Honda Engines, HONDA 389CC ENGINE, Engine Displacement 389 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 1 in, Model# GX390UT2XQA2

Item# 75925
Honda Engines, HONDA 389CC ENGINE, Engine Displacement 389 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 1 in, Model# GX390UT2XQA2

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Honda Engines, HONDA 389CC ENGINE, Engine Displacement 389 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 1 in, Model# GX390UT2XQA2

Click or Tap image to Zoom

$919.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Honda 389cc GX OHV air-cooled, 4-stroke, horizontal engine
  • OHV design delivers increased efficiency and optimal power transfer
  • Fuel efficient, high-output operation with precision camshaft design, precise valve timing and optimal valve overlap
  • Large capacity, multi-chambered exhaust system with improved camshaft and muffler reduce engine noise by up to 5dB
  • Muffler, breather valve, case cover, air intake system, rigid crankcase, helical-cut gears and lightweight materials are also designed to reduce noise level

See full description

Complete Your Solution

  • Honda Engines, HONDA 389CC ENGINE, Engine Displacement 389 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 1 in, Model# GX390UT2XQA2
  • Honda Power Equipment 10W-30 Motor Oil, 1-Qt. Bottle
  • Honda Engines, HONDA MAINT. KIT, Pieces (qty.) 4 Model# HONDAKIT5
  • GDI, HOUR METER W/TACHOMETER, Model# N111-0100-1005
Price for all four:

$1020.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Honda 389cc GX Series OHV commercial-grade engine is designed for the most demanding commercial applications. It has set an industry standard for reliability and durability. The Overhead Valve design offers cool, fuel-efficient operation and the cast iron cylinder sleeve provides longer service life. The GX is reliable, easy starting and quiet running. This legendary engine has earned the reputation as the preferred engine for construction equipment. Common applications include pressure washers, compressors, log splitters and chipper/shredders. Not for sale in CA.

What's Included

    (1) Engine, Model# GX390UT2XQA2

Downloads

Product Manual

Features + Benefits

  • Honda 389cc GX OHV air-cooled, 4-stroke, horizontal engine
  • OHV design delivers increased efficiency and optimal power transfer
  • Fuel efficient, high-output operation with precision camshaft design, precise valve timing and optimal valve overlap
  • Large capacity, multi-chambered exhaust system with improved camshaft and muffler reduce engine noise by up to 5dB
  • Muffler, breather valve, case cover, air intake system, rigid crankcase, helical-cut gears and lightweight materials are also designed to reduce noise level
  • Oil alert protects engine
  • Durable cast iron cylinder sleeve
  • Dual-element air cleaner keeps the engine running clean
  • Easy to use and maintain with simple throttle control, large fuel tank, wide-mouth automotive-style fuel cap, dual oil fills and drains, easy to use control box and easily accessible spark plug
  • Get quick starts with the heavy-duty recoil starter with ergonomic design and automatic decompression system
  • Double walled heavy-duty tank with in tank fuel strainer
  • Not for sale in CA

Key Specs

AttributeSpecification

item#

75925

Brand

Honda Engines

Manufacturer's Warranty

3 year limited warranty

Ship Weight

90.0 LB

Engine Displacement

389 cc

Engine Type

GX Series OHV Commercial-duty

Shaft Diameter

1 in

Shaft Length

3.48 in

Start Type

Recoil

Shaft Keyway

0.25 in

Net Torque

19.5 ft-lbs.

Crankshaft

Q-type

PTO Height

5.25 in

Cylinders (qty.)

1

Cylinder Bore

Cast Iron

Net Power Output

11.7 HP

Compression Ratio

8.2:1

Fuel Tank

Yes

Fuel Tank Capacity

6.4 qt
AttributeSpecification

Oil Capacity

1.16 qt

Low Oil Shutdown

Yes

Low Oil Alert

Yes

Shaft Rotation (From PTO Shaft Side)

Counter Clockwise

Governor System

Centrifugal Mechanical

Ignition System

Electronic

Carburetor

Float, External Vent

Lubrication System

Splash

Bearing Type

Ball

Auto Compression Release

Yes

Cooling System

Air

Bore

3.5 in

Stroke

2.5 in

Air Cleaner Type

Dual Element

Choke Control

Manual

Throttle Control

Remote

Fuel Filter

Yes

Muffler Included

Yes

Reviews

Questions & Answers

9 Reviews This action will navigate to reviews.

Questions

1–4 of 4 Questions
Sort by:

  1. What is the difference(s) between this model number (GX390UT2XQA2) and Model# GX390UT1QAA2?

    1 answer

    1. They are the same engine, the model GX390UT2XQA2 is replacing the model GX390UT1QAA2 when it is sold out.

      Helpful?

  2. does this engine have a threaded shaft

    1 answer

    1. This does not have a threaded shaft. We currently do not offer a Honda 389 CC engine with a threaded shaft.

      Helpful?

  3. WHAT IS THE HP ON THIS ENGINE?

    1 answer

    1. This Honda engine has a net power output of 11.7 HP at 3,600 RPM's.

      Helpful?

  4. Dimension of shipping box and total weight

    What is the dimension of shipping box and total weight of GX390UT2QA2 including shipping containler? Also need information on GX390-QNE2 with electric start

    1 answer

    1. The shipping dimensions for both engines, item #75925 and #6013 would be 21" L x 21" W x 21" H. The ship weight is 90 pounds.

      Helpful?
