Hobart AirForce 40i Plasma Cutter with Multi-Voltage Plug, Inverter, 120/240V, 15/20/40 Amp Output, Model #500576

Item# 96173
"Hobart AirForce 40i Plasma Cutter with Multi-Voltage Plug, Inverter, 120/240V, 15/20/40 Amp Output, Model #500576"
Top Seller
Hobart AirForce 40i Plasma Cutter with Multi-Voltage Plug, Inverter, 120/240V, 15/20/40 Amp Output, Model #500576

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Hobart AirForce 40i Plasma Cutter with Multi-Voltage Plug, Inverter, 120/240V, 15/20/40 Amp Output, Model #500576

Click or Tap image to Zoom

$2179.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Dual-Voltage capability with MVP (Multi-Voltage Plug) allows you to connect to common 120 or 240V power receptacles without the use of any tools, simply choose the plug that fits the receptacle
  • Clean cuts 5/8in. mild steel; severs steel up to 7/8in. thick
  • 12ft. XT40R torch - designed for increased comfort with an ergonomic trigger safety, extremely flexible cables, more efficient cooling and economical replacement XT series cutting tips for long life
  • Duty Cycles: 120 V (15A) 20A at 88 VDC, 60% duty cycle; 120 V (20A) 27A at 91 VDC, 35% duty cycle; 240V 40 A at 140 VDC, 60% duty cycle
  • Pilot Arc Controller allows you to cut expanded/perforated metals, as well as painted or coated surfaces, without retriggering the torch

See full description

Complete Your Solution

  • Hobart AirForce 40i Plasma Cutter with Multi-Voltage Plug, Inverter, 120/240V, 15/20/40 Amp Output, Model #500576
  • Klutch Cut-Resistant Goatskin/Cowhide MIG Welding Gloves, Single Pair, Gold/Black, XL
  • Klutch Steel Welding Table with Tool Kit, 36in.L x 24in.W x 33-1/4in.H
  • Klutch Mobile Welding Workstation with 26-Pc. Metal Fit-Up Kit, 40in.L x 24in.W x 36in.H, 600-Lb. Capacity
Price for all four:

$2752.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Hobart AirForce® 40i Plasma Cutter with Multi-Voltage Plug is an economical plasma cutting system for all conductive metals. With XT series torches, long life XT consumables, and a Pilot Arc Controller feature, you'll appreciate the enhanced performance. It can cut mild steel up to 7/8in. This portable unit features a lightweight, powerful inverter design and an ergonomic trigger safety, with more efficient air consumption and economically priced consumables. Plus the versatile multi-voltage plug (MVP) allows a user to connect to common 120V or 240V power receptacles. Plasma cutters cut faster and more precisely with a thinner kerf and less slag than cutting with oxy fuel. A smaller heat-affected zone also causes less warping. And you'll never have gas pressure settings, flame tuning, metal preheating, or gas cylinders or refills to worry about. Features Hobart's 5/3/1in.dustry Warranty protection.

What's Included

    (1) AirForce® 40i Plasma cutter (1) 12ft. XT40R hand-held torch (1) 12ft. work cable with clamp (1) Cable management (1) 10ft. power cord with 240V L6-30P twist lock plug and MVP2 Adapters (1) Extra consumables (2 tips, shield deflector, and electrode) (1) Easy-to-connect, built-in gas/air filter and regulator for extra protection

