MAXair Premium Wheelbarrow Air Compressor, 22 CFM, 9 HP, 10-Gal. Tank, 170 PSI, Honda Engine, Model# TT90G + MAP

Item# 6104038
MAXair Premium Wheelbarrow Air Compressor, 22 CFM, 9 HP, 10-Gal. Tank, 170 PSI, Honda Engine, Model# TT90G + MAP

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

MAXair Premium Wheelbarrow Air Compressor, 22 CFM, 9 HP, 10-Gal. Tank, 170 PSI, Honda Engine, Model# TT90G + MAP

Click or Tap image to Zoom

$2399.99

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Durable Twin Cylinder Cast Iron Pump
  • Two Year Commerical Warranty
  • Fuel Saving Idle Control
  • Extended Oil drain for Easy Service
  • 22 CFMs @ 100 psi

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The MAXair Premium TT90G+MAP wheelbarrow style compressor sets the standard in it's class! Producing 22 CFM's of air flow is just one of the features that sets this unit apart. The unit is powered by a reliaable GX270 OHV Honda engine paired with a durable "V" style cast iron 170 psi compressor head that reduces heat friction by runing slower therefore increasing the life of this unit vereses most of the competitiors. Features like extend oil drains, liquid filled gauges, extended tank drains, and automotive style air filters takes the hassle out service and maintentance on the unit. With more than enough air to operate high demand air tools, this unit will support 6 to 8 pnuematic nail guns or has enough power to get your constuction or farm equipment up and going faster when needed. Our "Premium Promise" gives you an unrivaled 2 year warranty even for commerical applications. With extra features like triple quick connects, a 1/2in. ball valve outlet and fuel saving idle control, this unit will hit your truck ready to perform. . . . MAXair is MORE!

What's Included

    (1) AIR COMPRESSOR

Downloads

Product Manual
Play Item Video

Features + Benefits

  • Durable Twin Cylinder Cast Iron Pump
  • Two Year Commerical Warranty
  • Fuel Saving Idle Control
  • Extended Oil drain for Easy Service
  • 22 CFMs @ 100 psi
  • Liquid Filled Pressure gauge
  • "V" Style Pump Improves Cooling & Minimizes Vibration
  • Industry Leading 10 Gallon Tank
  • Reliable GX270 OHV Honda Engine
  • Automotive Style Filters
  • Assembled in the USA!

Key Specs

AttributeSpecification

item#

6104038

Brand

MAXair

Manufacturer's Warranty

2 year limited warranty

Ship Weight

303.0 LB

Horsepower

9 HP

Air Tank Size

10 Gal

Engine Brand

Honda

CFM at 90 PSI

22

Max. PSI

170

Stage

1

Air Outlets (qty.)

4

Duty Cycle

100 %

Motor RPM

3,600

Working Pressure

120-150 PSI
AttributeSpecification

Engine Displacement

198 cc

Engine Start Type

Manual

Pump Material

Cast Iron

Pump Drive

Belt

Air Outlet Size

1/2 in. NPT

Oil Required

Yes

Low Oil Shutdown

Yes

Lubrication System

Splash

Pressure Gauge

Yes

Drain Type

Ball Valve

Tank Orientation

Horizontal

Engine Model

GX270 HONDA

Product Weight

215.0000 lb

Dimensions L x W x H (in.)

45.0 x 18.0 x 28.0 in

Reviews

Questions & Answers

Questions

  1. What size hole come out of the tanks? Is it all 1/2" it looked like it went from 1/4" to 1/2" for some reason.

    1 answer

    1. The M-style fitting sizes on this compressor are all 1/2".

      Helpful?

Warranty

Manufacturer's Warranty

2 year limited warranty
