METALpro Ironworker, 40-Ton, Foot Switch Control, Model# MP4000FS

Item# 9716621
"METALpro Ironworker, 40-Ton, Foot Switch Control, Model# MP4000FS"
METALpro Ironworker, 40-Ton, Foot Switch Control, Model# MP4000FS

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

METALpro Ironworker, 40-Ton, Foot Switch Control, Model# MP4000FS

Click or Tap image to Zoom

$4488.75

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Country of Origin - USA
  • 40 Ton Capacity
  • 3 year Warranty
  • Flat Bar Shear Capacity - 1/4" x 6", 3/8" x 4"
  • Angle Iron Shear Capacity - 1/4" x 3" x 3

See full description

Complete Your Solution

  • METALpro Ironworker, 40-Ton, Foot Switch Control, Model# MP4000FS
  • METALpro Sheet Metal Brake, 8in., Model# MP4110
  • METALpro 8-Pc. Round Punch & Die Set, Model# MP4142
  • METALpro 8-Pc. Round Punch & Die Set, Model# MP4144
Price for all four:

$6107.25

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The MP4000FS is a 40-ton Ironworker, powered by a 110V, single phase standard wall outlet or generator. Its compact, sturdy design boasts 40 tons of pressure at the punch station and 20 tons of pressure at the central workstation. This allows the user to punch a 3/4” round hole through 1/2” mild steel (capable of larger holes through thinner mild steel). METALpro’s footswitch design controls a hydraulic power system. This machine comes standard equipped with METALpro’s 6in., 3in. 1 combination shear. The shear consists of a flat bar shear, angle iron shear and round/square rod shear, built into one singular unit. METALpro stands behind their machines with a one-year limited manufacturing warranty. All METALpro machines and accessories are proudly made in the USA and built to last.

What's Included

    (1) Ironworker

Downloads

Product Manual Product Manual2
Additional Product Info

Features + Benefits

  • Country of Origin - USA
  • 40 Ton Capacity
  • 3 year Warranty
  • Flat Bar Shear Capacity - 1/4" x 6", 3/8" x 4"
  • Angle Iron Shear Capacity - 1/4" x 3" x 3
  • Rod Shear Capacity - 3/4"
  • Forming Capacity - Up to 1/2" Mild Steel (brake sold separately)
  • Punch Capacity - Up to 1/2" Mild Steel
  • 110/120V Single Phase
  • 1.5 horsepower
  • Hydraulic Pressure - 2900psi
  • Throat Depth - 3-3/4"
  • Operating Weight - 475 lbs
  • Machine Dimensions - 24" x 30.5" x 58"
  • OSHA/ASNI B11-8 Approved
  • Comes Standard with 8" 3 in 1 Combination Shear

Key Specs

AttributeSpecification

item#

9716621

Brand

Metal Pro

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

510.0 LB

Horsepower

1.5 HP

Volts

110

Phase

Single-phase

Hydraulic Pump Speed

300 GPM

Valve Pressure

2,900 PSI

Foot Switch Control

Yes

Throat Depth

3.75 in
AttributeSpecification

Punching Pressure

40 Tons

Reservoir Size

1.5 Gal

Flat Bar Shear Capacity

0.38 in

Square/Round Shear Capacity

0.75 in

Angle Shear Capacity

0.25 in

Coper Notcher Capacity

Pipe notcher capacity: 1/2in.–2in. Sch. 40 pipe

Amps

20

Portable

Yes

Product Weight

435.0000 lb

Dimensions L x W x H (in.)

30.0 x 24.0 x 55.25 in

Reviews

Questions & Answers

3 Reviews This action will navigate to reviews.

Questions

1–4 of 4 Questions
Sort by:

  1. Are other diameter punches and dies available for this machine

    1 answer

    1. Please see item #971668 and #971669 for different sized dies and punches.

      Helpful?

  2. shear blade sharping

    can the shear be tightened up and blades be sharpened????

    1 answer

    1. The shear on this unit can be tightened up and the blades can be sharpened as well.

      Helpful?

  3. what is the difference in the fs model and the standard? And whats the life on the punches and shear?

    what is the difference in the fs model and the standard? And whats the life on the punches and shear?

    1 answer

    1. The standard model features a hand lever float valve. The FS differs because it has a foot operated switch plus it also features a larger motor. The life expectancy can vary depending on type and thickness of material, however people have been known to get thousands of holes punched with the shears and punches.

      Helpful?

  4. Do the die's for notching angle iron come with the unit. What notching and bending can be done without accessory packages?

    1 answer

    1. No die's included, must purchase separately. No bending can be done, must buy brake separately, This will shear flat bar, angle iron, round and square stock. Optional items: 8" brake, pipe notcher and metal pro notcher 1/4X3/4X2" . See recommendation below.

      Helpful?
