EAGLE, 24 CFM Skid Mount No Tank, Horsepower 13 HP, Air Tank Size 30 Gal, Model# 11GSKTRKE

Item# 6104003
EAGLE, 24 CFM Skid Mount No Tank, Horsepower 13 HP, Air Tank Size 30 Gal, Model# 11GSKTRKE

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

EAGLE, 24 CFM Skid Mount No Tank, Horsepower 13 HP, Air Tank Size 30 Gal, Model# 11GSKTRKE

Click or Tap image to Zoom

$3199.99

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • GX390 Electric Start Honda Engine
  • 175 psi Two Stage
  • Cast Iron Pump
  • Automotive Style Air Filters
  • Skid Style Mount (No Tank)

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The 390cc 13hp electric start Eagle service truck air compressor has a heavy duty 3 cylinder cast iron compressor head that is driven with the quiet running reliable OHV Honda engine. The skid mount/top plate stlyle unit allows you to customize your service truck and add whatever size reciever tank to the locatoin of your choice on your truck. Making this unit ideal for off site service on the farm, contractor's site or other remote locations. The unit is loaded with convienent features like an extended oil drain automotive style air filters for easy service along with other features like the fuel saving idle control and easy view oil site gauge. With 24 CFMs of air and 175 psi of pressure, you can operate multiple tools at once.

What's Included

    (1) AIR COMPRESSOR SKID MOUNT ONLY - NO TANK

Downloads

Product Manual

Features + Benefits

  • GX390 Electric Start Honda Engine
  • 175 psi Two Stage
  • Cast Iron Pump
  • Automotive Style Air Filters
  • Skid Style Mount (No Tank)
  • Fully Enclosed Metal Belt Guard
  • Fuel Saving Idle Control Feature
  • Convenient Extended Oil Drain
  • "V" Style Design Minimizes Vibration & Improves Cooling
  • Easy View Oil Site Guage
  • Assembled in the USA!

Key Specs

AttributeSpecification

item#

6104003

Brand

EAGLE

Manufacturer's Warranty

1 year limited warranty

Ship Weight

420.0 LB

Horsepower

13 HP

Air Tank Size

30 Gal

Engine Brand

Honda

CFM at 90 PSI

24

Stage

2

Air Outlets (qty.)

0

Duty Cycle

100 %

Fuel Capacity

1.6 Gal

Motor RPM

3,600

Working Pressure

175 PSI
AttributeSpecification

Engine Displacement

390 cc

Engine Start Type

Electric and Pull

Pump Material

Cast Iron

Pump Drive

Belt

Oil Required

Yes

Low Oil Shutdown

Yes

Lubrication System

Splash

Pressure Gauge

Yes

Electronic Drain Valve

No

After Cooler Included

Yes

Air Dryer

None

Product Weight

410.0000 lb

Dimensions L x W x H (in.)

46.0 x 19.5 x 40.5 in

Reviews

Questions & Answers

Questions

Warranty

Manufacturer's Warranty

1 year limited warranty
