Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 4in. Bore, 16in. Stroke, 2in. Shaft, Model# PMC-5616

Item# 905616
Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 4in. Bore, 16in. Stroke, 2in. Shaft, Model# PMC-5616

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Prince Welded Tee Hydraulic Cylinder, 2,500 PSI, 4in. Bore, 16in. Stroke, 2in. Shaft, Model# PMC-5616

Click or Tap image to Zoom

$579.99

  • Shipping:

    Available now

  • Store Pickup:

    Not available - online only

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Universal end mountings. A favorite for contractors, industrial, and agricultural applications. All steel welded construction: weld-on cross tube. Heavy wall steel tubing, ground and polished chrome piston rod with pin eye, cast iron piston. O-rings and back up washers, trac-type gland retainer. Maximum working PSI is 2,500, bursting PSI is 5,000. 2 1/2in. bore cylinders have 3/4in. pin holes. The 3in. and 3 1/2in. bore cylinders have 1in. pin holes. The 4in. bore cylinders have 1 1/4in. pin holes. 2 1/2in. bore cylinders have 3/8in. working ports. The rest have 1/2in. working ports. Double acting. U.S.A.

Key Specs

AttributeSpecification

item#

905616

Brand

Prince

Manufacturer's Warranty

3 year limited warranty

Ship Weight

51.0 LB

Max. PSI

2,500
AttributeSpecification

Bore Diameter

4 in

Stroke Length

16 in

Shaft Diameter

2 in

Closed Pin Center

25 in

Reviews

Questions & Answers

Questions

1–2 of 2 Questions
Sort by:

  1. what kind of fluid does it take ?

    1 answer

    1. ATF (Automatic Transmission Fluid) is the fluid that is recommended to use with any hydraulic system.

      Helpful?

  2. I need the width of the connectors (where the pin goes in) on both the base and rod end of the cylinder

    1 answer

    1. The rod end width is 2 inches and base end width is 4 1/2 inches.

      Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty
