Honda Engines, HONDA 163CC OHV ELEC START ENG, Engine Displacement 163 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 3/4 in, Model# GX160UT2XQXE2

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Click or Tap image to Zoom
Shipping:
Factory shippedStore Pickup:
Not available - online only
- Automatic decompression for easy starting
- Lamp charging system
- Heavy-duty ball bearing supported crankshaft
- Double walled heavy-duty tank with in tank fuel strainer
- Battery cables not included
See full description
Description
Key Specs
Reviews
Q & A
Accessories
Warranty
Compare
Product Summary
What's Included
- (1) Engine, Model# GX160UT2XQXE2
Features + Benefits
- Automatic decompression for easy starting
- Lamp charging system
- Heavy-duty ball bearing supported crankshaft
- Double walled heavy-duty tank with in tank fuel strainer
- Battery cables not included
- Not for sale in CA.
Key Specs
| Attribute | Specification |
|---|---|
item# | 60591 |
Brand | Honda Engines |
Manufacturer's Warranty | 3 year limited warranty |
Ship Weight | 40.0 LB |
Engine Displacement | 163 cc |
Engine Type | GX Series OHV Commercial-duty |
Shaft Diameter | 3/4 in |
Shaft Length | 2.43 in |
Start Type | Electric and Recoil |
Shaft Keyway | 0.18 in |
Net Torque | 7.6 ft-lbs. |
Crankshaft | Q-type |
PTO Height | 4.17 in |
Cylinders (qty.) | 1 |
Cylinder Bore | Cast Iron |
Net Power Output | 4.8 HP |
Compression Ratio | 9:1 |
Fuel Tank | Yes |
| Attribute | Specification |
|---|---|
Fuel Tank Capacity | 3.3 qt |
Oil Capacity | 0.61 qt |
Low Oil Shutdown | Yes |
Shaft Rotation (From PTO Shaft Side) | Counter Clockwise |
Governor System | Centrifugal Mechanical |
Ignition System | Electronic |
Carburetor | Float, External Vent |
Lubrication System | Splash |
Auto Compression Release | Yes |
Cooling System | Air |
Bore | 2.7 in |
Stroke | 1.8 in |
Air Cleaner Type | Dual Element |
Choke Control | Manual |
Throttle Control | Remote |
Charging System Amps | 1 |
Muffler Included | Yes |
Reviews
Questions & Answers
Questions
-
· 16 years ago
what battery is recommended for this engine?
-
Jimbobjoeed· 16 years ago
Helpful?
-
ProductExpert11· 16 years ago
You will want to use a 12 volt battery with an ampere-hour rating of at least 18 AH.
Helpful?
-
-
· 6 years ago
Can this engine be started with a motorcycle battery? (12V 14AH 200CCA) or is starting this too much for such a small battery? Will the charging circuit keep the battery charged?
1 answer-
ProductExpert6· 6 years ago
A motorcycle battery would not be recommended for starting the electric start on this engine. The engine does have a 3 amp charging circuit to charge the battery.
Helpful?
-
-
· 7 years ago
How mant hp
What hp is the 163cc engine w/electric start?
1 answer-
ProductExpert6· 7 years ago
This engine would have an approximate horsepower rating of 5.5 HP.
Helpful?
-
