This engine is recoil start only, and does not have an amp rating.
Honda Engines, HONDA 160CC OHV GENERATOR ENGI, Engine Displacement 163 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 3/4 in, Model# GX160UT2VA2
This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.
Click or Tap image to Zoom
$499.99
- Automatic decompression for easy starting
- Heavy-duty ball bearing supported crankshaft
- Cast iron cylinder bore
- Double walled heavy-duty tank with in tank fuel strainer
- Fits U.S.A. applications
See full description
Price for all four:
$603.96
Accessories We Recommend
This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.
See All Horizontal Engines
See All Honda Engines Horizontal Engines
Currently Viewing This Product
Specifications
Specifications
Honda Engines, HONDA 160CC OHV GENERATOR ENGI, Engine Displacement 163 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 3/4 in, Model# GX160UT2VA2
NorthStar c180 Horizontal OHV Engine with Recoil Start, 179cc, 3/4in. x 2-7/16in. Shaft
Kohler Command PRO V-Twin Cylinder OHV Horizontal Engine - 20.5 HP, 674cc, 1.437in. x 4.41in. Shaft, Model# PA-CH640-3165
Kohler Command PRO Horizontal OHV Engine with Electric/Recoil Start - 429cc, 1in. x 3.49in. Shaft, 3600 RPM, Model# PA-CH440-3270
Engine Displacement
Same
163 cc
179 cc
675 cc
429 cc
Engine Type
Same
GX Series OHV Commercial-duty
OHV
Horizontal Gas
Command Pro
Shaft Diameter
Same
3/4 in
3/4 in
1-7/16 in
1 in
Shaft Length
Same
2.82 in
2.43 in
4.41 in
3.49 in
Start Type
Same
Recoil
Recoil
Electric
Electric and Recoil
Net Torque
Same
7.6 ft-lbs.
9.5 ft-lbs.
35.7 ft-lbs.
22.7 ft-lbs.
Crankshaft
Same
V-type
SAE J609EXT3 Straight Key W/shaft Dia.: 19.050mm (0.750in.) - Nominal
Hardened
Hardened
PTO Height
Same
4.17 in
4.17 in
-
-
Cylinders (qty.)
Same
1
1
2
1
Cylinder Bore
Same
Cast Iron
2.56
Cast Iron
Cast Iron
Net Power Output
Same
4.8 HP
3.7 HP
20.5 HP
14 HP
Compression Ratio
Same
9:1
8.5:1
8.5:1
8.0:1
Fuel Tank
Same
Yes
Yes
-
Yes
Fuel Tank Capacity
Same
3.3 qt
3.49 qt
-
1.7 qt
Oil Capacity
Same
0.59 qt
0.58 qt
2 qt
1.7 qt
Low Oil Shutdown
Same
Yes
Yes
Yes
Yes
Shaft Rotation (From PTO Shaft Side)
Same
Counter Clockwise
Counter Clockwise
Counter Clockwise
Counter Clockwise
Governor System
Same
Centrifugal Mechanical
Yes
Variable Speed Control
-
Ignition System
Same
Electronic
Transitorical Configuration
Electronic
Electronic
Carburetor
Same
Float, External Vent
Carburated
Smart Choke
Yes
Lubrication System
Same
Splash
Splash
Full Pressure
Splash
Auto Compression Release
Same
Yes
Yes
-
No
Cooling System
Same
Air
Air
Air
Air
Bore
Same
2.7 in
2.55 in
3.1 in
3.5 in
Stroke
Same
1.8 in
2.125 in
2.6 in
2.7 in
Air Cleaner Type
Same
Dual Element
Foam+paper
Dual Element
Dual Element
Choke Control
Same
Manual
Manual
Automatic
Remote
Throttle Control
Same
Manual
Adjustable
Automatic
Remote
Muffler Included
Same
Yes
Yes
Yes
Yes
Shaft Diameter Metric
Same
-
19.05 mm
36 mm
-
Shaft Length Metric
Same
-
61.7 mm
9.5 mm
88.646 mm
Shaft Keyway
Same
-
1-51/64 in
3/8-16 UNF in
3/8-24 UNF in
Low Oil Alert
Same
-
Yes
Yes
Yes
Bearing Type
Same
-
Ball
Parent Material
Ball
Charging System Amps
Same
-
No
20
3
Bolt Circle
Same
-
3.625 in
-
-
Mounting Base Length
Same
-
6.378 in
-
-
Mounting Base Width
Same
-
3.15 in
-
-
Fuel Filter
Same
-
-
Yes
Yes
Fuel Type
Same
-
-
-
Gasoline
Max. RPM
Same
-
-
-
3,750
