Ultra-Tow Single-Speed Worm Gear Hand WInch with Hex Drive, 2000-Lb. Load Capacity

Item# 5033506
Ultra-Tow Single-Speed Worm Gear Hand WInch with Hex Drive, 2000-Lb. Load Capacity

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ultra-Tow Single-Speed Worm Gear Hand WInch with Hex Drive, 2000-Lb. Load Capacity

Click or Tap image to Zoom

$124.99

  • Shipping:

  • Store Pickup:

    Not Available
  • 2,000-lb. load capacity
  • Single speed
  • 4.1:1 gear ratio
  • Worm gear drive for smooth operation
  • Worm gear with hex drive can be powered by a drill or wrench

See full description

Complete Your Solution

  • Ultra-Tow Single-Speed Worm Gear Hand WInch with Hex Drive, 2000-Lb. Load Capacity
  • Ultra-Tow Universal Winch Mount
  • Ultra-Tow Polyester Winch Strap, 20ft.L x 2in.W, 5000-Lb. Capacity
Price for all three:

$163.97

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Ultra-Tow Single-Speed Hex Drive Hand Winch features a smooth-operating worm gear drive and is suitable for multiple applications. Hex drive can be powered by a drill or wrench. Handle is easy to assemble and can be secured without a lock nut. Made with 1-piece heat-treated milled gears for durability. The compact, portable winch is simple to operate. Wire rope not included.

What's Included

    (1) Ultra-Tow Single-Speed Worm Gear Hand WInch with Hex Drive (1) Hardware bag

Features + Benefits

  • 2,000-lb. load capacity
  • Single speed
  • 4.1:1 gear ratio
  • Worm gear drive for smooth operation
  • Worm gear with hex drive can be powered by a drill or wrench
  • 8.26in.L handle is easy to assemble; can be secured without requiring a lock nut
  • Fits 5/16in. x 32ft. wire rope (not included)
  • 1-piece heat-treated milled gears
  • Powder-coat finish
  • Compact, portable design
  • Simple operation

Key Specs

AttributeSpecification

item#

5033506

Brand

Ultra-Tow

Manufacturer's Warranty

1 year limited warranty

Ship Weight

7.8 LB

Product Type

Hand Winch

Load Capacity

2,000 lb

Speed Settings

1

Ratchet Type

Gear

Drum Capacity

4.92 ft
AttributeSpecification

Max. Rope Diameter

5/16 in

Gear Ratio

’41:1

Automatic Brake

Yes

Freespooling

No

Mounting Hardware Included

No

For Use With

Used for parallel towing or lifting objects

Product Weight

8.3600 lb

Dimensions L x W x H (in.)

6.89 x 5.91 x 6.5 in

Reviews

Questions & Answers

Questions

1–4 of 4 Questions
Sort by:

  1. WHAT ARE THE DIMENSIONS OF THE MOUNTING BASE

    1 answer

    1. The mounting base measures 5" wide x 5.47" long. There are three mounting holes at the front. The two outer slots measure 15/16" long and are positioned 1-1/8" from each side edge (center to edge). The center hole is 3/8" in diameter and is centered on the base. All three holes are located 9/16" back from the front edge of the base.

      Helpful?

  2. Is there a locking mechanism on the winch?

    1 answer

    1. This winch does feature an automatic brake, but it does not have a lock.

      Helpful?

  3. Can I use nylon rope instead of cable? I want to use this on my boat for an anchor and use with rope.

    1 answer

    1. Nylon rope could be used in place of cable.

      Helpful?

  4. What is the actual gear ratio? It say 4.1:1 then says 41:1?

    1 answer

    1. The gear ratio of this hand winch is 4:1:1.
