Prince Tie-Rod Hydraulic Cylinder, 3,000 PSI, 5in. Bore, 8in. Stroke, 2in. Shaft

Item# 9035008
"Prince Tie-Rod Hydraulic Cylinder, 3,000 PSI, 5in. Bore, 8in. Stroke, 2in. Shaft"
Prince Tie-Rod Hydraulic Cylinder, 3,000 PSI, 5in. Bore, 8in. Stroke, 2in. Shaft

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Prince Tie-Rod Hydraulic Cylinder, 3,000 PSI, 5in. Bore, 8in. Stroke, 2in. Shaft

Click or Tap image to Zoom

$529.99

  • Shipping:

    Available now

  • Store Pickup:

    Not available - online only
  • Honed tubing
  • 1 1/4in. pins (included)
  • SAE 7/8 - 14 working ports
  • Induction hardened piston rods

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Prince Tie-Rod Hydraulic Cylinder is a heavy-duty double-acting tie-rod cylinder rated for 3,000 PSI continuous working pressure to handle demanding applications. Features high-strength ductile iron piston, butt, gland, and clevis, plus urethane seals in a honed tube for dependable performance. Aircraft-quality paint offers exceptional durability. Has high-quality urethane seals and SAE O-ring boss style ports. Includes Clevis and cotter pins for easy installation.

What's Included

    (1) Tie-rod cylinder

Downloads

Product Manual

Features + Benefits

  • Honed tubing
  • 1 1/4in. pins (included)
  • SAE 7/8 - 14 working ports
  • Induction hardened piston rods

Key Specs

AttributeSpecification

item#

9035008

Brand

Prince

Manufacturer's Warranty

3 year limited warranty

Ship Weight

73.4 LB

Max. PSI

3,000
AttributeSpecification

Bore Diameter

5 in

Stroke Length

8 in

Shaft Diameter

2 in

Closed Pin Center

20.25 in

Reviews

Questions & Answers

16 Reviews This action will navigate to reviews.

Questions

1–5 of 5 Questions
Sort by:

  1. How many tons would it push if I put it on a forging press?

    1 answer

    1. The column load is 58,900 pounds.

      Helpful?

  2. What is the length of this cylinder in the closed position

    1 answer

    1. The length of the cylinder when retracted is 20.25".

      Helpful?

  3. Is this a double acting cylinder?

    1 answer

    1. This can operate as either a single or double acting cylinder depending on how it is hooked up to a hydraulic system.

      Helpful?

  4. What fitting would I need to connect to 1/2" NPT high pressure hydraulic hose?

    1 answer

    1. The fitting would be a 7/8-14 NPTF SAE Boss-O Ring x 1/2 NPT M SAE Boss O-Ring Adapter.

      Helpful?

  5. What is the part number of this part number from Prince? I would like to determine the dimensions.

    1 answer

    1. The manufacturers model # is F500080ACDDA07B.

      Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty
