This SHOP FOX Mini Lathe can cut standard threads of 16,18,19,20 and 24 TPI (threads per inch).
SHOP FOX Mini Metal Lathe - 6in. x 10in., 3in. Chuck, Model# M1015
This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.
Click or Tap image to Zoom
$839.00
- 3in. chuck with internal and external jaws
- Swing over bed: 6in.
- Distance between centers: 10in.
- Cross slide travel: 2 3/8in.
- Spindle: 1-8 TPI RH; Spindle bore: 0.375in.
See full description
Price for all two:
$844.47
-
What kind or threading can you do with this lathe?
-
Helpful?
-
The Model M1015 lathe can cut threads (standard) of 16, 18, 19, 20, and 24 threads per inch (TPI).
Helpful?
-
-
Is there a drill chuck avialable for this lathe
-
The chuck for this is no longer available through Northern Tool. Please contact the mfg. directly for parts assistance.
Helpful?
-
The Shop Fox mini lathe does come with a lathe chuck, any additional chucks can be ordered through our parts department at 1-800-222-5381.
Helpful?
-
-
Is this 110 volt or 220 volt?
1 answer-
The mini metal lathe is 110 volt 60 Hz AC power.
Helpful?
-
-
carriage lock?
1 answer-
The Mini Metal Lathe does not have a carriage lock.
Helpful?
-
-
What is the smallest diameter rod that the chuck can clamp?
1 answer-
The 3 jaw chuck on this Shop Fox lathe can work with material from 0.0 to 2 inches.
Helpful?
-
-
What are the overall dimensions of this machine? Height, width,length?
1 answer-
The Shop Fox Mini Lathe has an overall length of 27.5 inches, width of 14.25 inches and a height of 13 inches.
Helpful?
-
-
Do you sell replacement chuck guards for this lathe?
1 answer-
Replacement chuck guards would need to be purchased through the manufacturer.
Helpful?
-
-
Is item # 334983 a metal lathe?
1 answer-
The Shop Fox mini lathe is designed to machine small metal parts.
Helpful?
-
-
What is this lathe's distance over the saddle( cross-slide)?
1 answer-
The swing over the bed is 6". The distance between the centers is 10". The swing over the saddle is 5". The cross slide is 4 1/8".
Helpful?
-
-
tooling
do you have a cutting tool kit for this lathe ????????????
1 answer-
The cutting tool kit for this mini lathe can be purchased through the manufacturer.
Helpful?
-
Accessories We Recommend
This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.
See All Lathes
See All Shop Fox Lathes
Currently Viewing This Product
Item # 7074192
$77,999.99
Specifications
Specifications
SHOP FOX Mini Metal Lathe - 6in. x 10in., 3in. Chuck, Model# M1015
GH-1640ZX, Large Spindle Bore Gear Head Lathe w/ Acu-Rite 203 DRO
GH-2680ZH, Large Spindle Bore Gear Head Lathe w/ Newall NMS800 and Taper Attachment Kit
GH-1640ZX, Large Spindle Bore Gear Head Lathe w/ Acu-Rite 203, CC
Horsepower
Same
0.2 HP
10 HP
15 HP
10 HP
Volts
Same
110
230V/460V
230
230V/460V
Distance Between Centers
Same
10 in
40 in
80 in
40 in
Swing Over Bed
Same
6 in
16 in
26 in
16 in
Product Type
Same
Mini Lathe
Other
Other
Other
Carriage Travel
Same
10 in
0 in
117.5 in
0 in
Phase
Same
Single-phase
Three-phase
Three-phase
Three-phase
Variable Speed
Same
Yes
Yes
Yes
Yes
Max. Speed
Same
2,000 rpm
1,500 rpm
1,000 rpm
1,500 rpm
Spindle Mount
Same
No
Yes
Yes
Yes
Spindle Bore Size
Same
0.375 in
3.125 in
4.5 in
3.125 in
Stand Included
Same
No
-
-
-
Dimensions L x W x H (in.)
Same
27.75 x 11.5 x 12 in
94.5 x 45.5 x 74.8 in
142.1 x 45.3 x 77.2 in
94.5 x 45.5 x 74.8 in
Product Weight
Same
-
4299.0000 lb
6724.0000 lb
4299.0000 lb
