Honda Self-Priming Water Pump, 4,440 GPH, 1 1/2in. Ports, 49cc Honda GXH50 4-Stroke Engine, Model# WX15AX2
This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.
Click or Tap image to Zoom
$589.00
- Durable 49cc Honda GXH50 commercial-grade engine is easy to start and provides ample power for the toughest conditions
- Compact and easy to use at only 20 lbs.
- Standard transport handle
- Hose clamps and strainer included
- Honda Oil Alert® protects the pump by shutting the engine off when low oil is detected
Prop 65 Warning: See Details
See full description
Price for all four:
$851.97
-
Are the NPT threads male or female on the connections?
-
Helpful?
-
This pump has male threads on the suction and discharge connections.
Helpful?
-
-
can this pump run deadheaded for any period of time?
-
The pump cannot run dry or be deadheaded without causing damage to the pump.
Helpful?
-
Not really. While it might survive a second or two, deadhead time puts extreme stress on the pump and can cause damage not covered under warranty. -Robert@Honda
Helpful?
-
-
What it the runtime on a single tank of fuel?
-
Because there are too many variables involved, there is no specification on the run time published for this water pump, by the manufacturer
Helpful?
-
Hi Johndeere44:
Sorry, but Honda does not publish run-time specs for this model. I checked with a model engineer, and he tells me it is because there are too many variables that can effect the run time. Amount of total lift for both the suction and discharge hoses, elevation of the pump (all gasoline engines make less power at higher altitudes), type of strainer, etc. All these things will effect the fuel consumption. I can tell you a 4-stroke motor is generally efficient, and the tanks size is suitable, providing a reasonable fuel supply for this application. -Robert@Honda
Helpful?
-
-
does this motor come with a spark arrestor screen?
-
Hi Tony1play:
A spark arrestor is not included with this pump, but is available as an accessory part. You can order it from any Honda dealer, or request it be ordered and installed on a new pump.
-Robert@Honda
Helpful?
-
This motor does not come with any kind of spark screen.
Helpful?
-
-
Can it pass pea gravel?
1 answer-
The pump is not recommended for pumping pea gravel or large solids. You would need a semi-trash pump or a trash pump for pumping pea gravel.
Helpful?
-
-
Is the pump head a diaphragm or centrifugal pump?
1 answer-
The water pump would have a centrifugal pump head.
Helpful?
-
-
Are the seals on the pump viton
1 answer-
The seals are not viton, they are made of carbon and ceramic.
Helpful?
-
-
Can the 1.5” hose be reduced to attach to a 3/4” garden hose ?
1 answer-
It is not recommended to reduce the discharge hose size as it will cause back pressure and damage the pump over time.
Helpful?
-
-
Can this be shipped to California?
1 answer-
This pump can ship to California.
Helpful?
-
-
Can the discharge hose be converted down to connect into a 3/4" garden hose?
1 answer-
You would be able to use an adapter to convert the water pump from a 1 1/2 inch port to fit a 3/4 inch garden hose.
Helpful?
-
Accessories We Recommend
This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.
See All Engine Driven Clear Water Pumps
See All Honda Power Equipment Engine Driven Clear Water Pumps
Currently Viewing This Product
Specifications
Specifications
Honda Self-Priming Water Pump, 4,440 GPH, 1 1/2in. Ports, 49cc Honda GXH50 4-Stroke Engine, Model# WX15AX2
Gol Pumps Self-Priming Water Pump, 9,245 GPM, 2in. Ports, 196cc Engine, Model# WG20
Gol Pumps Portable Self-Priming Water Pump, 2,113 GPH, 1in. Ports, 31cc Engine, Model# XG10
Pacer Water Pump Rebuild Kit, For Item# 109963 Chemical Water Pump, Model# 58-702EP-U
Max. Flow
Same
74 GPM
9,245 GPM
2,113 GPM
12,000 GPM
Engine Displacement
Same
49 cc
196 cc
31 cc
206 cc
Port Size
Same
1.5 in
2 in
1 in
2 in
Self-Priming
Same
Yes
Yes
Yes
Yes
Max. PSI
Same
54 PSI
43 PSI
42 PSI
52 PSI
Housing Material
Same
Aluminum
-
-
Polyester
Product Weight
Same
lb
55.1000 lb
15.5000 lb
-
Dimensions L x W x H (in.)
Same
12.875 x 10.875 x 14.875 in
20.3 x 16.3 x 16.3 in
13.6 x 10.5 x 12.4 in
-
Fuel Tank Capacity
Same
-
0.68 Gal
0.13 Gal
-
Max. Horsepower
Same
-
6 HP
-
5.5 HP
