Ruffneck CR1 Triton Washdown Unit Heater - 600V, 39kW, 133,068 BTU, Forced Air, Corrosion-Resistant, Model# CR1-600360-390-T

Item# 5092637
Ruffneck CR1 Triton Washdown Unit Heater - 600V, 39kW, 133,068 BTU, Forced Air, Corrosion-Resistant, Model# CR1-600360-390-T

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ruffneck CR1 Triton Washdown Unit Heater - 600V, 39kW, 133,068 BTU, Forced Air, Corrosion-Resistant, Model# CR1-600360-390-T

Click or Tap image to Zoom

$6379.99

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Washdown Unit Heater c/w T'stat - 600V 3Ø 39kW
  • Ruffneck™ CR1 Triton™ Series is a new generation of NEMA 4X corrosion-resistant washdown heaters. The first UL-listed Type 4X heater with models ranging from 3 kW to 39 kW.
  • IMPORTANT: Ruffneck™ CR1 heaters are suitable for non-hazardous locations only. For washdown applications use water pressure of less than 70 psi.
  • The entire heater is NEMA Type 4X
  • Epoxy-coated fan blade

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The Ruffneck CR1 Triton Washdown Unit Heater is a powerful and durable heating solution designed for non-hazardous locations where corrosion resistance is crucial. Operating at 600V with a robust 39kW output, this heater can produce up to 133,068 BTUs of forced air, ensuring efficient and consistent heating performance. Engineered to withstand challenging environments, the CR1 Triton features a corrosion-resistant construction, making it ideal for applications that involve water pressure of less than 70 psi. Whether used in washdown areas or other demanding settings, this unit heater delivers reliable warmth and durability, providing peace of mind and optimal functionality in maintaining comfortable temperatures.

What's Included

    (1) Washdown Unit Heater c/w T'stat - 600V 3Ø 39kW

Downloads

Additional Product Info

Features + Benefits

  • Washdown Unit Heater c/w T'stat - 600V 3Ø 39kW
  • Ruffneck™ CR1 Triton™ Series is a new generation of NEMA 4X corrosion-resistant washdown heaters. The first UL-listed Type 4X heater with models ranging from 3 kW to 39 kW.
  • IMPORTANT: Ruffneck™ CR1 heaters are suitable for non-hazardous locations only. For washdown applications use water pressure of less than 70 psi.
  • The entire heater is NEMA Type 4X
  • Epoxy-coated fan blade
  • 16-gauge stainless-steel cabinet
  • Custom-configured stainless-steel elements
  • Optional built-in accessories
  • Stainless-steel wall/ceiling mounting kit
  • 120 V controls
  • Stainless-steel temperature high-limit
  • Increased safety and protection against water penetration
  • Added corrosion protection
  • Better resistance to corrosion for longer life
  • Improved heat distribution and corrosion protection
  • Flexibility and reduced field installation costs
  • Flexible options for mounting heater
  • Better contactor pull-in reliability
  • Increased safety and reliability

Key Specs

AttributeSpecification

item#

5092637

Brand

Ruffneck

Manufacturer's Warranty

1 year limited warranty

Ship Weight

180.0 LB

Heat Type

Forced Air

Heat Output

133,068 Btu/hour

Hardwired

Yes

Indoor-Outdoor Use

Indoor

Volts

600

Watts

39,000

Amps

48.1
AttributeSpecification

Assembled Width

20.75 in

Assembled Height

32.25 in

Assembled Depth

23.5 in

Needs Direct Venting

No

Remote Included

No

Tip-Over Safety Switch

No

Blower Included

Yes

Blower CFM

2,100 cfm

Oscillating

No

Product Weight

130.0000 lb

Dimensions L x W x H (in.)

23.5 x 20.75 x 32.25 in
