BendPak 4-Post Extended Truck and Car Lift, 14,000-Lb. Capacity, Model# HDS-14LSX

Item# 144730
BendPak 4-Post Extended Truck and Car Lift, 14,000-Lb. Capacity, Model# HDS-14LSX

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

BendPak 4-Post Extended Truck and Car Lift, 14,000-Lb. Capacity, Model# HDS-14LSX

Click or Tap image to Zoom

$11,615.00

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

  • Store Pickup:

    Not available - online only
  • Rail-kit for optional accessories
  • Electric/hydraulic power system that powers a single hydraulic cylinder mounted under the runway
  • Forklift Required
  • Oversized self-lubricating cable rollers
  • Rugged 1 3/8in. roller axles

See full description

Complete Your Solution

  • BendPak 4-Post Extended Truck and Car Lift, 14,000-Lb. Capacity, Model# HDS-14LSX
  • BendPak Rolling Drain Pan for 4-Post Truck and Car Lifts, Model# DP-30
  • BendPak Integrated Rolling Bridge Airline Kit for 4-Post Car Lifts, Model# AK-14
Price for all three:

$12,270.00

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

BendPak's tradition of building professional-quality lift systems continues with this 14,000-lb. capacity 4-post lift. Item too large for lift gate. Requires forklift on site for unloading. This item is delivered by flatbed truck Monday--Friday with 24 hours advance notice. A forklift is required to offload the lift from a dock-height flatbed trailer. Item too large for lift gate. Requires forklift on site for unloading. This item is delivered by flatbed truck Monday-Friday with 24 hours advance notice. A forklift is required to offload the lift from a dock-height flatbed trailer.

What's Included

    (1) 4-post extended truck and car lift

Downloads

Product Manual

Features + Benefits

  • Rail-kit for optional accessories
  • Electric/hydraulic power system that powers a single hydraulic cylinder mounted under the runway
  • Forklift Required
  • Oversized self-lubricating cable rollers
  • Rugged 1 3/8in. roller axles
  • Multi-position safety locks and internal "anti-sway" slider blocks on each column
  • Nonskid ramp surface
  • Push-button safety release
  • Adjustable runways for different tread widths
  • Automatic leveling system
  • Integrated rear slip plates
  • Item too large for lift gate; Requires forklift on site for unloading
  • Heavy-duty 1/2in. aircraft cables

Key Specs

AttributeSpecification

item#

144730

Brand

BendPak

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

3067.0 LB

Capacity

14,000 lb

Max. Rise

6.4 ft

Horsepower

3 HP
AttributeSpecification

Motor Phase

Single-phase

Volts

220

Lock Spacing

4 in

Locking Position (qty.)

15

Time of Full Rise

60 sec.

Drive-Thru Clearance

98.25 in

Material

Steel

Reviews

Questions & Answers

Questions

1–6 of 6 Questions
Sort by:

  1. What is the difference between the HDS-14, HDS-14T, and the HDS-14LSX? We are looking for a good quality lift for our mechanics to be able to work on our fleet of pickups.

    1 answer

    1. The HDS-14T has a max rise of 82 inches and a minimum wheelbase of 135 inches, while HDS-14 and HDS-14LSX has a max rise of 70 inches and a minimum wheelbase of 140 inches. HDS-14LSX is specifically designed for wheel alignments in addition to other services, while the HDS-14 is designed for general vehicle maintenance.

      Helpful?

  2. Is this lift Made In USA or Imported?

    1 answer

    1. This item is imported from China.

      Helpful?

  3. What is the total Width, What is the runway width and lenght, The Total length is 204in does that include the lenght of the ramps?

    1 answer

    1. The total width of the BendPak 4-Post Lift is 130.” The runway width is 20.” The runway length is 199.” The total length with the ramps included is 241.”

      Helpful?

  4. ELECTRIC/HYDRAULIC POWER UNIT

    Illustrations show unit mounted to rear leg, is it possible to install on lf post (my existing one has air & power there).

    1 answer

    1. Yes, the power unit can be mounted on the front posts.

      Helpful?

  5. can this be set up to pull in one end and off the other ?

    1 answer

    1. This BendPak 4-Post Lift has optional drive-thru ramps available. They must be purchased via the manufacturer.

      Helpful?

  6. does this product come with the center jacks and turn plates

    do you sell turn plates separate

    1 answer

    1. The turn and split plates come standard with this lift. The jacks do not come standard and would have to be purchased separately. The jacks would be item #144718.

      Helpful?

Accessories We Recommend

This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.

See All Lift Accessories
BendPak Rolling Drain Pan for 4-Post Truck and Car Lifts, Model# DP-30
4.0 out of 5 stars. 2 reviews

BendPak Rolling Drain Pan for 4-Post Truck and Car Lifts, Model# DP-30

Item # 144625

$525.00

Warranty

Manufacturer's Warranty

12 months parts/12months labor

Compare with Most Popular in Four-Post Lifts

See All Four-Post Lifts

See All BendPak Four-Post Lifts

Specifications

Specifications
BendPak 4-Post Extended Truck and Car Lift, 14,000-Lb. Capacity, Model# HDS-14LSX
BendPak 4-Post Extended Truck Lift, 40,000-Lb. Capacity, Model# HDS-40X
BendPak Heavy-Duty 4-Post Truck Lift, 40,000-Lb. Capacity, Model# HDS-40
BendPak 4-Post Car Lift, 9000-Lb. Capacity, Model# HD-9
Capacity
Same

14,000 lb

40,000 lb

40,000 lb

9,000 lb

Max. Rise
Same

6.4 ft

5.8 ft

5.8 ft

6 ft

Horsepower
Same

3 HP

5 HP

5 HP

3 HP

Motor Phase
Same

Single-phase

Single-phase

Single-phase

Single-phase

Volts
Same

220

220

220/240

220

Lock Spacing
Same

4 in

4 in

4 in

4 in

Locking Position (qty.)
Same

15

13

13

14

Time of Full Rise
Same

60 sec.

75 sec.

75 sec.

50 sec.

Drive-Thru Clearance
Same

98.25 in

109 in

109 in

86.5 in

Material
Same

Steel

Steel

Steel

Steel
