TPI Variable Speed Air Curtain - 36in., 2672 CFM, Adjustable Discharge Vanes, 20-Ga. Steel, Model# CF36

Item# 2507585
TPI Variable Speed Air Curtain - 36in., 2672 CFM, Adjustable Discharge Vanes, 20-Ga. Steel, Model# CF36

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

TPI Variable Speed Air Curtain - 36in., 2672 CFM, Adjustable Discharge Vanes, 20-Ga. Steel, Model# CF36

Click or Tap image to Zoom

$1907.20

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Cabinet constructed of 20 gauge rigid steel with baked-on epoxy powder-coat paint for durability
  • Discharge vanes extends the entire width of the unit and are adjustable for optimum performance of air flow
  • Blowers are forward curved centrifugal type, DWDI with corrosion-resistant scroll and wheel
  • Motor is heavy duty, PSC, direct drive high efficiency and designed for use with SCR controller
  • Permanently lubricated for long life and has thermal overload protection

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The TPI Variable Speed Air Curtain is a high-performance solution designed to maintain indoor air quality and temperature by effectively separating indoor and outdoor environments. Measuring 36 inches in width, this air curtain delivers an impressive airflow of 2672 cubic feet per minute (CFM), ensuring robust and consistent air coverage. Constructed from durable 20-gauge steel, it offers long-lasting reliability and can withstand demanding conditions. The adjustable discharge vanes extend the entire length of the curtain, allowing for optimized airflow performance by directing the air precisely where needed. This feature enhances the curtain's efficiency in preventing unwanted air infiltration, thus maintaining a comfortable and controlled indoor climate. Ideal for use in various commercial and industrial settings, the TPI Variable Speed Air Curtain is an essential tool for improving energy efficiency, reducing HVAC load, and enhancing overall comfort and air quality.

What's Included

    (1) Air Curtain

Features + Benefits

  • Cabinet constructed of 20 gauge rigid steel with baked-on epoxy powder-coat paint for durability
  • Discharge vanes extends the entire width of the unit and are adjustable for optimum performance of air flow
  • Blowers are forward curved centrifugal type, DWDI with corrosion-resistant scroll and wheel
  • Motor is heavy duty, PSC, direct drive high efficiency and designed for use with SCR controller
  • Permanently lubricated for long life and has thermal overload protection
  • Has double insulation protection for quieter operation
  • Quick disconnects supplied to accommodate easy installation and service of motor
  • SCR Speed Controller supplied on all units compatible with the motor with low end adjustment for air volume control and savings in power consumption
  • Electric heat option available

Key Specs

AttributeSpecification

item#

2507585

Brand

TPI

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

75.0 LB

Fan Type

Cabinet
AttributeSpecification

Air Delivery

2,672 cfm

Outdoor Rated

No

Volts

120

Horsepower

0.5 HP

Max. Fan Speed

1,659 rpm
