SunStar Heating Products Infrared Ceramic Heater, Natural Gas, 120,000 BTU, Model# SG12-N

Item# 16308
SunStar Heating Products Infrared Ceramic Heater, Natural Gas, 120,000 BTU, Model# SG12-N

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

SunStar Heating Products Infrared Ceramic Heater, Natural Gas, 120,000 BTU, Model# SG12-N

Click or Tap image to Zoom

$616.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Constructed from aluminized steel for corrosion resistance and long life
  • Aluminum reflectors are designed to maximize radiant efficiency
  • Heaters can be angled mounted horizontal and up to 30 degrees
  • The minimum mounting height is 16ft. above finished floor for uniform energy distribution and human comfort
  • Requires the following clearances from any combustible material: 65in. above, 129in. below and 49in. from the sides of the heater

See full description

Complete Your Solution

  • SunStar Heating Products Infrared Ceramic Heater, Natural Gas, 120,000 BTU, Model# SG12-N
  • SunStar Heating Products 24 Volt Thermostat Relay Kit, Model# 43274020
  • SunStar Heating Products 24 Volt Thermostat, Model# 30562000
  • SunStar Heating Products Line Voltage Thermostat, Model# 30348020
Price for all four:

$722.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The SunStar Heating Products Ceramic Heater is ideal for spot heating or area heating of remote locations, farm buildings, shops, service areas, pump houses or other hard-to-heat spaces, providing both fuel efficiency of radiant heat and installation flexibility (not recommended for car washes). This is an energy-saving Direct Spark Ignition heater and can be controlled by a line voltage or 24V thermostat (sold separately). May require the following second stage regulators prior to the heater based on gas supply pressure: A regulator up to 2 PSIG line pressure or a regulator above 2 PSIG line pressure (both sold separately). NOT CERTIFIED OR APPROVED FOR RESIDENTIAL USE. Indoor use only. U.S.A.

NOTE: Please review the detailed Installation Operating Instructions (attached) for other specific installation requirements (gas pressure, ventilation etc) prior to purchasing the heater.

What's Included

    (1) Infrared ceramic heater

Downloads

Product Manual

Features + Benefits

  • Constructed from aluminized steel for corrosion resistance and long life
  • Aluminum reflectors are designed to maximize radiant efficiency
  • Heaters can be angled mounted horizontal and up to 30 degrees
  • The minimum mounting height is 16ft. above finished floor for uniform energy distribution and human comfort
  • Requires the following clearances from any combustible material: 65in. above, 129in. below and 49in. from the sides of the heater
  • The minimum supply gas pressure is 7.0in. Water Column (WC) and the maximum supply pressure is 14in. WC gas pressure
  • If higher gas pressure is supplied, you will need to install a line pressure regulator (sold separately) to reduce it to less than 14in. WC (or 1/2 PSIG)
  • No assembly required
  • Heaters are 100% test-fired prior to shipment
  • CSA design certified

Key Specs

AttributeSpecification

item#

16308

Brand

SunStar

Manufacturer's Warranty

1 year limited warranty

Ship Weight

48.0 LB

Heat Output

120,000 Btu/hour
AttributeSpecification

Heat Type

Infrared

Blower Included

No

Amps

1.2

Thermostat Included

No

Reviews

Questions & Answers

Questions

1–2 of 2 Questions
Sort by:

  1. Is the inlet gas valve available only on one side or is it an option for location?

    1 answer

    1. The SG12‑N has a fixed, non‑reversible gas inlet on one side only.

      Helpful?

  2. Do these have to be an angle mount or can they be hung perfectly horizontally

    1 answer

    1. The heater can be mounted on an angle or horizontally.

      Helpful?
