Endurance Marine Hand Winch With Auto Brake, 3500-Lb. Capacity, Model# RBW3500

Item# 97105
Endurance Marine Hand Winch With Auto Brake, 3500-Lb. Capacity, Model# RBW3500

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Endurance Marine Hand Winch With Auto Brake, 3500-Lb. Capacity, Model# RBW3500

Click or Tap image to Zoom

$273.00

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Heavy-duty marine grade hand winch made from durable high quality steel
  • Features an automatic brake in any position during operation
  • 3500-lb. pulling capacity
  • Adjustable and removable handle
  • 18.4:1 gear ratio

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Endurance Marine RBW auto brake hand winch is a heavy-duty marine grade winch made from durable steel, strong enough to handle the harshest of conditions, and holds up in marine and industrial environments. The winch features an automatic brake in any position during operation. The solid gears and stamped frame provide superb strength and long-term durability. The winch is made of high quality steel.

What's Included

    (1) Hand winch (1) Handle

Downloads

Product Manual

Features + Benefits

  • Heavy-duty marine grade hand winch made from durable high quality steel
  • Features an automatic brake in any position during operation
  • 3500-lb. pulling capacity
  • Adjustable and removable handle
  • 18.4:1 gear ratio
  • Drum capacity: 72ft. x 1/4in. steel cable
  • Drum capacity: 42ft. x 1/16in. strap

Key Specs

AttributeSpecification

item#

97105

Brand

Endurance Marine

Manufacturer's Warranty

1 year limited warranty

Ship Weight

10.0 LB

Product Type

Hand Winch

Load Capacity

3,500 lb
AttributeSpecification

Drum Capacity

72 ft

Max. Rope Diameter

1/4 in

Gear Ratio

18.4:1

Product Weight

18.0000 lb

Dimensions L x W x H (in.)

7.0 x 6.0 x 5.0 in

Reviews

Questions & Answers

Questions

1–5 of 5 Questions
Sort by:

  1. Is it Bi-directional, i.e. up and down?

    1 answer

    1. The model RBW3500 is a single directional winch.

      Helpful?

  2. I have 2 inch strap is drum wide enough to handle it ?

    1 answer

    1. The widest strap the winch will accommodate is 1.5".

      Helpful?

  3. What kind of connection connects the handle to the winch?

    1 answer

    1. Insert the hexagon socket of the crank handle on to the hexagon end of the main drive axle. Screw tightly using the enclosed screw nut and hex key. Make the pitch and screw hole at the same level.

      Helpful?

  4. Can you use an electric drill with a socket hooked directly to the drive shaft for increased operating speed in lieu of the handle?

    1 answer

    1. This winch is not designed to be used with a power drill or other similar attachments.

      Helpful?

  5. Does the brake work in both up and down operation.  I need to lift a load, hold, and then lower the load.  There will be a 2000 lb load in both up and down direction

    1 answer

    1. The brake will hold in both up and down operation. It would handle the 2000 pounds.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
