This is a single phase machine, that can be connected to three phase power by dropping the middle leg of input power.
Lincoln Electric Precision TIG 275 AC/DC TIG Welder Ready-Pak, 208/230/460 Volt, Model# K2618-1
Top Seller
This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.
Click or Tap image to Zoom
$11,999.99
- AC Auto-Balance® automatically adjusts for the optimal mix of cleaning and penetration when welding aluminum.
- Or, take full control - adjust the AC Balance® to increase or decrease cleaning action or penetration on aluminum
- Delivers the widest output range in its class with an amperage range of 2 to 340 amps
- Upgrade with the optional Advanced Pulse Control panel to enable better control over heat input, resulting in less warping and distortion on thin metals
- The Precision TIG 275 features the patented Micro-Start™ II Technology, which enhances starting and arc stability, and provides for more precise welds and crater fills
Prop 65 Warning: See Details
See full description
Price for all two:
$12,042.98
What's Included
- (1) Welder (1) Under-Cooler Cart water cooler (1) Foot Amptrol™ with 25ft. cable assembly (1) Gas regulator/flowmeter and 10ft. hose kit (1) 25ft. TIG torch (1) Zippered TIG torch cover (1) Torch parts kit (2) Water hoses (1) 15ft. work cable and clamp (1) Adapter for optional PTA-9 or PTA-17 torch
Downloads
Features + Benefits
- AC Auto-Balance® automatically adjusts for the optimal mix of cleaning and penetration when welding aluminum.
- Or, take full control - adjust the AC Balance® to increase or decrease cleaning action or penetration on aluminum
- Delivers the widest output range in its class with an amperage range of 2 to 340 amps
- Upgrade with the optional Advanced Pulse Control panel to enable better control over heat input, resulting in less warping and distortion on thin metals
- The Precision TIG 275 features the patented Micro-Start™ II Technology, which enhances starting and arc stability, and provides for more precise welds and crater fills
- Includes Under-Cooler Cart water cooler, Foot Amptrol™ with 25ft. cable assembly, gas regulator/flowmeter and 10ft. hose kit, 25ft. TIG torch with zippered cover, torch parts kit, 2 water hoses, 15ft. work cable and clamp, adapter for optional PTA-9 or PTA-17 torch
- Machine - 49.7 x 28 x 41
Accessories We Recommend
This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.
See All TIG Welders
See All Lincoln Electric TIG Welders
Currently Viewing This Product
Specifications
Specifications
Lincoln Electric Precision TIG 275 AC/DC TIG Welder Ready-Pak, 208/230/460 Volt, Model# K2618-1
Lincoln Electric Precision TIG 275 Welder , 208/230/460 Volt, 2-340 Amp Output, Model# K2619-1
Forney, Forney 220 AC/DC TIG Welder Package, Model# 420
Volts
Same
208-230/460
208-230/460
-
Max. Amps
Same
340
340
-
Power Type
Same
AC
AC
AC
Welding Processes
Same
Stick, TIG
Stick, TIG
-
Duty Cycle
Same
40% At 275a
60% At 86/78/39a; 40% At 104/94/47a
-
Weldable Materials
Same
Aluminum, Mild Steel, Stainless Steel
Stainless Steel
-
Min. Amps
Same
2
2
-
Power Cord Length
Same
25 ft
8.5 ft
-
Clamp Cable Length
Same
15 ft
10 ft
-
Electrode Cable Length
Same
15 ft
25 ft
-
Regulator and Gas Hose Included
Same
Yes
No
-
Shielding Gas Required
Same
No
No
-
Product Weight
Same
434.0000 lb
420.5000 lb
88.0000 lb
Dimensions L x W x H (in.)
Same
41.0 x 28.0 x 49.68 in
33.0 x 28.0 x 38.25 in
27.5 x 20.5 x 19.0 in
