Ironton 8in. Benchtop Drill Press, 8in., 1/3 HP, 5 Speeds

Item# 49381
"Ironton 8in. Benchtop Drill Press, 8in., 1/3 HP, 5 Speeds"
Ironton 8in. Benchtop Drill Press, 8in., 1/3 HP, 5 Speeds

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ironton 8in. Benchtop Drill Press, 8in., 1/3 HP, 5 Speeds

Click or Tap image to Zoom

$99.99

  • Shipping:

    Available now
    $19.99 Same Day

  • Store Pickup:

    1 in stock at Fredericksburg VA - Pickup in under 1 hr

  • 1/2in. chuck capacity with 1/2in. maximum drilling capacity
  • 2in. vertical stroke
  • 8in. swing adds versatility
  • Depth lock with a ball knob handle for precise adjustments that stay true hole after hole
  • Roomy 6-5/16in. x 6-5/16in. worktable

  • Prop 65 Warning: See Details

See full description

Complete Your Solution

  • Ironton 8in. Benchtop Drill Press, 8in., 1/3 HP, 5 Speeds
  • Milwaukee Men's Cut 1 Nitrile Utility Gloves, Red/Black, Large, Model# 48-22-8902
  • 3M SecureFit Safety Glasses, Clear Lens, Model# SF400C-LV-4-PS
  • Radians Earplug Neckband, NRR 25dB, Orange, Model# RB2120
Price for all four:

$123.44

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This Ironton 8in. Benchtop Drill Press is a compact yet powerful bench-mount press that delivers precision drilling and pinpoint accuracy. Features a 1/3 HP, 120V motor with 5 speeds that generate 740–3140 RPM. A great choice for the home hobbyist.

What's Included

    (1) Drill press (1) Chuck key (1) Allen key

Downloads

Product Manual
Play Item Video

EFFICIENT PERFORMANCE

Equipped with a POWERFUL MOTOR and MULTIPLE SPEED options, this drill press handles various materials and thicknesses, making it ideal for creating PRECISE HOLES and SMOOTH FINISHES


PRECISION DRILLING

The Ironton® BENCHTOP DRILL PRESS is an essential tool for home hobbyists, offering reliable and accurate drilling with its finely ADJUSTABLE SPEED SETTINGS and STABLE DESIGN


USER-FRIENDLY FEATURES

Depth adjustments are made easy with a simple turn of the BALL KNOB HANDLE, ensuring each hole is drilled to the exact depth required, while the BUILT-IN CHUCK KEY STORAGE provides convenience and saves time

Features + Benefits

  • 1/2in. chuck capacity with 1/2in. maximum drilling capacity
  • 2in. vertical stroke
  • 8in. swing adds versatility
  • Depth lock with a ball knob handle for precise adjustments that stay true hole after hole
  • Roomy 6-5/16in. x 6-5/16in. worktable
  • 18-1/8in.L x 8-1/4in.W x 23-1/4in.H overall size (450mm x 190mm x 595mm)
  • Built-in chuck key storage keeps the chuck close at hand and easy to find
  • 5 speeds under 60 Hz power: 740 RPM, 1,100 RPM, 1,530 RPM, 2,100 RPM, 3,140 RPM; 5 speeds under 50 Hz power: 620 RPM, 920 RPM, 1,280 RPM, 1,750 RPM, 2,620 RPM
  • 2.3 Amps
  • 1.8ft.L, 18 AWG3 cord

Key Specs

AttributeSpecification

item#

49381

Brand

Ironton

Manufacturer's Warranty

1 year limited warranty

Ship Weight

37.0 LB

Horsepower

0.3 HP

Volts

120

Max. Speed

3,140 rpm

360 Degree Head Swivel

No

Speeds (qty.)

5
AttributeSpecification

Product Type

Drill Press

Vertical Stroke

2 in

Drilling Capacity

1/2 in

Light Included

No

Stand Included

Yes

Variable Speed

No

Swing

8 in

Product Weight

lb

Dimensions L x W x H (in.)

