SHOP FOX Oscillating Benchtop Drill Press - 8 1/2in., 5-Speed, 1/2 HP, 110V, Model# W1667

Item# 49562
SHOP FOX Oscillating Benchtop Drill Press - 8 1/2in., 5-Speed, 1/2 HP, 110V, Model# W1667

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

SHOP FOX Oscillating Benchtop Drill Press - 8 1/2in., 5-Speed, 1/2 HP, 110V, Model# W1667

Click or Tap image to Zoom

$420.00

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • A dust collection fitting helps to keep things clean while working
  • Drum shaft can also act as an oscillating sander
  • Cushioned grip quill handles add operating comfort
  • 1/64in. to 1/2in. chuck capacity holds a wide range of drill bit sizes
  • Effectively drills mild steel up to 1/2in. thick

See full description

Complete Your Solution

  • SHOP FOX Oscillating Benchtop Drill Press - 8 1/2in., 5-Speed, 1/2 HP, 110V, Model# W1667
  • 3M SecureFit Safety Glasses, Clear Lens, Model# SF400C-LV-4-PS
  • Radians Earplug Neckband, NRR 25dB, Orange, Model# RB2120
  • Milwaukee Men's Cut 1 Nitrile Utility Gloves, Red/Black, Large, Model# 48-22-8902
Price for all four:

$443.45

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This 8 1/2in. SHOP FOX® Oscillating Benchtop Drill Press is a compact, versatile bench-top unit with oscillating spindle that can be used as both a drill press and an oscillating sander to give you 2 machines in half the space. Ideal for use in almost any situation from small hobby shops to professional machine shops. Some assembly required. Cannot ship to AK, CA or HI.

What's Included

    (1) Drill press and set of hardware

Downloads

Product Manual

Features + Benefits

  • A dust collection fitting helps to keep things clean while working
  • Drum shaft can also act as an oscillating sander
  • Cushioned grip quill handles add operating comfort
  • 1/64in. to 1/2in. chuck capacity holds a wide range of drill bit sizes
  • Effectively drills mild steel up to 1/2in. thick
  • Powerful 1/2 HP, 110V motor with 5 speeds for versatility that can handle a variety of projects
  • Range of speeds: 620-3100 RPM
  • Sturdy adjustable height worktable measures 7in.L x 7in.W to offer plenty of operating room

Key Specs

AttributeSpecification

item#

49562

Brand

Shop Fox

Manufacturer's Warranty

2 year limited warranty

Ship Weight

54.0 LB

Horsepower

0.5 HP

Volts

110

Max. Speed

3,100 rpm

360 Degree Head Swivel

Yes

Speeds (qty.)

5

Product Type

Drill Press
AttributeSpecification

Drilling Capacity

1/2 in

Chuck Size

1/2 in

Light Included

No

Stand Included

No

Variable Speed

No

Max. Spindle Distance

11 in

Swing

8.5 in

Product Weight

lb

Dimensions L x W x H (in.)

17.0 x 9.0 x 23.0 in

Reviews

Questions & Answers

32 Reviews This action will navigate to reviews.

Questions

1–10 of 13 Questions
Sort by:

  1. can a drill chisel be used with this press?

    1. This drill press is too small to use with a drill chisel. Please see the 1 HP option, item 426423, this will work with a drill chisel.

      Helpful?

    2. This drill press is only a 1/2 HP, for a more heavy-duty drill press that would work with a drill chisel see my recommendations below.

      Helpful?

  2. Picture shows a stand, specs say no stand. Which is it?

    8 1/2" drill press. Key Specs-stand include? No. Picture shows stand. How do you support the drill and motor without a stand?

    1. Has the stand as pictured. recommend bolting base to bench to keep press from flipping over if you were drilling and bit seized in work piece.

      Helpful?

    2. The stand is included with the Drill Press.

      Helpful?

  3. this picture looks as though it has a radial arm

    1. Does not have a radial arm.

      Helpful?

    2. The Shop Fox Oscillating Drill Press Model #W1667 does not have radial arm (photo error that is being corrected). Shop Fox Model #W1669 which is Northern Tool Item #49563 is a radial arm Drill Press.

      Helpful?

  4. How does the chuck attach and secure to the spindle? Is it just a press on by purchaser or is it mechanically attached?

    1 answer
    Originally posted on grizzly.com

    1. Thank you for your question. The chuck is fastened in place using an M5-.8 x 20 cap screw that threads into the spindle.

  5. Is it possible to buy parts to add a Rack and Cranking Table

    1 answer
    Originally posted on grizzly.com

    1. We appreciate you reaching out. Grizzly does not offer a replacement for the existing table.

  6. Overall height of drill press

    1 answer
    Originally posted on grizzly.com

    1. Thank you for reaching out. The drill press dimensions are (W × D × H): 9" × 17" × 23".

  7. Where would I get a drill chuck key for a shopfox bench top drill model# w1667

    1 answer

    1. The drill chuck key is part number PX1667056 and can be purchased through the manufacturer directly.

      Helpful?

  8. Can this be used for mortising

    1 answer
    Originally posted on grizzly.com

    1. We appreciate your inquiry. The drill press lacks the necessary sturdiness to withstand the force required for making a mortise. There is a high risk of damaging or breaking the pinion shaft or the handle shafts while attempting to do so.

  9. is there a work light accessory for the fox 81/2 inch drill press

    1 answer
    Originally posted on grizzly.com

    1. We appreciate your question. You might consider looking at the T33680. This magnetic gooseneck LED light has a magnetic base and can be placed on the side of the headstock and adjusted in many positions.

  10. Who is manufacturer

    1 answer

    1. The press is manufactured in China for Shop Fox.

      Helpful?
