Endurance Marine Hand Winch With Auto Brake, 2500-Lb. Capacity, Model# RBW2500

Item# 97106
Endurance Marine Hand Winch With Auto Brake, 2500-Lb. Capacity, Model# RBW2500

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Endurance Marine Hand Winch With Auto Brake, 2500-Lb. Capacity, Model# RBW2500

Click or Tap image to Zoom

$196.00

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Heavy-duty marine grade hand winch made from durable high quality steel
  • Features an automatic brake in any position during operation
  • 2500-lb. pulling capacity
  • Adjustable and removable handle
  • 11.1:1 gear ratio

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Endurance Marine RBW auto brake hand winch is a heavy-duty marine grade winch made from durable steel, strong enough to handle the harshest of conditions, and holds up in marine and industrial environments. The winch features an automatic brake in any position during operation. The solid gears and stamped frame provide superb strength and long-term durability. The winch is made of high quality steel.

What's Included

    (1) Hand winch (1) Handle

Downloads

Product Manual

Features + Benefits

  • Heavy-duty marine grade hand winch made from durable high quality steel
  • Features an automatic brake in any position during operation
  • 2500-lb. pulling capacity
  • Adjustable and removable handle
  • 11.1:1 gear ratio
  • Drum capacity: 55ft. x 1/4in. steel cable
  • Drum capacity: 32ft. strap

Key Specs

AttributeSpecification

item#

97106

Brand

Endurance Marine

Manufacturer's Warranty

1 year limited warranty

Ship Weight

9.0 LB

Product Type

Hand Winch

Load Capacity

2,500 lb
AttributeSpecification

Drum Capacity

55 ft

Max. Rope Diameter

1/4 in

Gear Ratio

11.1:1

Product Weight

15.0000 lb

Dimensions L x W x H (in.)

7.0 x 6.0 x 5.0 in

Reviews

Questions & Answers

Questions

1–3 of 3 Questions
Sort by:

  1. Can this model free wheel, when dispensing cable or rope to the load or must you crank it backwards?

    1 answer

    1. The winch does have free spool. You will need to remove the crank handle. Press the handle knob and turn the knob counter clockwise. Do not use the free spool function under load.

      Helpful?

  2. I want to use this on my davit which would hang upside down. I think i would have to hang it backwards to get the handle positioning right. Does mounting orientation matter? and can I use cable? or synthetic rope

    1 answer

    1. This can be mounted in different positions, it just needs to be properly bolted down. A steel cable or winch strap should be used.

      Helpful?

  3. Does this come with the necessary hardware for using a flat strap versus a rope wire?

    1 answer

    1. The winch will include the strap bar to attach a strap to it. See page 14 of the product manual on our web for instructions to install a strap.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
