Fill-Rite Cast Aluminum Heavy-Duty Piston Drum Pump, 2in. NPT, Model# FR152NT

Item# 109579
Fill-Rite Cast Aluminum Heavy-Duty Piston Drum Pump, 2in. NPT, Model# FR152NT

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Fill-Rite Cast Aluminum Heavy-Duty Piston Drum Pump, 2in. NPT, Model# FR152NT

Click or Tap image to Zoom

$249.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Durable corrosion-resistant cast aluminum
  • Double piston action delivers 20 gallons every 100 strokes, saving time and effort
  • No electricity needed -- ideal for low-volume applications were access to power is now available
  • Designed for stationary or mobile use
  • Onboard vacuum breaker facilitates uninterrupted performance, creating a smoother flow at discharge

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The Fill-Rite® FR152 Cast Aluminum Heavy-Duty Piston Drum Pump delivers 20 gallons per 100 strokes. This hand lever fuel transfer pump and accessory bundle comes complete with a spout, suction pipe, discharge hose and installation components.

What's Included

    (1) Hand fuel pump

Downloads

Product Manual
Play Item Video

Features + Benefits

  • Durable corrosion-resistant cast aluminum
  • Double piston action delivers 20 gallons every 100 strokes, saving time and effort
  • No electricity needed -- ideal for low-volume applications were access to power is now available
  • Designed for stationary or mobile use
  • Onboard vacuum breaker facilitates uninterrupted performance, creating a smoother flow at discharge
  • Padlock-compatible handle adds security to protect your investment
  • Included discharge nozzle storage and anti-siphon technology prevent accidental fuel spillage

Key Specs

AttributeSpecification

item#

109579

Brand

Fill-Rite

Manufacturer's Warranty

2 year limited warranty

Ship Weight

15.65 LB

Pump Style

Piston
AttributeSpecification

GPM

20

For Use With

Gas, Diesel

Inlet Port

1 in

Outlet Port

3/4 in

Material

Cast Iron

Reviews

Questions & Answers

52 Reviews This action will navigate to reviews.

Questions

1–10 of 15 Questions
Sort by:

  1. How will this pump perform on hydrolic oil in subzero weather?

    1. When pumping hydraulic oil in very cold temperatures, the oil will become more viscous and more difficult to pump.

      Helpful?

    2. Thanks for your question on using the FR152 with hydraulic oil.

      When pumping hydraulic oil in very cold temperatures, the oil will become more viscous and more difficult to pump.

      The maximum viscosity that we typically recommend is around 350 centipoise (2000 SSU). After that, it just becomes more and more difficult to pump the oil. As a reference, 350 centipoise is like 30 weight motor oil at 70° F.

      You can still pump the oil when the viscosity is higher, but again, it takes more effort.

      Thanks again for your question.

      Best Regards,
      Tuthill Technical Support

      Helpful?

  2. Do you have 8' replacement hose for this unit?

    1. Our part # is TVH058G9054. Please call our parts department @ 1-800-657-0516 for price and availability.

      Helpful?

    2. Thanks for your question.

      Yes, we do have a replacement hose for the FR152 Piston Hand Pump. Our part number is H058G9054. This is the 8' hose that is sold with the pump.

      Have a great week.
      Best Regards,

      Helpful?

  3. How do I connect goldenrod filter to flow rite piston hand pump

    The angle looks like you can't get it on without some kind of angled fitting.

    1. When looking at the pump, you will notice the black plug that is on the top of the pump. This is the vacuum breaker, and it is threaded into a ¾" opening.

      Remove the vacuum breaker and install it in the angled port on the side of the pump (normally where the hose screws into the pump).

      Now you can install a nipple (if needed) and a street elbow right out of the top of the pump. You can connect the Goldenrod filter head to the street elbow. I would install a second street elbow on the discharge side of the filter head so that your hose will hang straight down, preventing it from crimping over.

      Helpful?