18.12 x 8.25 x 23.25 in

Reviews

Questions & Answers

76 Reviews This action will navigate to reviews.

Questions

1–10 of 21 Questions
Sort by:

  1. Will this work for metal?

    Can this drill through metal? I am looking for a smaller drill press that can be used with up to half inch steel and brass.

    1. This drill press is designed to drill a variety of metals such as steel, brass, cast iron and aluminum. Please see our item #42091 for a set of metal drilling bits.

      Helpful?

    2. Yes... just feed slowly. Don’t slam the press down into the work, otherwise you’ll bog the motor.

      Helpful?

    3. This drill press is designed to drill a variety of metals such as steel, brass, cast iron and aluminum. Please see our Product Recommendations below for metal drilling bits.

      Helpful?

  2. Can this be used to drill through beach stones and beach glass?

    1. This unit can be used on a wide variety of materials. Most beach stone and glass require a high RPM machine such as a rotary tool like our item #4975139. Please follow the material recommended speed requirements and follow all safety instructions.

      Helpful?

    2. Yes, first you’ll need to stake a dimple on the work to prevent cracking and prevent the drill bit from creeping when you initially engage the work piece. You will need to research what the proper bit is needed for the material and remember to feed the chuck slowly into the work. Feeding the bit slowly does not imply a slow drill speed. You will need to look at the recommended drill speed setting (you can find it online) which depends on the work material (glass, stone or granite). Feed rate must be slow for this specific machine (lots of in and out of the chuck and clearing/blowing clean the bit while you’re drilling) while using a cooling fluid (water spray) during drilling.

      Helpful?

    3. This unit can be used on a wide variety of materials. Most beach stone and glass require a high RPM machine such as the Product Recommendation below. Please follow the material recommended speed requirements and follow all safety instructions.

      Helpful?

  3. How do you change speeds

    1 answer

    1. To adjust the speed, loosen the belt tension lock knob. Pull the motor toward the front to reposition the belt on the desired pulley. Once the belt is in place, push the motor toward the rear to tighten the belt and secure it by tightening the belt tension lock knob.

      Helpful?

  4. How solid is the drill stop? Is it spongy or accurate ? I am looking for a small press that will be accurate for trimming brass. It does need to stop at the same spot repeatedly ?

    1 answer

    1. The drill has a solid stop so it will accurately and consistently stop at the same spot.

      Helpful?

  5. Is there a specific square hole drill bit adapter that works with this drill?

    1 answer

    1. Ironton does not manufacturer a square hole drill adapter for the drill press. You may use another brand of square hole adapter on the press. You will need to use an external stand to connect.

      Helpful?

  6. What are the overall dimensions?

    1 answer

    1. The overall dimensions are 18.12" L x 8.25" W x 23.25" H.

      Helpful?

  7. Does the table tilt?

    1 answer

    1. The table will tilt. Loosen the hex bolt below the table. Rotate the table to the desired angle shown on the scale. Then, tighten the hex bolt to secure the table tilt.

      Helpful?

  8. I want to drill 4 to 6" into sides of 1 x 6 or 1x8* shelving for "hidden shelving" installations. How deep can I drill a continued hole ? I read that the vertical distance the drill can travel in 2" is this correct ?

    1 answer

    1. The drilling capacity is 1/2" diameter. That is the recommended maximum hole size. The vertical stroke distance is 2". With the table and material raised up, the maximum cutting depth would be just less than 2".

      Helpful?

  9. Is the gear shaft available as a spare part?

    1 answer

    1. The gear shaft/handles, part #IRN49381-43, is available through our sister company, Jacks Small Engines. Please visit www.JacksSmallEngines.com for pricing and availability.

      Helpful?

  10. what is the quill taper?

    1 answer

    1. The spindle quill has JT (Jacobs Taper) 33 Taper.

      Helpful?
