Honda Engines, HONDA GX 270CC ENGINE, Engine Displacement 270 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 1 in, Model# GX270UT2QC9

Item# 60969
Honda Engines, HONDA GX 270CC ENGINE, Engine Displacement 270 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 1 in, Model# GX270UT2QC9

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Honda Engines, HONDA GX 270CC ENGINE, Engine Displacement 270 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 1 in, Model# GX270UT2QC9

Click or Tap image to Zoom

$799.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Not for sale in CA

See full description

Complete Your Solution

  • Honda Engines, HONDA GX 270CC ENGINE, Engine Displacement 270 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 1 in, Model# GX270UT2QC9
  • Honda Power Equipment 10W-30 Motor Oil, 1-Qt. Bottle
  • GDI, HOUR METER W/TACHOMETER, Model# N111-0100-1005
Price for all three:

$862.97

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Honda 270cc GX Series OHV commercial-grade engine is designed for the most demanding commercial applications. It has set an industry standard for reliability and durability. Overhead valve design offers cooler, fuel-efficient operation and cast iron cylinder sleeve provides longer service life. The GX is reliable, easy starting and quiet running. Meets EPA and CARB emission levels standards. This legendary engine has earned the reputation as the preferred engine for construction equipment. Common applications include pressure washers, compressors, go-karts, log splitters and chipper/shredders. Not for sale in CA.

What's Included

    (1) Engine, Model# GX270UT2QC9

Downloads

Product Manual
Additional Product Info

Features + Benefits

  • Not for sale in CA

Key Specs

AttributeSpecification

item#

60969

Brand

Honda Engines

Manufacturer's Warranty

3 year limited warranty

Ship Weight

63.0 LB

Engine Displacement

270 cc

Engine Type

GX Series OHV Commercial-duty

Shaft Diameter

1 in

Shaft Length

3.48 in

Start Type

Recoil

Net Torque

14.1 ft-lbs.

Crankshaft

Q-type

PTO Height

5.25 in

Cylinders (qty.)

1

Cylinder Bore

Cast Iron

Net Power Output

8.5 HP
AttributeSpecification

Compression Ratio

8.5:1

Fuel Tank Capacity

5.6 qt

Oil Capacity

1.16 qt

Shaft Rotation (From PTO Shaft Side)

Counter Clockwise

Governor System

Centrifugal Mechanical

Ignition System

Electronic

Carburetor

Float, Inner Vent

Lubrication System

Splash

Cooling System

Air

Bore

3 in

Stroke

2.3 in

Air Cleaner Type

Cyclone

Choke Control

Manual

Throttle Control

Remote

Reviews

Questions & Answers

2 Reviews This action will navigate to reviews.

Questions

1–2 of 2 Questions
Sort by:

  1. What is the HP?

    1 answer

    1. The engine would be an approximate 8.5 HP.

      Helpful?

  2. Shaft is 1". Does this shaft have a key way?

    1 answer

    1. This engine has a 1/4 x 1-1/2 keyway on the shaft.

      Helpful?
