available

  • In Store Only:

  • Extra-Versatile Operation: Multi-process TIG/stick welding functions offer the welding capabilities you need to handle a variety of projects
  • Dual-Voltage Design Operates Where You Need It: 120/230V input allows the unit to be plugged in almost anywhere
  • Handles the Heavy Metals: Get powerful performance welding steel, stainless steel and aluminum up to 3/16in. thick
  • Extra-Lightweight Inverter Design: Special inverter technology weighs in at up to 50% lighter than comparable models and delivers ultra-consistent welds
  • Take-Anywhere Portability: A robust carrying handle is built into the machine for easy, convenient movement during transport or at the jobsite

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This Klutch Dual-Voltage 200 Amp AC/DC TIG/Stick Welder features dual 120/230V input that can be plugged into most outlets for convenient use almost anywhere. The efficient inverter-powered system is super lightweight, up to 50% lighter, for easy transport and requires up to 25% less input power than traditionally powered welders while also delivering consistent power output. Power Factor Correction (PFC) design provides even more efficiency and higher welding performance. The user interface makes machine setup easy. A pulse feature is also available, which provides a drumbeat-like rhythm for filler metal deposition. This unit is a great TIG welder for use on aluminum. The AC frequency and AC balance can be adjusted to provide more cleaning action on dirty aluminum or to maximize penetration on thick materials. Auto setting parameters all adjust for easier welding. Includes a foot pedal for hands-free operation. 20% duty cycle @ 200A (230V input); 35% duty cycle @ 120A (120V input). Welding amperage range: 15–200A (240V input); 15–120A (120V input). DC output allows the welder to weld a wide variety of materials including steel, stainless steel, cast iron, hard surfacing and aluminum. Includes 10ft. MIG gun, 10ft. grounding cable with clamp, 6ft. gas hose, gas regulator, 2ft.L, 120V power cord adapter, 2 contact tips and a flux-core nozzle. CSA approved.

What's Included

    (1) 15ft. TIG torch (1) 10ft. grounding cable with electrode holder (1) 10ft. grounding cable with clamp (1) 25ft. cable with foot pedal (1) 120V adapter (1) Regulator (1) 10ft. gas hose

Downloads

Product Manual
Play Item Video

Features + Benefits

  • Extra-Versatile Operation: Multi-process TIG/stick welding functions offer the welding capabilities you need to handle a variety of projects
  • Dual-Voltage Design Operates Where You Need It: 120/230V input allows the unit to be plugged in almost anywhere
  • Handles the Heavy Metals: Get powerful performance welding steel, stainless steel and aluminum up to 3/16in. thick
  • Extra-Lightweight Inverter Design: Special inverter technology weighs in at up to 50% lighter than comparable models and delivers ultra-consistent welds
  • Take-Anywhere Portability: A robust carrying handle is built into the machine for easy, convenient movement during transport or at the jobsite
  • Includes overload protection

Key Specs

AttributeSpecification

item#

5875906

Brand

Klutch

Manufacturer's Warranty

3 year limited warranty

Ship Weight

57.0 LB

Volts

120/230

Max. Amps

200

Power Type

DC

Multi-process

Yes

Max. Weld Thickness

0.375 in

Duty Cycle

20% at 200A

Weldable Materials

Steel,Stainless steel, Iron, Aluminum
AttributeSpecification

Min. Amps

10

Wire Feed Speed Control

No

Cart Included

No

Mig Ready

No

Power Cord Length

8 ft

Clamp Cable Length

10 ft

Electrode Cable Length

10 ft

Regulator and Gas Hose Included

Yes

Shielding Gas Required

Yes

Product Weight

37.8000 lb

Dimensions L x W x H (in.)

20.7 x 10.2 x 16.1 in
