Hobart AirForce 27i Plasma Cutter With Multi-Voltage Plug, Inverter, 120V/240V, 15A/20A/30A Output, Model #500575

Item# 96172
"Hobart AirForce 27i Plasma Cutter With Multi-Voltage Plug, Inverter, 120V/240V, 15A/20A/30A Output, Model #500575"
Hobart AirForce 27i Plasma Cutter With Multi-Voltage Plug, Inverter, 120V/240V, 15A/20A/30A Output, Model #500575

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Hobart AirForce 27i Plasma Cutter With Multi-Voltage Plug, Inverter, 120V/240V, 15A/20A/30A Output, Model #500575

Click or Tap image to Zoom

$1799.99

  • Shipping:

    Free shipping (lower 48 states) - Available now
    $19.99 Same Day

  • Store Pickup:

    1 in stock at Fredericksburg VA - Pickup in under 1 hr

  • Dual-Voltage capability with MVP (Multi-Voltage Plug) allows you to connect to common 120 or 240V power receptacles without the use of any tools, simply choose the plug that fits the receptacle
  • Clean cuts 3/8in. mild steel; severs steel up to 5/8in. thick
  • XT30R torch is designed for increased comfort with an ergonomic trigger safety, more efficient cooling and economical replacement cutting tips
  • Wind Tunnel Technology™ prevents abrasive dust and particles from damaging internal components
  • Fan-On-Demand™ cooling system operates only when needed, reducing power consumption and contaminants drawn into the machine

See full description

Complete Your Solution

  • Hobart AirForce 27i Plasma Cutter With Multi-Voltage Plug, Inverter, 120V/240V, 15A/20A/30A Output, Model #500575
  • Klutch Cut-Resistant Goatskin/Cowhide MIG Welding Gloves, Single Pair, Gold/Black, XL
  • Ingersoll Rand Twin-Stack Portable Electric Air Compressor, 2 HP, 4-Gallon, 4.3 CFM, Model# P1IU-A9
  • Klutch Steel Welding Table with Tool Kit, 36in.L x 24in.W x 33-1/4in.H
Price for all four:

$2472.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Hobart AirForce® 27i Plasma Cutter With Multi-Voltage Plug is an economical plasma cutter system for all conductive metals. Inverter-based design and reliable technology pack a lot of performance into a very portable package. The AirForce 27i features a multi-voltage plug (MVP) that allows a user to connect to common 120V or 240V power receptacles. The XT series torch and long life XT tips and electrodes provide added performance to an already exceptional plasma cutter. Plasma cutters cut faster and more precisely with a thinner kerf and less slag than cutting with oxy fuel. A smaller heat-affected zone also causes less warping. And you'll never have gas pressure settings, flame tuning, metal preheating or gas cylinders or refills to worry about.

What's Included

    (1) AirForce 27i plasma cutter (2) Tips (1) Electrode (1) Shield deflector (1) 10-ft. (3m) power cord with 5-15P (120V, 15 Amp) and 6-50P (240V, 50 Amp) MVP™ plugs (1) Easy-to-connect, built-in gas/air filter and regulator (1) 12 ft. XT30R hand-held torch (1) 12 ft. work cable with clamp (1) Cable management system