    2. Thanks for your question. It is a great one. When looking at the pump, you will notice the black plug that is on the top of the pump. This is the vacuum breaker, and it is threaded into a ¾" opening.

      Remove the vacuum breaker and install it in the angled port on the side of the pump (normally where the hose screws into the pump).

      Now you can install a nipple (if needed) and a street elbow right out of the top of the pump. You can connect the Goldenrod filter head to the street elbow. I would install a second street elbow on the discharge side of the filter head so that your hose will hang straight down, preventing it from crimping over.

      Best Regards

      Helpful?

  4. Is this pump compatible with methanol

    1. This is not compatible with 100% methanol.

      Helpful?

    2. The FR152 is not compatible with 100% methanol. If this is what you are pumping, then this pump will not work. If you are pumping some blend of methanol and another liquid, I would need to know the percentages of methanol and the other liquid(s).

      Thanks for your interest in our products.

      Best Regards,

      Helpful?

  5. Do you sell a rebuild kit for this pump?

    Tuthill Transfer Pump 5200 Series / Model FR152

    1. The item # is 109611. Please see below.

      Helpful?

    2. Thanks for your question on the rebuild kit.

      Yes, there is a rebuild kit for the piston hand pump. The Northern Tool item number is 109611.

      Thanks and Best Regards,

      Helpful?

  6. is there a filter kit available for this model?

    1. The filter kit is item # 39623. This contains a cast iron filter head, an 18 GPM 10 micron spin on filter, and a multi plane swivel. Please see below.

      Helpful?

    2. Thanks for your question on filters and the FR152 Piston Hand Pump.

      The kit is the KIT375FA as I have attached my response. This will contain a cast iron filter head, an 18 GPM, 10 micron spin on filter, as well as a multi plane swivel.

      Let us know if you have any further questions.

      Thanks and Best Regards,

      Helpful?

  7. Will this pump work on your fuel tank #71083?

    1. The #71083 fuel tank has a standard 2" opening on the top that the Fill-Rite pump will mount into.

      Helpful?

    2. The #71083 fuel tank has a standard 2" opening on the top that the Fill-Rite pump will mount into.

      Simply screw the suction pipe into the pump (don't forget to use a sealant on the threads), then lower the suction pipe into the tank and screw the pump into the 2" opening on top of the tank.

      You may want to consider using sealant on the 2" threads as well. Sealing these threads will help keep water from seeping into the tank.

      Have a great week!

      Helpful?

  8. Can this pump be used for gasoline or diesel fuel?

    1. Yes, this will work with both gasoline and diesel fuel.

      Helpful?

    2. Thanks for your interest in Fill-Rite products!

      The piston hand pump will work very well with both gasoline and diesel fuel.

      Thanks again for your interest. Have a Great Week.

      Helpful?

  9. What is the length of the inlet tube.

    I do not yet have a tank. It seems like the length of the inlet tube and the depth of the tank would need to be very close (without hitting the bottom of the tank of course) in order to pump as much fuel as possible from the tank.

    Please let me know the length of inlet pipe so that I can select a tank accordingly. Or if I am not understanding how this works, maybe you can explain things to me.

    1. Comes with an inner and outer tube which slide together so you have almost 2ft if range on the depth of the tank. mine in on a square truck box tank which only a little ove 2 ft but the tube will slide to accommodate a 55gal drum.

      Helpful?

    2. The suction pipe adjusts to fit 15-55 gallon drums. The shortest length is 20" and fully extended the length would be 34".

      Helpful?

  10. Fill-Rite Hand Fuel Pump — 2in. NPT, Model# FR152NT I want to pump gasoline from an underground tank. How much vertical lift will this pump produce?

    1. We pump fuel from a 12,000 gallon underground tank that is more than 10 feet to the bottom and have no problem.

      Helpful?

    2. The pump has a maximum vertical lift of 11 feet.

      Helpful?

Warranty

Manufacturer's Warranty

2 year limited warranty
