EAGLE, 47 dB 25ft. Silent Air Compressor, Horsepower 1 HP, Air Tank Size 4 Gal, Volts 110 Volt, Model# EA-4000

Item# 6040126
EAGLE, 47 dB 25ft. Silent Air Compressor, Horsepower 1 HP, Air Tank Size 4 Gal, Volts 110 Volt, Model# EA-4000

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

EAGLE, 47 dB 25ft. Silent Air Compressor, Horsepower 1 HP, Air Tank Size 4 Gal, Volts 110 Volt, Model# EA-4000

Click or Tap image to Zoom

$454.99

  • Shipping:

    Factory shipped

  • Dual Piston Design Pumps more air than most of the competition.
  • 2.5 CFM @ 100 PSI
  • Only 47db @ 25ft
  • Features Eagle's easy start head unloader system to reduce starting amps
  • Low Speed 1720 RPM induction motor provides strong starting torque and reduces unecessary wear compared to higher speed motors.

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The Eagle Silent Series Compressor line up was designed specifically with the professional contractor in mind. Our units feature a dual piston system with a low RPM motor allowing the unit to run slower while creating less friction and less heat which add up to longer life. The Eagle Silent Air Compressors out last most other oil free compressor designs by 8 to 10 times! The With more than a half dozen product specific patents along with years of product engineering and development you can be sure that you are getting the industry best when you choose an Eagle Silent Series model. The EA-4000 is super quiet at only 47db 25ft. The dual tank side stack design is robust and practical at the same time. This unit is ideal for trim or framing roofing carpenters that need a quite compressor to make the job site more productive and safer. While powerful enought to operate pnuematic trim nd framing nail guns etc, this model also idea for around the house use to air up tires, balls, floats etc.

What's Included

    (1) AIR COMPRESSOR

Features + Benefits

  • Dual Piston Design Pumps more air than most of the competition.
  • 2.5 CFM @ 100 PSI
  • Only 47db @ 25ft
  • Features Eagle's easy start head unloader system to reduce starting amps
  • Low Speed 1720 RPM induction motor provides strong starting torque and reduces unecessary wear compared to higher speed motors.
  • All Steel Design Protects Critical Components From Job Site Elements
  • Large Pressure Gauges are set on a 65 degree angle, making them easy to read from a standing postion
  • Pro Style Dual Universal Quick Connects
  • Heavy duty, Robust Roll Cage Design Protects Critcal Components From Potential Damage on Work Sites or Garages
  • Dual piston pump and low rpm motor reduces friction and heat which both add up to longer life expectancy
  • Lever Style Drain Valves makes it easy to keep tank moisture drained
  • Built In Regulator
  • Operates 2 to 3 Pnuematic Air Nail Guns
  • Oil Free & Maintenace Free
  • 80% Quieter Than Traditional Air Compressors

Key Specs

AttributeSpecification

item#

6040126

Brand

EAGLE

Manufacturer's Warranty

1 year limited warranty

Horsepower

1 HP

Air Tank Size

4 Gal

Volts

110 Volt

CFM at 90 PSI

2.5

Max. PSI

125

Stage

1

Air Outlets (qty.)

2

Amps

7.2

Duty Cycle

0.5 %

Fuel Capacity

0 Gal

Motor RPM

1,720

Working Pressure

95-125 PSI

Motor Phase

1
AttributeSpecification

Pump Material

Cast Iron

Pump Drive

Direct

Air Outlet Size

1/4 in. NPT

CFM at 40 PSI

3.2

Noise Level

47 dB

Oil Required

No

Lubrication System

Oil-Free

Pressure Gauge

Yes

Electronic Drain Valve

No

After Cooler Included

No

Drain Type

Ball Valve

Tank Orientation

Horizontal

Engine Model

Not Applicalble

Product Weight

69.0000 lb

Dimensions L x W x H (in.)

16.9 x 16.5 x 16.5 in

Reviews

Questions & Answers

Warranty

Manufacturer's Warranty

1 year limited warranty
