Ingersoll Rand Air Compressor Pump, Single-Stage, 3 HP, Model# SS3

Item# 404803
Ingersoll Rand Air Compressor Pump, Single-Stage, 3 HP, Model# SS3

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ingersoll Rand Air Compressor Pump, Single-Stage, 3 HP, Model# SS3

Click or Tap image to Zoom

$618.99

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

  • Store Pickup:

    Not available - online only
  • For use with Item#s 1592060, 1592058, 1592059 and 1592027
  • Cast iron frame and cylinder
  • Splash lubrication (pump requires oil, #1592005, sold separately)
  • Includes pump, filter and flywheel

See full description

Complete Your Solution

  • Ingersoll Rand Air Compressor Pump, Single-Stage, 3 HP, Model# SS3
  • Ingersoll Rand T-30 Select Compressor Oil, 1 Liter Bottle
Price for all two:

$662.98

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Ingersoll Rand Air Compressor Pump, is an industrial-class single-stage replacement pump designed for Ingersoll Rand air compressors. Engineered to deliver unmatched reliability and performance, this pump operates with a robust 3 HP motor, ensuring efficient and consistent air compression for various applications. Built with high-quality materials and precision craftsmanship, it is ideal for demanding environments where durability and dependability are crucial. Whether used in workshops, manufacturing facilities, or other professional settings, the Ingersoll Rand Air Compressor Pump offers superior functionality and long-lasting service, making it a trusted choice for professionals seeking excellence in air compression technology.

What's Included

    (1) Ingersoll Rand Single-Stage Air Compressor Pump -- 3 HP

Features + Benefits

  • For use with Item#s 1592060, 1592058, 1592059 and 1592027
  • Cast iron frame and cylinder
  • Splash lubrication (pump requires oil, #1592005, sold separately)
  • Includes pump, filter and flywheel

Key Specs

AttributeSpecification

item#

404803

Brand

Ingersoll Rand

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

51.0 LB

Stage

1
AttributeSpecification

Max. Horsepower

3

Max. PSI

135

Product Weight

lb

Dimensions L x W x H (in.)

12.0 x 13.0 x 15.0 in

Reviews

Questions & Answers

13 Reviews This action will navigate to reviews.

Questions

1–10 of 16 Questions
Sort by:

  1. Can I hook up a 5hp motor to this compressor?

    1. The correct unit for a 5 HP motor is our pump item 404804.

      Helpful?

    2. Yes, I used the motor off a 5hp "Sears" oil less noisy compressor and it has no problems whatsoever, I reach full compression in a 30 gal reservoir in just over 4 minutes. My flywheel runs 811 RPM after using the smallest pulley I had off the 3400 RPM motor.

      Helpful?

    3. Yes you will have an extra 2 HP that will not harm the unit at all, also you will spend a little more in electricity, remember that the cost of the electricity will be for the time you will work with your compressor, those 2 extra HP will need to be fed and they will rise the electricity bill each month, than the 3 HP.
      Go with the 5 HP and change it whenever you can in order to save in electricity bill, the 5 HP will do the work as well as the 3 HP.

      Helpful?

  2. Gas Powered?

    Can this pump be used with a gas powered engine?

    1. yes

      Helpful?

    2. This Ingersoll Rand pump can be used with a gas engine to power it. You would need a 5 HP gas engine.

      Helpful?

  3. Rotation?

    Is the pump directional,or can it be operated CW-CCW?Also what are the recommendations for the breaking in of this pump?Thanks!

    1. This pump is directional, I would have to go watch mine run to give you a definitive answer. This is a very good rugged pump and I would recommend that you figure out a motor solution if your motor happens to run the wrong way, this pump is that good.

      As far as the break in procedure goes, they do include the procedure in the package, which is a well built wooden crate. My pump was broken in by running it free-wheel [no piping] for 20 minutes and then oil change.

      I tied in a line voltage "Hobbs" meter to record the accumulative running hours for my 20 hour oil changes.

      Helpful?

    2. It can only go one direction which is CCW. It is recommended to fill the pump with oil and open up the valve and let it vent to the atmosphere for about 10 minutes. Then shut off the valve and let it build the air pressure.

      Helpful?

  4. What is center of mounting holes

    1 answer

    1. The center to center mounting hole will be 5''.

      Helpful?

  5. What is the flywheel diameter?

    1 answer

    1. The flywheel diameter on this air compressor pump is 12.8".

      Helpful?

  6. What is the difference between a SS3 and a SS4 compressor pump

    1 answer

    1. The SS4 model is for 5 HP motors and is 14 CFM at 90 PSI. The SS3 model is rated for 3 HP motors is 11.8 CFM at 90 PSI.

      Helpful?

  7. Shaft Size and Keyway

    What is the shaft and Keyway for this pump? Looking to change the flywheel out to get the proper RPM and wanted to make sure I purchase the correct one.

    1 answer

    1. This Ingersoll Rand SS3 compressor pump has a tapered shaft that tapers from 0.942" to 0.939" with a 3/16" keyway.

      Helpful?

  8. Where is this made?

    Made in USA?

    1 answer

    1. This Ingersoll Rand Single-Stage Compressor Pump is made in India.

      Helpful?

  9. what is the recommended ac 115/120 motor to go with this compressor?

    1 answer

    1. At the moment Northern Tool does not offer a 115/120V compressor duty motor that is rated to 3HP.

      Helpful?

  10. Can you tell me what the mounting bolt pattern dimensions are and confirm that it uses a V belt as the picture shows.

    1 answer

    1. This pump uses a 4 bolt mounting pattern that is 6'' x 5''. This pump uses a V belt.

      Helpful?
