BendPak, 20000lb Capacity Clearfloor High-Rise Heavy-Duty, Capacity 20000 lb, Max. Rise 6.9 ft, Horsepower 5 HP, Model# 20AP

Item# 6283718
BendPak, 20000lb Capacity Clearfloor High-Rise Heavy-Duty, Capacity 20000 lb, Max. Rise 6.9 ft, Horsepower 5 HP, Model# 20AP

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

BendPak, 20000lb Capacity Clearfloor High-Rise Heavy-Duty, Capacity 20000 lb, Max. Rise 6.9 ft, Horsepower 5 HP, Model# 20AP

Click or Tap image to Zoom

$24,395.00

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

  • Store Pickup:

    Not available - online only
  • Durable powder coat finish
  • Oversized cable sheave diameter reduces cable fatigue
  • Automatic arm restraints withstand over 2000-pounds of side force
  • Forklift Required
  • Single-point safety release

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Experience unparalleled direct-drive lifting performance with the 20AP two-post lift. This heavy-duty car lift is built with top-of-the-line materials, boasts cutting-edge technology, and features a design that’s ahead of its time. With a lifting capacity of 20,000 lbs., it’s engineered to handle heavy loads with ease, making it a standout choice for automotive professionals seeking reliability and efficiency. In the dynamic world of automotive repair, staying equipped with the latest tools is crucial for keeping pace with evolving technology. BendPak’s AP Series of two-post lifts represents a significant leap forward in car lift engineering. By integrating the finest features from existing lift types, this innovative design sets new industry standards. Built to withstand heavy-duty usage, handle high loads, and prioritize both operator safety and efficiency, the 20AP is truly a standout solution. The 20AP offers unmatched versatility with the convenience of wide or narrow installation options, all packaged into one compact package. This dependable car lift features an expandable top beam and Bi-Metric™ swing arms to accommodate a wide variety of vehicle lifting requirements, whether you need to lift symmetrically or asymmetrically. With its simple yet sophisticated design, it minimizes service and maintenance costs, delivering lower operating expenses and heightened productivity. Automatic Arm Restraint System Prevents Unplanned Movement For decades, swing arms restraints have been integral to two-post lifts, minimizing the risk of arm shifting during vehicle loading and servicing. Despite that, traditional systems often struggle to withstand the considerable forces exerted when vehicles unexpectedly shift on support pads or adapters. This challenge arises from factors like improper loading or the addition/removal of heavy drivetrain components, resulting in an unanticipated shift in the vehicle’s center of balance.

What's Included

    (1) 1 Two Post Lift

Downloads

Product Manual

Features + Benefits

  • Durable powder coat finish
  • Oversized cable sheave diameter reduces cable fatigue
  • Automatic arm restraints withstand over 2000-pounds of side force
  • Forklift Required
  • Single-point safety release
  • Drop-end arms provide a lower pad height
  • Dual hydraulic direct-drive cylinders
  • Electric / hydraulic HVLP power system
  • Self-lubricating dura-glide UHMW polyethylene bearing system
  • Padded overhead safety shutoff bar

Key Specs

AttributeSpecification

item#

6283718

Brand

BendPak

Manufacturer's Warranty

5 year limited warranty

Ship Weight

3466.0 LB

Capacity

20,000 lb

Max. Rise

6.9 ft

Horsepower

5 HP

Motor Phase

Single-phase

Volts

220
AttributeSpecification

Lock Spacing

4 in

Locking Position (qty.)

15

Time of Full Rise

45 sec.

Pad Height

8.75 in

Drive-Thru Clearance

107.87 in

Material

Steel

Product Weight

3426.0000 lb

Dimensions L x W x H (in.)

31.0 x 168.0 x 169.0 in

Reviews

Questions & Answers

Questions

  1. What is the spacing in between for the ID and also what is the minimum height of a wall for the garage you need

    1 answer

    1. The drive thru width is 107.75 inches. The distance between the posts is 126 inches. The distance from the floor to the top switch is 162.5 inches. The overall height of the hoist is 169 inches.

      Helpful?

Warranty

Manufacturer's Warranty

5 year limited warranty