Downloads

Product Manual Product Manual2
Play Item Video

Features + Benefits

  • Dual-Voltage capability with MVP (Multi-Voltage Plug) allows you to connect to common 120 or 240V power receptacles without the use of any tools, simply choose the plug that fits the receptacle
  • Clean cuts 3/8in. mild steel; severs steel up to 5/8in. thick
  • XT30R torch is designed for increased comfort with an ergonomic trigger safety, more efficient cooling and economical replacement cutting tips
  • Wind Tunnel Technology™ prevents abrasive dust and particles from damaging internal components
  • Fan-On-Demand™ cooling system operates only when needed, reducing power consumption and contaminants drawn into the machine
  • Power Factor Correction (PFC) circuitry draws up to 30% less amperage for the same cutting range when compared to the competition, expanding an operator's work area via extension cord, while minimizing nuisance circuit breaker trips caused by voltage drops
  • LVC™ line voltage compensation provides peak performance power under variable input voltage conditions (+/- 15%) for steady and cleaner-ending cuts
  • Internal gas/air filter and regulator controls the amount of usage and flow, or air or gas
  • Starts without high frequency protecting the unit by not interfering with or damaging controls or computers
  • Diagnostics LED lights for quick troubleshooting of pressure, power and cup situations
  • Postflow cooling circuit extends the life of consumables and torch by cooling them with postflow air after the trigger is released
  • Compatible with engine-driven welders, delivering complete cutting capability when powered by an engine-driven welder/generator with 240V receptacle of 4 kW or more
  • Hobart 5/3/1 industrial warranty offers: a 5-year limited warranty on transformers, stabilizers and main rectifiers; 3-year limited warranty on generators, PC boards and drive systems; and 1-year limited warranty on guns (MIG, Plasma and TIG torches)

Key Specs

AttributeSpecification

item#

96172

Brand

Hobart

Manufacturer's Warranty

5 year limited warranty

Ship Weight

21.6 LB

Volts

Multi

Amps

30

Cutting Thickness

0.375 in

Sever Thickness

0.63 in

Clamp Cable Length

1 in
AttributeSpecification

Plasma Gas Flow

5 cfm

Max. PSI

90

Duty Cycle

120 V (15a) 20a At 88 Vdc, 60% Duty Cycle; 120 V (20a) 27a At 92 Vdc, 35% Duty Cycle; 240v 30 A At 92 Vdc, 40% Duty Cycle

Power Cord Length

10 ft

Compressor Included

No

Cart Included

No

Product Weight

19.0000 lb

Dimensions L x W x H (in.)

9.0 x 5.5 x 13.25 in

Reviews

Questions & Answers

28 Reviews This action will navigate to reviews.

Questions

1–9 of 9 Questions
Sort by:

  1. Does this unit have the “pilot arc” feature? Where it doesn’t need to ground through the piece you are working on to strike the arc?

    1 answer

    1. This unit comes with the XT30R torch with a drag shield.

      Helpful?

  2. Does this Hobart AirForce 27i plasma cutter include a built in air compressor like the smaller model does?

    1 answer

    1. This plasma cutter does not have a built-in air compressor. The recommended air compressor is item number 154220.

      Helpful?

  3. What is maximum thickness for cutting?

    1 answer

    1. The maximum clean cut thickness is 3/8".

      Helpful?

  4. is this a mig tig and plasma cutter

    1 answer

    1. This is a plasma cutter only and can be run on 120 volt or 230 volt.

      Helpful?

  5. Does this machine have a water separator built in?

    1 answer

    1. The plasma cutter will come with a built in water separator. It is recommended that an external water separator also be added as well to the plasma cutter for the cleanest driest air possible.

      Helpful?

  6. Does the Hobart AirForce® 27i Plasma Cutter come with cutter drag shield item #48991, which fits the XT30R plasma torch? Or, do I need to order it separately.

    1 answer

    1. The drag shield needs to be purchased separately. Northern Tool no longer carries the drag shield.

      Helpful?

  7. How available are the disposables used with this unit??

    1 answer

    1. The disposables for this unit are generally in stock and available for ordering.

      Helpful?

  8. How much air pressure for the airforce 27i

    1 answer

    1. This Hobart Plasma Cutter requires 3 CFM at 90-120 PSI for operation.

      Helpful?

  9. 240v outlet

    I'm having a 240v outlet and breaker wired in my garage. How many amp breaker should I have for this cutter? I was thinking a 50 amp but the plug that came with the cutter says 20 amp.

    1 answer

    1. The Hobart AirForce 27i plasma cutter includes a 10-ft. power cord with 5-15P (120V, 15 Amp) and 6-50P (240V, 50 Amp) MVP™ plugs. The 6-50P plug can be used with a 30 amp circuit breaker or larger.

      Helpful?
