Fill-Rite FR410B Chemical Transfer Pump System, 12 Volt, 13 GPM, Model# FR410B

Item# 109594
Fill-Rite FR410B Chemical Transfer Pump System, 12 Volt, 13 GPM, Model# FR410B

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Fill-Rite FR410B Chemical Transfer Pump System, 12 Volt, 13 GPM, Model# FR410B

Click or Tap image to Zoom

$1084.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Engineered with double diaphragms for maintaining constant output pressure regardless of load
  • Santoprene diaphragms are compatible with a wide range of fluids including but not limited to agricultural pesticides, herbicides, fertilizers, mild acids, soaps and water
  • Durable pump can run dry without causing any internal damage, giving you peace of mind
  • Thermally-protected motor prevents overheating, ensuring your pump withstands the test of time
  • Conveniently available in 6 core configurations for your application including the portable Chemtraveller, recirculating Mix-N-Go, mobile Pump-N-Go, sturdy IBC tote bracket, steel drum mount and plastic straight flange

See full description

Complete Your Solution

  • Fill-Rite FR410B Chemical Transfer Pump System, 12 Volt, 13 GPM, Model# FR410B
  • Strongway Spring-Rewind Fuel and Oil Hose Reel, 3/4in. x 25ft. NBR Rubber Hose, 1250 PSI
  • Fill-Rite Mechanical Fuel Meter, 1in., Model# 901CMK4200
  • GPI 3-30 GPM Digital Fuel Meter
Price for all four:

$2034.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Fill-Rite Chemical Transfer Pump System, is engineered for efficient and reliable fluid transfer, delivering up to 13 gallons per minute (GPM) with a 12V power source. This high-performance system is designed to handle a variety of chemicals, making it ideal for industrial and agricultural applications. The package includes a durable metal bung mount for secure attachment, a polypropylene suction pipe for effective fluid intake, and additional chemical fittings to ensure compatibility with various substances. The manual nozzle type allows for precise control during dispensing, enhancing operational efficiency and safety. Built to withstand rigorous use, the Fill-Rite Chemical Transfer Pump System offers robust construction and dependable performance, making it a valuable tool for professionals who require consistent and effective fluid handling solutions.

What's Included

    (1) Diaphragm pump

Downloads

Product Manual
Additional Product Info

Features + Benefits

  • Engineered with double diaphragms for maintaining constant output pressure regardless of load
  • Santoprene diaphragms are compatible with a wide range of fluids including but not limited to agricultural pesticides, herbicides, fertilizers, mild acids, soaps and water
  • Durable pump can run dry without causing any internal damage, giving you peace of mind
  • Thermally-protected motor prevents overheating, ensuring your pump withstands the test of time
  • Conveniently available in 6 core configurations for your application including the portable Chemtraveller, recirculating Mix-N-Go, mobile Pump-N-Go, sturdy IBC tote bracket, steel drum mount and plastic straight flange
  • Manufacturer's 5-Year Warranty

Key Specs

AttributeSpecification

item#

109594

Brand

Fill-Rite

Manufacturer's Warranty

5 year limited warranty

Ship Weight

35.0 LB

GPM

13

Nozzle Type

Manual

Amps

20

Watts

240

Inlet Port

1 in

Outlet Port

1 in
AttributeSpecification

Discharge

24 ft

Self-Priming

Yes

Hose Length

12 ft

Speed

2,600 rpm

Duty Cycle

30 min

Bypass Valve

No

Horsepower

0.25 HP

Product Weight

lb

Dimensions L x W x H (in.)

15.25 x 8.75 x 10.5 in

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

  1. gasoline rated? aviation fuel rated?

    is this pump rated for gasoline also?

    Is it also rated for aviation fuel?

    1. This pump is not to be used with gasoline or aviation fuel.

      Helpful?

    2. Thanks for your question.

      The FR410B pump is not rated for gasoline or aviation fuel.

      The FR410B is made of polypropylene and will not conduct static electricity. This means that you can get a static spark at the nozzle. Also, the gasoline will wear the check balls in the pump, and they will not seal properly, causing the pump to lose prime and not be able to re-prime.

      As for aviation fuel, we do not recommend any of our pumps for pumping fuel into aircraft.

      Thanks again for your questions and interest in Fill-Rite products.

      Best Regards,
      Fill-Rite Technical Support

      Helpful?