Downloads

Product Manual Product Manual2
Play Item Video

Features + Benefits

  • Dual-Voltage capability with MVP (Multi-Voltage Plug) allows you to connect to common 120 or 240V power receptacles without the use of any tools, simply choose the plug that fits the receptacle
  • Clean cuts 5/8in. mild steel; severs steel up to 7/8in. thick
  • 12ft. XT40R torch - designed for increased comfort with an ergonomic trigger safety, extremely flexible cables, more efficient cooling and economical replacement XT series cutting tips for long life
  • Duty Cycles: 120 V (15A) 20A at 88 VDC, 60% duty cycle; 120 V (20A) 27A at 91 VDC, 35% duty cycle; 240V 40 A at 140 VDC, 60% duty cycle
  • Pilot Arc Controller allows you to cut expanded/perforated metals, as well as painted or coated surfaces, without retriggering the torch
  • Wind Tunnel Technology™ prevents abrasive dust and particles from damaging internal components
  • Fan-On-Demand™ cooling system operates only when needed, reducing power consumption and contaminants drawn into the machine
  • Power factor correction (PFC) circuitry draws up to 30% less amperage for the same cutting range as compared to the competition
  • PFC expands operator's work area via extension cord, while minimizing nuisance circuit breaker trips caused by voltage drops
  • LVC™ line voltage compensation provides peak performance power under variable input voltage conditions (±15%) for steady and cleaner-ending cuts
  • Internal gas/air filter and regulator controls amount of usage and flow of air or gas
  • Starts without high frequency, protecting the unit by not interfering with or damaging controls or computers
  • Diagnostic LED lights for quick troubleshooting of pressure, power and cup situations
  • Postflow cooling circuit extends life of consumables and torch by cooling them with postflow air after trigger is released
  • Automatic gouging consumable detection adjusts gas pressure to optimize performance, eliminating the need for a manual regulator
  • Compatible with engine-driven welders, offering complete cutting capability when powered by an engine-driven welder/generator with a 240V receptacle of 8 kW or more
  • Hobart 5/3/1 Industrial Warranty -- 5-year warranty on transformers, stabilizers and main rectifiers; 3-year warranty on generators, PC boards and drive systems; 1-year warranty on guns (MIG, Plasma and TIG torches)

Key Specs

AttributeSpecification

item#

96173

Brand

Hobart

Manufacturer's Warranty

5 year limited warranty

Ship Weight

25.8 LB

Volts

120/240

Amps

20

Cutting Thickness

0.625 in

Sever Thickness

0.88 in

Clamp Cable Length

1 in
AttributeSpecification

Plasma Gas Flow

4.8 cfm

Max. PSI

120

Duty Cycle

50% At 40a

Power Cord Length

10 ft

Pilot Arc

Yes

Compressor Included

No

Cart Included

No

Product Weight

21.0000 lb

Dimensions L x W x H (in.)

9.0 x 5.5 x 13.25 in

Reviews

Questions & Answers

31 Reviews This action will navigate to reviews.

Questions

1–9 of 9 Questions
Sort by:

  1. What size and capacity air compressor that is required

    1. The air compressor will need to provide at least 6.0 CFM at 90-120 PSI.

      Helpful?

    2. Per the manual, the new version (generation 2) requires 6.0cfm @ 90psi

      Helpful?

    3. air compressor has to be 6.0SCFM at least 90psi

      Helpful?

  2. What's the max cutting depth

    1 answer

    1. The maximum cutting capacity for mild steel for a clean cut is 5/8" on 240 volts. The maximum severance cut is 7/8" on 240 volts. On 120 volt it has a rated clean cut of approximately 1/4" to 3/8" with a maximum sever cut of 7/8".

      Helpful?

  3. does this machine have a drag tip or does it need a stand off

    1 answer

    1. The torch will have a drag shield included.

      Helpful?

  4. Can the 40i easily connect to a plasma cutting table

    1 answer

    1. This plasma cutter does not have any CNC set up options, so it would not mount to a plasma cutting table.

      Helpful?

  5. What is the duty cycle on the highest setting? And how come the 27i doesn’t have a pile arc ???

    1 answer

    1. The duty cycle on the highest setting would be 50%.

      Helpful?

  6. Is less air flow required to cut thinner steel?

    1 answer

    1. Per the manufacturer, less air flow is not required to cut thinner steel.

      Helpful?

  7. what tips are needed for the xt40r torch

    1 answer

    1. The replacement tips are Hobart Model #770797. Northern Tool does not offer these tips.

      Helpful?

  8. This cutter requires no gas cylinders right?

    1 answer

    1. This plasma cutter does not require any gas. It will require an external air compressor that can produce 6.0 CFM at 90-120 PSI.

      Helpful?

  9. What is the thinest metal the 40I rated to cut, Does this require different tips

    1 answer

    1. Per the manufacturer, the thinnest metal would be thin steel that is 12 gauge. Different tips would not be required.

      Helpful?
