Fill-Rite, 2 to 20 GPM Digital Meter, Model# 825X700

Item# 6151213
Fill-Rite, 2 to 20 GPM Digital Meter, Model# 825X700

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Fill-Rite, 2 to 20 GPM Digital Meter, Model# 825X700

Click or Tap image to Zoom

$285.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Designed with nutating disc technology that is capable of moving rust and small debris that jam and cause damage to other meters.
  • Rugged polypropylene body resists corrosion in demanding chemical and industrial applications.
  • Measures fluids within +/- 1% accuracy, ensuring your record-keeping is precise as possible.
  • In-line design allows for installation at the pump or at the end of the discharge hose, with an LCD display that rotates 360° for your convenience.
  • Track fluids in any user-created unit in addition to preset measurements like gallons, litres, ounces, pints, and quarts.

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The 825X700 Digital Meter measures 2 to 20 GPM with EPDM seals. Has an accuracy of ±0.5%, left to right flow and 1in. NPT Threads. Measures in gallons, liters, quarts, pints, ounces, and special units (Field Selectable) with 20 preset calibration points. For use with water and chemicals. Not for use with liquids with a flash point of 100° F (37.8° C) or less.

What's Included

    (1) One Digital Meter

Features + Benefits

  • Designed with nutating disc technology that is capable of moving rust and small debris that jam and cause damage to other meters.
  • Rugged polypropylene body resists corrosion in demanding chemical and industrial applications.
  • Measures fluids within +/- 1% accuracy, ensuring your record-keeping is precise as possible.
  • In-line design allows for installation at the pump or at the end of the discharge hose, with an LCD display that rotates 360° for your convenience.
  • Track fluids in any user-created unit in addition to preset measurements like gallons, litres, ounces, pints, and quarts.
  • One-step field calibration for numerous fluids makes installation quick, saving you time and eliminating frustration.

Key Specs

AttributeSpecification

item#

6151213

Brand

Fill-Rite

Manufacturer's Warranty

2 year limited warranty

Ship Weight

1.53 LB

Min. Flow Rate

2 GPM

Max. Flow Rate

20 GPM

Max. PSI

50

Product Type

Fuel Meters
AttributeSpecification

Inlet Port

1 in. NPT

Outlet Port

1 in. NPT

Min. Temperature

0 °F

Max. Temperature

130 °F

Display

Digital

Product Weight

1.5300 lb

Dimensions L x W x H (in.)

3.3 x 5.5 x 5.2 in

Reviews

Questions & Answers

Questions

  1. I need readings in SCFM, is this meter capable to swap the scale measure?

    1 answer

    1. It would not be recommended to swap the scale measure on this digital meter.

      Helpful?

Warranty

Manufacturer's Warranty

2 year limited warranty
